Page 1 Ring Imager / Ring Scanner Bar Code Programming Guide For: ® HX2 with Windows CE 5 Operating System ® HX3 with Windows CE 5 Operating System...
Page 2: Limited Warranty
Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HII.
Page 3: Table Of Contents
Table of Contents Chapter 1 - Introduction Ring Scanners and Ring Imagers Integrated Scanners and Integrated Imagers Tethered and Wireless Scanners Cautions and Warnings Bar Code Readers Return to Factory Default Settings How To Scan a Bar Code Scan a Linear Bar Code Scan a 2D Bar Code Good Read / Bad Read Indicators Factors That May Impact Decode Performance...
Page 4 Set Default Parameter Scanner Parameters – General Aim Duration Bi-Directional Redundancy 2-10 Data Options 2-11 Disable All Symbologies 2-11 Scan Data Transmission Format 2-12 Transmit Code ID Character 2-14 Transmit No Code ID Character 2-14 Transmit Symbol Code ID Character 2-15 Transmit AIM Code ID Character 2-16...
Page 5 Length Within Range 2-44 Any Length 2-44 Code 11 2-45 Set Lengths for Code 11 2-45 One Discrete Length (Parameter L1) 2-46 Two Discrete Lengths (Parameter L2) 2-46 Length Within Range 2-47 Any Length 2-47 Code 11 Check Digit Verification 2-48 Transmit Code 11 Check Digits 2-49...
Page 6 GS1 DataBar Expanded (RSS-Expanded) 2-68 Convert GS1 DataBar (RSS) to UPC/EAN 2-68 Interleaved 2 of 5 2-69 I 2 of 5 Digit Verification 2-70 Convert I 2 of 5 to EAN-13 2-71 Set Lengths for I 2 of 5 2-71 One Discrete Length (Parameter L1) 2-72 Two Discrete Lengths (Parameter L2)
Page 7 Supplementals 2-94 Decode UPC/EAN Supplementals 2-94 User-Programmable Supplementals 2-96 Decode UPC/EAN Supplemental Redundancy 2-97 EAN-8 Zero Extend 2-98 UCC Coupon Extended Code 2-98 UPC/EAN Security Level 2-99 ASCII Character Equivalents 2-101 Appendix 2-105 Laser On Time (superseded) 2-105 Scan Angle (SE955 only) superseded) 2-106 Set Lengths for I 2 of 5 (superseded) 2-107...
Page 8 Transmit No Code ID Character 3-21 Transmit Symbol Code ID Character 3-22 Transmit AIM Code ID Character 3-23 Prefix / Suffix Values 3-27 Prefix 3-27 Suffix 1 3-28 Suffix 2 3-28 Scan Data Transmission Format 3-29 Transmit “No Read” Message 3-31 UPC/EAN 3-32...
Page 9 Any Length 3-55 Code 39 Check Digit Verification 3-56 Transmit Code 39 Check Digit 3-57 Code 39 Full ASCII Conversion 3-58 Code 93 3-59 Set Lengths for Code 93 3-59 One Discrete Length (Parameter L1) 3-60 Two Discrete Lengths (Parameter L2) 3-60 Length Within Range 3-61...
Page 10 Any Length 3-79 3-80 Set Length(s) for MSI 3-80 One Discrete Length (Parameter L1) 3-81 Two Discrete Lengths (Parameter L2) 3-81 Length Within Range 3-82 Any Length 3-82 MSI Check Digits 3-83 Transmit MSI Check Digit 3-84 MSI Check Digit Algorithm 3-85 Postal Codes 3-86...
Page 11 MicroQR 3-103 QR Code 3-104 QR Inverse 3-104 Redundancy Level 3-105 Security Level 3-107 Intercharacter Gap Size 3-109 Imager Keypad Number Symbols 3-110 Chapter 4 - Decode Zones Ring Laser Ring Imager PL4407 Near Focus Decode Distances PL4407 Far Focus Decode Distances PL4407 Toggled Focus Decode Distances PL4407 Decode Distances in Darkness Chapter 5 - Technical Assistance...
Page 13: Chapter 1 - Introduction
Module, HX2 and HX3 use only one ring scanner or ring imager at a time. The HX2 and HX3 are usually worn on the arm or at the waist. The HX2 and HX3 will beep twice when a configuration bar code is successfully scanned.
Page 14: Cautions And Warnings
Cautions and Warnings It is good practice to avoid looking into the beam emitted by any scan beam aperture. Do not connect the beam aperture to any other device, for example, a beam magnifier. Class 2 laser scanners use a low power, visible light diode. As with any very bright light source, such as the sun, the user should avoid staring directly into the light beam.
Page 15: How To Scan A Bar Code
The linear bar codes in this guide were created using Code 128 symbology. Your Ring Decoder has been set up by Honeywell to automatically read / decode Code 128 bar codes.
Page 16: Scan A 2D Bar Code
Scan a 2D Bar Code To scan a bar code with the imager, point the beam aperture at a bar code and press the Scan button. You will see a bracketed cross-hair strike the bar code. Holding the beam aperture approximately 3 – 12 inches away from the bar code, aim the imager aperture toward the selected bar code.
Page 17: Factors That May Impact Decode Performance
Code 39. The use of Code 128 or other more complex symbologies will almost always result in a reduction in maximum read distance. Honeywell will not support bar code reader maximum distances (from Decode Zones) when symbologies other than Code 39 are used.
Page 18: Bar Code Help
acquired. Some bar code reader engines contain protection circuitry that shuts the bar code reader down in temperatures that exceed the recommended operating temperature. Bar Code Help Whether there are beeps in conjunction with scan and decode functions is dependent on the application currently running in the Ring Decoder.
Page 19: Miscellaneous Programmable Bar Codes
Ring decoding devices do not have the ability to emit a good read or bad read sound. Beep After Good Decode Audible scan progress indicators are generated by the bar code reader driver on Honeywell mobile devices, not the bar code reader engine. Use Windows Control Panel options to set up the mobile device audible indicators.
