HX3
Wearable Computer
Microsoft® Windows® CE 5 Operating System
Battery Charger User's Guide

Advertisement

   Also See for Honeywell HX3

   Related Manuals for Honeywell HX3

   Summary of Contents for Honeywell HX3

  • Page 1

    Wearable Computer Microsoft® Windows® CE 5 Operating System Battery Charger User's Guide...

  • Page 2: Limited Warranty

    Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HII.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1: Introduction About this Guide Setup Overview Cautions and Warnings Battery Charger Lithium-Ion Battery Pack Components Battery Charger Battery Charging Pocket Installation Assemble the Power Supply Setup Charging Batteries Inserting a Battery into the Charging Pocket Remove the Battery from the Charging Pocket Interpreting the Charging Pocket LEDs RED Continuous - on any charge pocket...

  • Page 4

    Dimensions 1-16 Chapter 2: Set up a Battery Maintenance Routine Introduction Extending Battery Life Self-Discharge Peripheral Devices Maintenance Routine Label the Batteries A Simple Battery Usage Routine Sample Log for Battery Maintenance Chapter 3: Technical Assistance...

  • Page 5: Chapter 1: Introduction

    This device cannot charge/recharge coin cell batteries sealed inside the mobile device, if any. About this Guide This HX3 Battery Charger User's Guide is intended to familiarize the user with the safety and operating instructions necessary to use the HX3 Battery Charger (Model HX2A310CHGR6US, HX2A311CHGR6WW) to charge rechargeable lithium-ion battery packs (HX2A301BATTSTD, HX2A302BATTEXT) .

  • Page 6: Cautions And Warnings

    Do not store the Li-Ion battery pack in direct sunlight or anywhere the battery pack cannot cool down. If the Li-Ion battery pack is hot after removal from the HX3, allow it to cool at room temperature or in a cool air stream before placing it in the charger.

  • Page 7: Components

    Components Battery Charger 1. Front 2. Battery Charging Pocket 3. Battery Charge LED Indicator 4. Analyze Pocket 5. Analyze LED 6. Analyze Dome Switch 7. Analyze Progress LEDs 8. AC/DC Power Connector...

  • Page 8: Battery Charging Pocket

    Battery Charging Pocket 1. Battery Charging Pocket 2. Alignment Ribs 3. Battery Charging Contacts 4. Battery Charge Progress LED Note: Batteries used by the HX3 body worn Voice device are charged, recharged and analyzed using the HX2 labeled battery charger.

  • Page 9: Installation

    Installation Assemble the Power Supply Assemble the AC adapter for the HX3 Battery Charger before connecting it to the charger. The AC power supply for the battery charger is shipped with the battery charger. Contact Technical Assistance if there is no AC cable.

  • Page 10: Setup

    Setup Prerequisite: The AC Adapter is assembled and receiving AC power. The battery charger should be located in an area where it: Is well ventilated. Is not in high traffic areas. Locates or orients the AC cord so that it will not be stepped on, tripped over or subjected to damage or stress. Has enough clearance to allow easy access to the power port on the back of the device.

  • Page 11: Charging Batteries

    Use the charge function to return the HX3 battery pack to its maximum available power capacity. Use the analyze function to compare the battery pack’s maximum available capacity to the specified capacity. This allows you to determine the battery pack’s power loss due to age.

  • Page 12: Inserting A Battery Into The Charging Pocket

    Inserting a Battery into the Charging Pocket Caution! It is important that battery packs are inserted into the charging pocket correctly. Inserting the battery incorrectly could result in damage to the battery pack or the charger. Caution! Do not “slam” the battery pack into the charging pocket. Damage may result. When preparing the battery pack for insertion into the battery charging pocket, hold the battery with the battery charging contacts in line with the charging contacts in the charging pocket.

  • Page 13: Interpreting The Charging Pocket Leds

    Interpreting the Charging Pocket LEDs The status of the charge operation is indicated by the color of the LED for each charging pocket. RED Continuous - on any charge pocket Continuous red means the battery pack is charging. RED FLASHING - on any charge pocket Battery pack fault or failure.

  • Page 14: Using The Charge/analyze Pocket

    Using the Charge/Analyze Pocket 1. Analyze/Charge Percentage of Original value 2. Analyze Dome switch 3. Analyze/Charge Pocket LED The analyze/charge pocket is the one closest to the HX2 battery charger label and the Analyze dome switch. The analyze/charge pocket can be used to: Charge a standard battery pack in less than four hours.

