Windows Certificate Store vs. Certs Path

Note: It is important that all dates are correct on the HX3 and host computers when using any type of certificate. Certificates
are date sensitive and if the date is not correct authentication will fail.

User Certificates

EAP-TLS authentication requires a user certificate. The user certificate must be stored in the Windows certificate store.
• To generate the user certificate, see
• To import the user certificate into the Windows certificate store, see
• A Root CA certificate is also needed. Refer to the section below.

Root CA Certificates

Root CA certificates are required for EAP/TLS, PEAP/GTC and PEAP/MSCHAP. Two options are offered for storing these
certificates. They may be imported into the Windows certificate store or copied into the Certs Path directory.

Using the Certs Path

1. See Generating a Root CA Certificate
PC.
2. Copy the certificate to specified directory on the mobile device. The default location for Certs Path is \System. A
different location may be specified by using the Certs Path global variable. Note the location chosen for certificate
storage should persist after a reboot.
3. When completing the Credentials screen for the desired authentication, do not check the Use MS store check box
after checking the Validate server check box.
4. Enter the certificate name in the CA Cert text box.
5. Click OK to exit the Credentials screen and then Commit to save the profile changes.

Using the Windows Certificate Store

1. See Generating a Root CA Certificate
PC.
2. To import the certificate into the Windows store, See
3. When completing the Credentials screen for the desired authentication, be sure to check the Use MS store check
box after checking the Validate server check box.
4. The default is to use all certificates in the store. If this is OK, skip to the last step.
5. Otherwise, to select a specific certificate click on the Browse (...) button.
6.
7. Uncheck the Use full trusted store check box.
8. Select the desired certificate and click the Select button to return the selected certificate to the CA Cert text box.
9. Click OK to exit the Credentials screen and then Commit to save the profile changes.
9 - 18
Generating a User Certificate
(page 9-32) and follow the instructions to download the Root Certificate to a
(page 9-32) and follow the instructions to download the Root Certificate to a
Installing a Root CA Certificate
(page 9-36).
Installing a User Certificate
(page 9-35).
(page 9-41).