Page 20: Cleaning The Beam Aperture
Cleaning the Beam Aperture Note: New devices -- Remove the shipping film from the beam aperture before first use. Keep fingers and rough, sharp or abrasive objects away from the beam aperture. If the aperture becomes soiled or smudged, clean only with a standard household cleaner such as Windex® without vinegar or use Isopropyl Alcohol.
Page 21: Chapter 2 - Symbol Laser Scanner
Scan engine manufacturers may offer more bar codes and options than are contained in this section. Please note that the bar codes in this section are only those supported by Honeywell and the mobile devices it manufactures or supports. If you need...
Page 22: Aiming Modes
Decoding algorithms released by the bar code engine manufacturer often change upon each new release. Programming parameters that were available at one release may not be available upon a later software release. Honeywell supports the programming bar codes for the specific bar code reader engines in this guide only. SE955 Scan Engine...
Page 23: Pre-Configured Default Values
Pre-Configured Default Values SE 955 Parameter Default Set Default Parameter All Defaults Scanning Options Aim Duration 0.0 sec Aiming Mode Not Supported Beeper Volume Not Supported Bi-directional Redundancy Disable Laser On Time 3.0 sec. Linear Code Type Security Levels Parameter Pass Through Disable Parameter Scanning Enable...
Page 24 SE 955 Parameter Default Transmit UPC-E1 Check Digit Enable UPC-A Preamble System Character UPC-E Preamble System Character UPC-E1 Preamble System Character Convert UPC-E to A Disable Convert UPC-E1 to A Disable EAN-8 Zero Extend Disable Convert EAN-8 to EAN-13 Type Type is EAN-13 UPC/EAN Security Level UCC Coupon Extended Code...
Page 25 SE 955 Parameter Default Code 11 Disable Set Lengths for Code 11 Length within Range: 04 – 55 Code 11 Check Digit Verification Disable Transmit Code 11 Check Digit(s) Disable Interleaved 2 of 5 Interleaved 2 of 5 Enable Set Length(s) for I 2 of 5 I 2 of 5 Check Digit Verification Disable Transmit I 2 of 5 Check Digit...
Page 26 SE 955 Parameter Default GS1 DataBar Expanded (RSS Expanded) Disable Convert GS1 DataBar (RSS) to UPC/EAN Disable Composite CC-C Not Supported CC-AB Not Supported TLC-39 Not Supported Data Options Transmit Code ID Character None Prefix/Suffix Values Prefix NULL Suffix 1 Suffix 2 Scan Data Transmission Format Data as is...
Page 27 SE 955 Parameter Default Transmit Time Stamp Not Supported Transmit Sender Not Supported Transmit Addressee Not Supported Transmit Checksum Not Supported Transmit File Size Not Supported Transmit Macro PDF Control Header Not Supported Last Block Marker Not Supported Flush Macro Buffer Not Supported Abort Macro PDF Entry Not Supported...
Page 28: Set Default Parameter
Set Default Parameter Bar Code Decoder Engine SE955 If custom defaults were set by scanning Write Custom Defaults, scan Restore Defaults to Restore Defaults retrieve and restore the bar code reader’s custom default settings. If no custom defaults were set, scan Restore Defaults to restore the factory default values. Set Factory Defaults Restore the factory default values.
Page 29: Scanner Parameters - General
Scanner Parameters – General Aim Duration Bar Code Decoder Engine SE955 Note: For correct operation, reboot the mobile device after changing this value. When a bar code reader with an aim mode is triggered either by a Scan button press, or a Start_Decode command, this parameter sets the duration the aiming pattern is seen before a scan attempt begins.
Page 30: Bi-Directional Redundancy
Bi-Directional Redundancy Bar Code Decoder Engine SE955 Use this parameter to decide whether a bar code is successfully scanned in both directions before being decoded. Note: This parameter is only valid when a Linear Code Type Security Level has been enabled. The default for Security Level parameter is Level 1.
Page 31: Data Options
Data Options Note: SE955 ring bar code reader engine prefix and suffix parameters cannot be set, changed, or reset using the bar codes in this section. See previous section titled Prefix / Suffix. Disable All Symbologies Bar Code Decoder Engine SE955 Scan the bar code below to disable the decoding of all symbologies.
Page 32: Scan Data Transmission Format
Scan Data Transmission Format Bar Code Decoder Engine SE955 Use this option when you want to append a prefix and suffix to the decode data. Set this parameter by scanning one of the following bar codes. Note: Parameter “Prefix/Suffix Values” should be set after setting this parameter. * Data As Is [Data] [Suffix 1] [Data] [Suffix 2]...
Page 33 [Prefix] [Data] [Suffix 1] [Prefix] [Data] [Suffix 2] [Prefix] [Data] [Suffix 1] [Suffix 2] Now you are ready to scan one of the “Prefix/Suffix Values” bar codes. 2-13...
Page 34: Transmit Code Id Character
Transmit Code ID Character Bar Code Decoder Engine SE955 A code ID character identifies the code type of a scanned bar code. This may be useful when the bar code reader is decoding more than one code type. In addition to any single character prefix already selected, the code ID character is inserted between the prefix and the decoded symbol.
Page 35: Transmit Symbol Code Id Character
Transmit Symbol Code ID Character UPC-A, UPC-E, UPC-E1, EAN-8, EAN-13 Code 39, Code 32 Codabar Code 128 Code 93 Interleaved 2 of 5 Discrete 2 of 5 or Discrete 2 of 5 IATA Code 11 MSI Plessey UCC/EAN-128 Bookland EAN Trioptic Code 39 Coupon Code GS1 DataBar Omnidirectional (RSS-14),...
Page 36: Transmit Aim Code Id Character
Transmit AIM Code ID Character Each AIM Code Identifier contains the three character string ]cm where: ]= Flag Character (ASCII 93) c= Code Character Code 39 Code 128 UPC/EAN Codabar Code 93 Code 11 Interleaved 2 of 5 MSI Plessey D2 of 5, IATA 2 of 5 Code 39 Trioptic, Bookland EAN GS1 DataBar (RSS)
Page 37 Option Code Type Option Value Trioptic Code 39 No option specified at this time. Always transmit 0. Example:A Trioptic bar code 412356 is transmitted as ]X0412356 Code 128 Standard data packet, No Function code 1 in first symbol position. Function code 1 in first symbol character position. Function code 1 in second symbol character position.