  • Page 15: Begin Analyzing

    Begin Analyzing Press the Analyze dome switch within 15 seconds of inserting the battery in the Analyze pocket to start the Analyze (Charge – Discharge – Charge) process. If the analyze dome switch is not pressed within 15 seconds, the battery will be charged, but not analyzed. The Analyze progress LEDs indicate the battery capacity as a percent of the original value.

  • Page 16: Battery Charger Help

    The following is intended as an aid in determining whether the battery pack or the charger may be malfunctioning: Problem Cause Solution Check if the HX3 battery pack has Honeywell part number Different manufacturer's battery pack, HX2A301BATTSTD /160289-0001 or Battery pack does not or there is an object in the charging HX2A302BATTEXT/160320-0001 on the label.

  • Page 17

    Problem Cause Solution replacement options. The battery pack voltage has not LED is flashing RED at Contact Technical Assistance for battery pack replacement reached 6.0V within 30 minutes and any pocket. options. the charger has timed out. Remove battery pack from the charging pocket and allow it to adjust to room temperature.

  • Page 18: Charger Cleaning, Storage And Service

    Charger Cleaning, Storage and Service Cleaning Unplug the charger from the power source before cleaning or removing debris from charging pockets. Use only mild detergent with a slightly damp cloth to clean the outside of the charger. Do not use solvents or flammable cleaners.

  • Page 19: Battery Cleaning, Storage And Service

    Battery Cleaning, Storage and Service Cleaning The battery pack should not require cleaning unless it has become heavily soiled. Old or damaged batteries should be disposed of promptly and properly. The best way to dispose of used batteries is to recycle them. Battery recycling facilities recover the Nickel, Lithium or Lead from old batteries to manufacture new batteries.

  • Page 20: Technical Specifications

    Technical Specifications Electrical Note: Battery packs may leak up to 1mA current through the battery contacts when left in an unpowered battery charger charging pocket. Parameter Minimum Maximum Note Power Supply Input Voltage (V AC-IN) 100 VAC 240VAC Auto-switching Power Supply Input Frequency (freq) 47Hz 63Hz Temperature...

  • Page 21: Chapter 2: Set Up A Battery Maintenance Routine

    Chapter 2: Set up a Battery Maintenance Routine Introduction The HX3 uses a standard (2000 mAh) or extended (4000 mAh) battery. Minimum battery life is 500 charge/discharge cycles before replacement. Hand held devices and body worn devices use Lithium Ion (Li-Ion) main battery packs that are lightweight and relatively small.

  • Page 22: Peripheral Devices

    If the peripheral device does not have its own power source, and is designed to draw power from your HX3 battery, be aware that the way you use the peripheral device affects the drain on your battery. Peripheral devices affect your battery life in the following ways: The number of peripheral devices you use affects the drain on your batteries.

  • Page 23: Maintenance Routine

    Maintenance Routine Managing your batteries with a battery maintenance routine is intended to ensure: You get as much battery life as you can. You need fewer batteries per shift. Every shift has fully charged batteries. There is a battery slot on the charger for each battery at the end of every shift. All unused batteries are placed in a charger at the end of every shift.

  • Page 24: A Simple Battery Usage Routine

    A Simple Battery Usage Routine A color coding routine used for a large or small operation that uses the same kind of battery in all mobile devices: 1. Color code all batteries by shift: 1. Shift 1 Blue 2. Shift 2 Red 3.

  • Page 25: Sample Log For Battery Maintenance

    Coin (Backup) Battery Maintenance Mobile Device Serial Number (on exterior label) Placed in Service (Date) Backup Battery Type Nickel-Cadmium (NiCd) Power Source HX3 Main Battery Backup Battery Shift Date Discharged Date Recharged Final Capacity Reading HX3 Main Battery Charger (HX3 Battery Charger)

  • Page 27: Chapter 3: Technical Assistance

    Limited Warranty Honeywell International Inc. ("HII") warrants its products to be free from defects in materials and workmanship and to conform to HII’s published specifications applicable to the products purchased at the time of shipment. This warranty does not cover any HII product which is (i) improperly installed or used;...

  • Page 28

    The duration of the limited warranty for the HX3 Battery Charger is 1 year. The duration of the limited warranty for the HX3 2000mAh Li-Ion and 4000mAh Li-Ion Battery is 6 months. The duration of the limited warranty for the HX3 Ring Scanner and Ring Imager is 1 year.

  • Page 30

    Honeywell Scanning & Mobility 9680 Old Bailes Road Fort Mill, SC 29707 www.honeywellaidc.com E-EQ-HX3CHGROG Rev F 10/12...
