When turning [Angle] on in the <Rotation> group
and inclining the pattern
No. Parameter Adjustment
1 Angle Rotation angle of pattern
a) 1 p. 86.
When turning [Speed] on in the <Rotation> group
and rotating the pattern at a constant rate
No. Parameter Adjustment
1 Speed Rotation speed of pattern
a) 1 p. 86
6
To interchange color 1 and color 2, press the [Color
Invert] button, turning it on.
Applying the zabton effects
Notes
The zabton function and [Fine Key]
turned on at the same time.
1
In the M/E-1 >Key1 >Edge menu (1112), press
[Zabton], turning it on.
2
Adjust the following parameters.
No. Parameter Adjustment
1 Size Pattern size
2 Soft Edge softness of the pattern
3 Density Density
Notes
If in the pattern selection described below you select
"Mask Pattern," and "Box" for the main mask, the
"Size" parameter here cannot be adjusted. Set "Size"
in the Main Mask menu.
3
To adjust the pattern and color, press [Zabton Adjust].
The Zabton Adjust menu appears.
4
In the <Zabton Pattern> group, select the pattern.
Key Wipe: Use a key wipe.
You can change this pattern by pressing [Pattern
Select] to open the menu for key wipe pattern
selection (Pattern Select menu), and make
adjustments by pressing [Pattern Adjust] to open
the menu for pattern adjustment (Wipe Adjust
menu).
Key Edge Pattern: Use a color mixing pattern for key
edge.
a)
a)
5
(1 p. 71) cannot be

Mask

The mask function can be used to mask off unneeded parts
of a key or background, or to remove defects.
Using a mask
For example, to perform settings for key 1 on the M/E-1
bank, use the following procedure.
1
2
3
4
You can change this pattern by pressing [Pattern
Select] to open the menu for edge color mix
dedicated wipe pattern selection (Mix Pattern
Select menu), and make adjustments by pressing
[Pattern Adjust] to open the menu for pattern
adjustment (Matte Adjust menu).
Mask Pattern: Use the main mask Box or Pattern.
You can also press [Pattern Select], and in the
corresponding pattern adjustment menu, change the
pattern.
To adjust the color, press [Zabton Color] and adjust
the following parameters.
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3 Hue Hue
4 Density Density
Open the M/E-1 >Key1 >Main Mask menu (1113).
In the <Mask Type> group, select the mask type.
Key Mask: Masks a part of a key.
Bkgd Mask: Masks a part of a background.
In the <Mask Source> group, select the mask source.
Box: Signal from the dedicated box generator
Pattern: Signal from the dedicated pattern generator
Set the mask source parameters.
When Box is selected
No. Parameter Adjustment
1 Top Position of top side
2 Left Position of the left side
3 Right Position of the right side
4 Bottom Position of the bottom side
5 Soft Box softness
73
Key Adjustments (Menus)