Page 38 Option Code Type Option Value Standard packet in full EAN country code format, which is 13 digits for UPC-A and UPC-E (not including supplemental data). Two digit supplement data only Five digit supplement data only EAN-8 data packet. Example: A UPC-A bar code 012345678905 is transmitted as ]E00012345678905 Bookland EAN No options specified at this time.
Page 39: Laser On Time
Laser On Time Bar Code Decoder Engine SE955 Note: For correct operation, reboot the Ring Decoder after changing this value. This parameter sets the maximum time decode processing continues during a scan attempt. It is programmable in 0.1 second increments from 0.50 to 25.5 seconds. If a label has not been decoded before this time expires and the session is terminated, the system regards it as a failed scan attempt.
Page 40: Linear Code Type Security Level (Redundancy Level)
Linear Code Type Security Level (Redundancy Level) Bar Code Decoder Engine SE955 Use this parameter to determine the security level appropriate for bar code quality. The security level indicates how many times the bar code must be successfully read by the bar code reader before being decoded. There are four security levels.
Page 41 Select an option by scanning one of the bar codes shown below. If you wish to change your selection, scan Cancel. Note: Linear Code Type Security does not apply to Code 128. * Level 1 Level 2 Level 3 Level 4 2-21...
Page 42: Parameter Pass Through
Parameter Pass Through Bar Code Decoder Engine SE955 Enable Parameter Pass Through to transmit bar codes in the following format, in Code 128, to the host: <FNC3>L<any length data> <FNC3>B<12 characters of data> Note that the special Code 128 character <FNC3> must appear at the beginning of this data. However, if the appropriate data does not follow this as shown above, it does not transmit to the host device.
Page 43: Parameter Scanning
Parameter Scanning Bar Code Decoder Engine SE955 Use this parameter to decide whether bar code reader parameters can be set using the bar codes in this section. Note: When this parameter is disabled, scan the Set Defaults parameter bar code to enable parameter scanning. When disabled, either scan the Enable Parameter Scanning bar code or the Set All Defaults bar code (or set this parameter to 01h via a serial command) to reset the parameter and bar codes in this section can then be scanned.
Page 44: Power Mode
SE955 Note: Honeywell mobile devices are designed to be operated in Low Power Mode. Honeywell recommends leaving this value unchanged. A parameter setting of Continuous On means the laser bar code reader will not power down until the mobile device is powered off.
Page 45: Simple Serial Interface (Ssi) Options
Simple Serial Interface (SSI) Options Bar Code Decoder Engine SE955 The SSI Options bar codes are directed toward the host programmer when writing host/bar code reader interface programs for different hosts. For help seeTechnical Assistance. Note: Baud Rate Parameter must remain at 9600 bps at all times. SSI Default Values Bar Code Decoder Engine SE955...
Page 46: Baud Rate
Baud Rate Bar Code Decoder Engine SE955 Baud rate is the number of bits of data transmitted per second. The bar code readers baud rate setting should match the data rate setting of the host device. If not, data may not reach the host device or may reach it in distorted form. Default = 9600 bps. Baud rate should always be set to 9600.
Page 47: Decode Data Packet Format
Decode Data Packet Format Bar Code Decoder Engine SE955 This parameter selects whether decoded data is transmitted in raw format (unpacketed), or transmitted with the packet format as defined by the serial protocol. If the raw format is chosen, ACK/NAK handshaking is automatically disabled for decode data. Set this parameter by scanning either of the following bar codes.
Page 48: Host Character Time-Out
Host Character Time-out Bar Code Decoder Engine SE955 This parameter determines the maximum time the decoder waits between characters transmitted by the host before discarding the received data and declaring an error. The time-out is set in 0.01 second increments from 0.01 seconds to 0.99 seconds. After scanning the bar code below, scan two numerical bar codes to set the desired time-out.
Page 49: Host Serial Response Time-Out
Host Serial Response Time-out Bar Code Decoder Engine SE955 This parameter determines the maximum time the decoder waits for an ACK or NAK before resending. Also, if the decoder wants to send, and the host has already been granted permission to send, the decoder waits for the designated time-out before declaring an error.
Page 50: Intercharacter Delay
Intercharacter Delay Bar Code Decoder Engine SE955 Select the intercharacter delay option matching host requirements. The intercharacter delay gives the host system time to service its receiver and perform other tasks between characters. The delay period can range from no delay to 99 msec in 1 msec increments. After scanning the bar code below, scan two numerical bar codes to set the delay.
Page 51: Parity
Parity Bar Code Decoder Engine SE955 A parity check bit is the most significant bit of each ASCII coded character. Select the parity type according to host device requirements. The Odd parity bit has a value 0 or 1, based on Odd Parity data, to ensure that an odd number of 1 bits is con- tained in the coded character.
Page 52 Space Parity * No Parity The SSI Options bar codes are directed toward the host programmer when writing host/bar code reader interface programs for different hosts. For help seeTechnical Assistance. 2-32...
Page 53: Software Handshaking
Software Handshaking Bar Code Decoder Engine SE955 The SSI Options bar codes are directed toward the host programmer when writing host/bar code reader interface programs for different hosts. For help seeTechnical Assistance. Default = Enable This parameter offers control of the data transmission process in addition to that offered by hardware handshaking. Hardware handshaking is always enabled and cannot be disabled by the user.
Page 54: Stop Bit Select
Stop Bit Select Bar Code Decoder Engine SE955 The stop bit(s) at the end of each transmitted character marks the end of transmission of one character and prepares the receiving device for the next character in the serial data stream. The number of stop bits selected (one or two) depends on the number the receiving computer is programmed to accommodate.
Page 55: Time-Out Between Decodes, Same Symbol
Time-out Between Decodes, Same Symbol Bar Code Decoder Engine SE955 Use this parameter to prevent the beeper from continuously beeping when a symbol is left in the bar code reader's field of view. Default = 1.0 Second. To begin setting differing symbol timeout values, scan this bar code: Using the "Keypad Number Symbols"...
Page 56: Transmit "No Read / Decode" Message
Transmit “No Read / Decode” Message Bar Code Decoder Engine SE955 Use this parameter to decide whether a message is sent to the host when a bar code symbol does not decode. When enabled, and a symbol does not decode within either: A trigger pull activates the laser and decode processing, the processing continues until a trigger release, or The laser decode processing continues until the Laser On Timeout is reached.
Page 57: Trigger Mode
SE955 Note: Body worn devices with ring bar code readers are designed to be operated in Host Trigger Mode. Honeywell recommends leaving the Trigger Mode default value unchanged for these devices. Use this parameter to determine when the laser is activated and decoding begins, how long the laser remains on and what determines the cessation of the laser scan and decode process.
Page 58 Select a trigger mode by scanning the appropriate bar code. If you wish to change your selection, scan Cancel. Level Pulse Continuous Blinking * Host 2-38...
Page 59: Scan Angle (Se955 Only)
Scan Angle (SE955 only) Bar Code Decoder Engine SE955 Choose one of the options below to set the scan angle to narrow or wide. Once the parameter bar code is scanned, the Scan Angle setting is persistently stored. Select an option by scanning one of the bar codes shown below. Narrow Angle (35°) * Wide Angle See Also: "Scan Angle (SE955 only) superseded)"...
Page 60: Scanner Parameters - Bar Code Type Specific
Scanner Parameters – Bar Code Type Specific Chinese 2 of 5 Bar Code Decoder Engine SE955 When enabled, Chinese 2 of 5 symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the bar codes shown below. Enable Chinese 2 of 5 * Disable Chinese 2 of 5 2-40...
Page 61: Codabar
Codabar Bar Code Decoder Engine SE955 When enabled, Codabar symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the bar codes shown below. Enable Codabar * Disable Codabar CLSI Editing Bar Code Decoder Engine SE955 When enabled, the start and stop characters are stripped from the bar code and a space is inserted after the 1 , and 10 characters of a 14 character Codabar symbol.
Page 62: Notis Editing
NOTIS Editing Bar Code Decoder Engine SE955 When enabled, the start and stop characters are stripped from a decoded Codabar symbol. Set this parameter by scanning either of the bar codes shown below. Enable NOTIS Editing * Disable NOTIS Editing Set Lengths for Codabar Bar Code Decoder Engine SE955...
Page 63: One Discrete Length (Parameter L1)
One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only Codabar symbols containing 14 characters, scan the “Codabar One Discrete Length” bar code and then “1” and “4” bar codes using the “Keypad Number Symbols”.
Page 64: Length Within Range
Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only Codabar symbols containing between 4 and 12 characters, scan the “Codabar Length Within Range” bar code and then “0”, “4”, “1”...
Page 65: Code 11
Code 11 Bar Code Decoder Engine SE955 When enabled, Code 11 symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the bar codes shown below. Enable Code 11 * Disable Code 11 Set Lengths for Code 11 Bar Code Decoder Engine SE955 Lengths for Code 11 may be set for:...
Page 66: One Discrete Length (Parameter L1)
One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only Code 11 symbols containing 14 characters, scan the “Code 11 One Discrete Length” bar code and then “1” and “4” bar codes using the “Keypad Number Symbols”.
Page 67: Length Within Range
Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only Code 11 symbols containing between 4 and 12 characters, scan the “Code 11 Length Within Range” bar code and then “0”, “4”, “1”...
Page 68: Code 11 Check Digit Verification
Code 11 Check Digit Verification Bar Code Decoder Engine SE955 When enabled, this parameter checks the integrity of a Code 11 symbol to ensure it complies with the specified check digit algorithm. Note: Enable “Code 11 Check Digit Verification” when “Transmit Code 11 Check Digits”...
Page 69: Transmit Code 11 Check Digits
Transmit Code 11 Check Digits Bar Code Decoder Engine SE955 Note: Code 11 Check Digit Verification must be enabled for this parameter to function. Transmit (Enable) * Do Not Transmit (Disable) 2-49...
Page 70: Code 128
Code 128 Bar Code Decoder Engine SE955 Set this parameter by scanning either of the bar codes shown below. * Enable Code 128 Disable Code 128 2-50...
Page 71: Gs1-128 (Formerly Ucc/Ean-128)
GS1-128 (formerly UCC/EAN-128) Bar Code Decoder Engine SE955 Set this parameter by scanning either of the bar codes shown below. * Enable GS1-128 Disable GS1-128 GS1-128 is a convention for printing data fields with standard Code 128 bar code symbols. GS1-128 symbols are distinguished by a leading FNC 1 character as the first or second character in the symbol.
Page 72: Lengths For Code 128
The following table indicates the behavior of the SE955 in each of the four possible parameter settings. Standard Code 128 UCC/EAN 128 Effect and Example Disable Disable No Code 128 symbols can be read. Disable Enable Read only symbols with leading FNC1. Examples: FNC1 FNC1...
Page 73: Code 39
Code 39 Bar Code Decoder Engine SE955 Note: This parameter must be enabled when “Convert Code 39 to Code 32” is to be enabled. Set this parameter by scanning either of the bar codes shown below. * Enable Code 39 Disable Code 39 Code 39 Check Digit Verification Bar Code Decoder Engine...
Page 74: Code 32 Prefix
Code 32 Prefix Bar Code Decoder Engine SE955 This parameter adds the prefix character “A” to all Code 32 bar codes. Note: When enabled, “Convert Code 39 to Code 32” parameter must also be enabled. Set this parameter by scanning either of the bar codes shown below. Enable Code 32 Prefix * Disable Code 32 Prefix 2-54...
Page 75: Convert Code 39 To Code 32
Convert Code 39 to Code 32 Bar Code Decoder Engine SE955 Note: Code 39 must be enabled in order for this parameter to function. Note: When parameter “Code 32 Prefix” is to be enabled, this Convert Code 39 to Code 32 (Italian Pharma Code) parameter must also be enabled.
Page 76: Code 39 Full Ascii Conversion
Code 39 Full ASCII Conversion Bar Code Decoder Engine SE955 Note: Code 39 Full ASCII and Trioptic Code 39 should not be enabled simultaneously. When enabled, the ASCII character set assigns a code to letter, punctuation marks, numerals, and most control keystrokes on the keyboard.
Page 77: Code 39 One Discrete Length (Parameter L1)
Code 39 One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only Code 39 symbols containing 14 characters, scan the “Code 39 One Discrete Length” bar code and then “1” and “4” bar codes using the “Keypad Number Symbols”...
Page 78: Code 39 Length Within Range
Code 39 Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only Code 39 symbols containing between 4 and 12 characters, scan the “Code 39 Length Within Range” bar code and then “0”, “4”, “1”...
Page 79: Transmit Code 39 Check Digit
Transmit Code 39 Check Digit Bar Code Decoder Engine SE955 When enabled, the check digit is transmitted with the data. Parameter setting for “Code 39 Check Digit Verification” has no effect on this parameter value. Set this parameter by scanning either of the bar codes shown below. Enable Transmit Code 39 Check Digit * Disable Transmit 2-59...
Page 80: Trioptic Code 39
Trioptic Code 39 Bar Code Decoder Engine SE955 Trioptic Code 39 symbols always contain six characters. Note: When Trioptic Code 39 is enabled, set the “Code 39 Full ASCII” parameter to disabled. Both parameters should not be enabled simultaneously. Set this parameter by scanning either of the bar codes shown below. Enable Trioptic Code 39 * Disable Trioptic Code 39 2-60...
Page 81: Code 93
Code 93 Bar Code Decoder Engine SE955 When enabled, Code 93 symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the bar codes shown below. Enable Code 93 * Disable Code 93 Set Lengths for Code 93 Bar Code Decoder Engine SE955 Lengths for Code 93 may be set for:...
Page 82: One Discrete Length (Parameter L1)
One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only Code 93 symbols containing 14 characters, scan the “Code 93 One Discrete Length” bar code and then “1” and “4” bar codes using the bar codes on the “Keypad Number Symbols”...
Page 83: Length Within Range
Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only Code 93 symbols containing between 4 and 12 characters, scan the “Code 93 Length Within Range” bar code and then “0”, “4”, “1”...
Page 84: Discrete 2 Of 5
Discrete 2 of 5 Bar Code Decoder Engine SE955 When enabled, Discrete 2 of 5 (D 2 of 5) symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the bar codes shown below. Enable Discrete 2 of 5 * Disable Discrete 2 of 5 Set Lengths for Discrete 2 of 5 Bar Code Decoder Engine...
Page 85: One Discrete Length (Parameter L1)
One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only D 2 of 5 symbols containing 14 characters, scan the “D 2 of 5 One Discrete Length” bar code and then “1” and “4” bar codes using the bar codes on the “Keypad Number Symbols”...
Page 86: Length Within Range
Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only D 2 of 5 symbols containing between 4 and 12 characters, scan the “D 2 of 5 Length Within Range” bar code and then “0”, “4”, “1” and “2”...
Page 87: Gs1 Databar (Rss) Codes
GS1 DataBar (RSS) Codes GS1 DataBar Omnidirectional (RSS-14) Bar Code Decoder Engine SE955 Enable GS1 DataBar Omnidirectional (RSS-14) * Disable GS1 DataBar Omnidirectional (RSS-14) GS1 DataBar Limited (RSS-Limited) Bar Code Decoder Engine SE955 Enable GS1 DataBar Limited (RSS-Limited) * Disable GS1 DataBar Limited (RSS-Limited) 2-67...
Page 88: Gs1 Databar Expanded (Rss-Expanded)
GS1 DataBar Expanded (RSS-Expanded) Bar Code Decoder Engine SE955 Enable GS1 DataBar Expanded (RSS-Expanded) * Disable GS1 DataBar Expanded (RSS-Expanded) Convert GS1 DataBar (RSS) to UPC/EAN Bar Code Decoder Engine SE955 This parameter only applies to GS1 DataBar Omnidirectional (RSS-14) and GS1 DataBar Limited (RSS Limited) symbols. When this conversion is enabled, GS1 DataBar Omnidirectional (RSS-14) and GS1 DataBar Limited (RSS Limited) symbols encoding a single zero as the first digit have the leading ‘010’...
Page 89: Interleaved 2 Of 5
Interleaved 2 of 5 Bar Code Decoder Engine SE955 When enabled, Interleaved 2 of 5 (I 2 of 5) symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the bar codes shown below. * Enable Interleaved 2 of 5 Disable Interleaved 2 of 5 2-69...
Page 90: I 2 Of 5 Digit Verification
I 2 of 5 Digit Verification Bar Code Decoder Engine SE955 When enabled, this parameter checks the integrity of an I 2 of 5 symbol to ensure it complies with a specified algorithm, either USS (Uniform Symbology Specification) or OPCC (Optical Product Code Council). Set this parameter by scanning one of the bar codes shown below.
Page 91: Convert I 2 Of 5 To Ean-13
Convert I 2 of 5 to EAN-13 Bar Code Decoder Engine SE955 A successful bar code conversion requires the following to be true: Interleaved 2 of 5 scanning is enabled. One of the I 2 of 5 lengths is set to 14. The bar code has a leading zero.
Page 92: One Discrete Length (Parameter L1)
One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to decode I 2 of 5 symbols containing only 14 characters, scan the “I 2 of 5 One Discrete Length” bar code and then the “1” and “4” bar codes using the “Keypad Number Symbols”.
Page 93: Length Within Range
Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only I 2 of 5 symbols containing between 4 and 12 characters, scan the “I 2 of 5 Length Within Range” bar code and then “0”, “4”, “1” and “2”...
Page 94: Transmit I 2 Of 5 Check Digit
Transmit I 2 of 5 Check Digit Bar Code Decoder Engine SE955 When enabled, the check digit is transmitted with the data. Parameter setting for “I 2 of 5 Check Digit Verification” has no effect on this parameter value. Set this parameter by scanning either of the bar codes shown below. Enable Transmit I 2 of 5 Check Digit * Disable Transmit I 2 of 5 Check Digit 2-74...
Page 95: Msi Plessey
MSI Plessey Bar Code Decoder Engine SE955 When enabled, MSI Plessey symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the bar codes shown below. Enable MSI Plessey * Disable MSI Plessey MSI Plessey Check Digit Algorithm Bar Code Decoder Engine SE955 When the...
Page 96: Msi Plessey Check Digits
MSI Plessey Check Digits Bar Code Decoder Engine SE955 Check digits placed at the end of the MSI Plessey bar code verify the integrity of the data. At least one check digit is always required. Check digits are not automatically transmitted with the data. Note: When Two Check Digits is selected, an “MSI Plessey Check Digit...
Page 97: One Discrete Length (Parameter L1)
One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only MSI Plessey symbols containing 14 characters, scan the “MSI Plessey One Discrete Length” bar code and then “1” and “4” bar codes using “Keypad Number Symbols”.
Page 98: Length Within Range
Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only MSI Plessey symbols containing between 4 and 12 characters, scan the “MSI Plessey Length Within Range” bar code and then “0”, “4”, “1”...
Page 99: Transmit Msi Plessey Check Digit
Transmit MSI Plessey Check Digit Bar Code Decoder Engine SE955 When enabled, the check digit is transmitted with the data. Set this parameter by scanning either of the bar codes shown below. Enable Transmit MSI Plessey Check Digit * Disable Transmit MSI Plessey Check Digit 2-79...
Page 100: Upc/Ean
UPC/EAN UPC-A Bar Code Decoder Engine SE955 Select an option by scanning either of the bar codes shown below. * Enable UPC-A Disable UPC-A 2-80...
Page 101: Upc-E
UPC-E Bar Code Decoder Engine SE955 Select an option by scanning either of the bar codes shown below. * Enable Disable 2-81...
Page 102: Upc-E1
UPC-E1 Bar Code Decoder Engine SE955 Select an option by scanning either of the bar codes shown below. Enable UPC-E1 * Disable UPC-E1 2-82...
Page 103 EAN-8 Bar Code Decoder Engine SE955 Select an option by scanning either of the bar codes shown below. * Enable EAN-8 Disable EAN-8 2-83...
Page 104 EAN-13 Bar Code Decoder Engine SE955 Select an option by scanning either of the bar codes shown below. * Enable EAN-13 Disable EAN-13 2-84...
Page 105: Bookland Ean
Bookland EAN Bar Code Decoder Engine SE955 Select an option by scanning either of the bar codes shown below. Enable Bookland EAN * Disable Bookland EAN 2-85...
Page 106: Bookland Isbn Format
Bookland ISBN Format Bar Code Decoder Engine SE955 Select one of the following formats for Bookland data when Bookland EAN is enabled. Bookland ISBN-10 - The bar code reader reports Bookland data starting with 978 in traditional 10-digit format with the special Bookland check digit for backward-compatibility.
Page 107: Check Digits
Check Digits Bar Code Decoder Engine SE955 Transmit UPC-A Check Digit This parameter determines whether the symbol will be transmitted with or without the UPC-A check digit. Select an option by scanning either of the bar codes shown below. * Enable Transmit UPC-A Check Digit Disable Transmit UPC-A Check Digit Transmit UPC-E Check Digit This parameter determines whether the symbol will be transmitted with or without the UPC-E check digit.
Page 108: Transmit Upc-E1 Check Digit
Transmit UPC-E1 Check Digit This parameter determines whether the symbol will be transmitted with or without the UPC-E1 check digit. Select an option by scanning either of the bar codes shown below. * Enable Transmit UPC-E1 Check Digit Disable Transmit UPC-E1 Check Digit 2-88...
Page 109: Conversions
Conversions Bar Code Decoder Engine SE955 Convert UPC-E to UPC-A When this parameter is enabled, UPC-E (zero suppressed) decoded data is converted to UPC-A format before transmission. After conversion, data follows UPC-A format and is affected by UPC-A programming selections (e.g., Preamble, Check Digit, etc.).
Page 110: Convert Upc-E1 To Upc-A
Convert UPC-E1 to UPC-A When this parameter is enabled, UPC-E1 (zero suppressed) decoded data is converted to UPC-A format before transmission. After conversion, data follows UPC-A format and is affected by UPC-A programming selections (e.g., Preamble, Check Digit, etc.). When disabled, UPC-E1 (zero suppressed) decoded data is transmitted without conversion. Select an option by scanning either of the bar codes shown below.
Page 111: Preambles
Preambles Bar Code Decoder Engine SE955 UPC-A Preamble A preamble is a lead-in character for UPC-A symbols transmitted to the host device. The lead-in characters are considered part of the symbol. Data is sent to the host in the following format: No Preamble [data] System Character...
Page 112: Upc-E Preamble
UPC-E Preamble A preamble is a lead-in character for UPC-E symbols transmitted to the host device. The lead-in characters are considered part of the symbol. Data is sent to the host in the following format: No Preamble [data] System Character [schar] [data] System Character and Country [country code] [schar] [data]...
Page 113: Upc-E1 Preamble
UPC-E1 Preamble A preamble is a lead-in character for UPC-E1 symbols transmitted to the host device. The lead-in characters are considered part of the symbol. Data is sent to the host in the following format: No Preamble [data] System Character [schar] [data] System Character and Country [country code] [schar] [data]...
Page 114: Supplementals
Decode UPC/EAN Supplementals Note: In order to minimize the risk of invalid data transmission, Honeywell recommends that you select whether to read or ignore supplemental characters. Supplementals are additionally appended characters (2 or 5) according to specific code format conventions (e.g., UPC-A + 2).
Page 115 Enable 978/979 Supplemental Mode If you select 978/979 Supplemental Mode and are scanning Bookland EAN bar codes, see Enable/Disable Bookland EAN to enable Bookland EAN, and select a format using Bookland ISBN Format. Enable 977 Supplemental Mode Enable 414/419/434/439 Supplemental Mode Enable 491 Supplemental Mode Enable Smart Supplemental Mode Applies to EAN-13 bar codes starting with any prefix listed...
Page 116: User-Programmable Supplementals
Supplemental User Programmable Type 1 and 2 Smart Supplemental Plus User Programmable 1 Smart Supplemental Plus User Programmable 1 and 2 User-Programmable Supplementals When Supplemental User-Programmable option is selected from Decode UPC/EAN Supplementals, select User- Programmable Supplemental 1 to set the 3-digit prefix. Then select the 3 digits using the “Keypad Number Symbols”.
Page 117: Decode Upc/Ean Supplemental Redundancy
Decode UPC/EAN Supplemental Redundancy With Autodiscriminate UPC/EAN Supplementals selected, this option adjusts the number of times a symbol without supplementals will be decoded before transmission. The range is from 2 to 20 times. Five or above is recommended when decoding a mix of UPC/EAN symbols with and without supplementals, and the autodiscriminate option is selected. Default = 7 Times.
Page 118: Ean-8 Zero Extend
EAN-8 Zero Extend Bar Code Decoder Engine SE955 When this parameter is enabled, five leading zeros are added to decoded EAN-8 symbols to make them compatible in format to EAN-13 symbols. Use parameter “Convert EAN-8 to EAN-13 Type” to label the extended symbol. When disabled, EAN-8 symbols are transmitted as is and parameter “Convert EAN-8 to EAN-13 Type”...
Page 119: Upc/Ean Security Level
UPC/EAN Security Level Bar Code Decoder Engine SE955 Use this parameter to determine the security level appropriate for UPC/EAN bar code quality. There is an inverse relationship between security and bar code reader aggressiveness, so be sure to choose only that level of security necessary for any given application.
Page 120 Select an option by scanning one of the bar codes shown below. If you wish to change your selection, scan Cancel. * Level 0 Level 1 Level 2 Level 3 2-100...
Page 121: Ascii Character Equivalents
ASCII Character Equivalents Values from 1128 through 1255 (hex values 80h through FFh) may also be set. But the conversion of those characters to printable characters is not standardized. Therefore, they are not included in the table. Full ASCII Code 39 Scan Value Hex Value Keystroke...
Page 122 Full ASCII Code 39 Scan Value Hex Value Keystroke ASCII Character Encode Char. 1032 Space Space Space 1033 1034 " " 1035 1036 1037 1038 & & 1039 ’ 1040 1041 1042 1043 1044 1045 1046 1047 1048 1049 1050 1051 1052 1053...
Page 123 Full ASCII Code 39 Scan Value Hex Value Keystroke ASCII Character Encode Char. 1068 1069 1070 1071 1072 1073 1074 1075 1076 1077 1078 1079 1080 1081 1082 1083 1084 1085 1086 1087 1088 1089 1090 1091 1092 1093 1094 1095 1096 ‘...
Page 124 Full ASCII Code 39 Scan Value Hex Value Keystroke ASCII Character Encode Char. 1104 1105 1106 1107 1108 1109 1110 1111 1112 1113 1114 1115 1116 1117 1118 1119 1120 1121 1122 1123 1124 1125 1126 1127 Undefined Undefined 2-104...
Page 125: Appendix
Appendix This appendix contains information that is superseded by newer information. It contains programming bar codes for Symbol SE955 scan engines only. Laser On Time (superseded) Bar Code Decoder Engine SE955 For correct operation, reboot the Ring Decoder after changing this value. Note: The bar code on this page has been replaced with a newer bar code.
Page 126: Scan Angle (Se955 Only) Superseded)
Scan Angle (SE955 only) superseded) Bar Code Decoder Engine SE955 Note: The bar code on this page has been replaced with a newer bar code. See Also: "Scan Angle (SE955 only)". Choose one of the options below to set the scan angle to narrow or wide. Once the parameter bar code is scanned, the Scan Angle setting is persistently stored.
Page 127: Set Lengths For I 2 Of 5 (Superseded)
Set Lengths for I 2 of 5 (superseded) Bar Code Decoder Engine SE955 Note: The bar codes on this page have been replaced with newer bar codes. See Also: "Set Lengths for I 2 of 5". Lengths for I 2 of 5 may be set for: any length, one or two discrete lengths, or lengths within a specific range.
Page 128: Length Within Range
Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only I 2 of 5 symbols containing between 4 and 12 characters, scan the “I 2 of 5 Length Within Range” bar code and then “0”, “4”, “1” and “2”...
Page 129: Keypad Number Symbols
Keypad Number Symbols The bar code labels shown below represent a numeric keypad, with decimal values 0 through 9. Each label can be scanned individually to enter a numeric value. Use these numeric value symbols to enter numeric input in the course of performing a scan engine system configuration.
Page 130 Cancel 2-110...
Page 131: Chapter 3 - Symbol Imagers
An asterisk (*) next to an option indicates the default setting. The HX2 and HX3 will beep twice when a configuration bar code is successfully scanned.
Page 132: Prefix / Suffix
Use the scan wedge control panel in the host computer to set prefix and suffix values. The prefix and suffix bar codes are present in this section as a courtesy to Honeywell customers. Refer to Start > Settings > Control Panel > Scanner in the Body Worn device's Reference Guide for information and...
Page 133: Pre-Configured Default Values
Pre-Configured Default Values Parameter Default Value Set Default Parameter All Defaults Parameter Scanning Enable Operational Mode Decode Mode Beep After Good Decode Not Supported Beeper Tone Not Supported Beeper Volume Not Supported Decode Session Timeout 9.9 sec Power Mode PL4407 Low Power Power Mode MS4407...
Page 134 Parameter Default Value Serial Host Parameters Not Supported Symbologies UPC/EAN UPC-A Enable UPC-E Enable UPC-E1 Disable EAN-8/JAN 8 Enable EAN-13/JAN 13 Enable Bookland EAN Disable Decode UPC/EAN/JAN Supplementals (2 and 5 digits) Ignore UPC/EAN/JAN Supplemental Redundancy Transmit UPC-A Check Digit Enable Transmit UPC-E Check Digit Enable...
Page 135 Parameter Default Value Buffer Code 39 Disable Code 93 Code 93 Disable Set Length(s) for Code 93 4 to 55 Code 11 Code 11 Disable Set Lengths for Code 11 4 to 55 Code 11 Check Digit Verification Disable Transmit Code 11 Check Digit(s) Disable Interleaved 2 of 5 (ITF) Interleaved 2 of 5 (ITF)
Page 136 Parameter Default Value Japan Postal Enable Australian Postal Enable Dutch Postal Enable Transmit US Postal Check Digit Enable GS1 DataBar GS1 DataBar 14 Enable GS1 DataBar Limited Enable GS1 DataBar Expanded Enable Convert GS1 DataBar to UPC/EAN Disable Composite Composite CC-C Disable Composite CC-A/B Disable...
Page 137: Set All Defaults / Cancel Bar Codes
Set All Defaults / Cancel Bar Codes Use the Set All Defaults bar code to return all parameters to their default values. Scanning this bar code does not affect the mobile device’s operating system, wireless client or installed software (e.g., AppLock) settings. Note: When the Parameter Scanning...
Page 138: Enable / Disable Parameter Scanning
Enable / Disable Parameter Scanning Use this parameter to decide whether bar code reader parameters can be set using the bar codes in this section. Note: When this parameter is disabled, scan the Set All Defaults parameter bar code to enable parameter scanning. When disabled, either scan the Enable Parameter Scans bar code or the Set All Defaults bar code to reset the parameter.
Page 139: Imager Parameters - General
Imager Parameters – General Except for the General imager attributes in this section that can be set by the end-user, imager programming attributes are set using the Windows scan wedge panel resident on the mobile device. Bar code manipulation parameters assigned using the Windows scan wedge panels are applied to the data resulting from successful bar code scans.
Page 140: Decode Aiming Pattern
Decode Aiming Pattern Note: This parameter only applies when in Decode Mode. See Also: Operational Mode. Scan Enable Decode Aiming Pattern to project the aiming pattern during bar code capture, or Disable Decode Aiming Pattern to turn the aiming pattern off. * Enable Decode Aiming Pattern Disable Decode Aiming Pattern Decoding Autoexposure...
Page 141: Decoding Illumination
Decoding Illumination Note: When this parameter is disabled, any LED Illumination parameter setting is ignored. The decoder has three small bright LEDs situated above the scan aperture. Enable this parameter for LED illumination upon every decode. The effectiveness of the illumination decreases as the distance to the target increases.
Page 142: Focus Mode
Focus Mode Select a focus mode to control the working range of the imager. When Far Focus is selected, the imager is optimized to read at its far position. With Near Focus, the imager is optimized to read at its near position. Smart Focus toggles the focus position after every frame.
Page 143: Led Illumination
LED Illumination Note: This parameter only applies for decoding if Decoding Illumination is enabled. If Decoding Illumination is disabled, all illumination is off for that mode, regardless of this LED Illumination setting. Default = PL4407: Internal Illumination MS4407: External Illumination The imager has three small bright LEDs situated above the scan aperture.
Page 144: Operational Mode
Operational Mode In Decode Mode (the default mode), and upon a Scan button event, the imager attempts to locate and decode enabled bar codes within its field of view. The decoder remains in this mode as long as the Scan button is pressed or until a bar code is decoded. Note: A Decode Mode bar code is not available.
Page 145: Power Mode
Power Mode Note: Honeywell mobile devices are designed to be operated in Low Power Mode. Honeywell recommends leaving this value unchanged. Default = PL4407: Low Power MS4407: Continuous On A parameter setting of Continuous On means the laser will not power down until the mobile device is powered off.
Page 146: Presentation Mode Session Timeout
Presentation Mode Session Timeout This parameter, and the Presentation Mode parameter, are directed toward ring decoders that can scan a bar code that enters its field of view, determine a good read/bad read, then scan again. This parameter determines how long the ring decoder will attempt to decode a bar code before determining if it is a good read or a bad read.
Page 147: Time Delay To Low Power Mode
Time Delay to Low Power Mode This parameter sets the time the decoder remains active after decoding. The decoder wakes upon a Scan button press or when the host attempts to communicate with the decoder. This parameter only applies when Power Mode is set to Low Power.
Page 148: Time-Out Between Decodes, Same Symbol
60 Minute Delay Time-out between Decodes, Same Symbol This option is used in presentation mode to prevent multiple reads of a symbol left in the ring decoder’s field of view. The timeout begins when the bar code is removed from the field of view. It is programmable in 0.1 second increments from 0.0 to 9.9 seconds.
Page 149: Trigger Modes
Trigger Modes Note: Honeywell mobile devices with ring bar code readers are designed to be operated in Level Trigger Mode. Honeywell recommends leaving the Trigger Mode default value unchanged. Default PL4407 = Level Trigger Mode MS4407 = Presentation Mode Use this parameter to determine when the laser is activated and decoding begins, how long the laser remains on and what determines the cessation of the laser scan and decode process.
Page 150: Report Version
Report Version Scan the following bar code to view the version of software currently installed in the ring decoder. The result will be displayed on the host device display. 3-20...
Page 151: Transmit Code Id Character
Transmit Code ID Character A code ID character identifies the code type of a scanned bar code. This may be useful when the imager is decoding more than one code type. In addition to any single character prefix already selected, the code ID character is inserted between the prefix and the decoded symbol.
Page 152: Transmit Symbol Code Id Character
Transmit Symbol Code ID Character UPC-A, UPC-E, UPC-E1, EAN-8, EAN-13 Code 39, Code 32 Codabar Code 128 Code 93 Interleaved 2 of 5 Discrete 2 of 5 or Discrete 2 of 5 IATA Code 11 MSI Plessey UCC/EAN-128 Bookland EAN Trioptic Code 39 Coupon Code GS1 DataBar-14, GS1 DataBar-Limited, GS1 DataBar-Expanded...
Page 153: Transmit Aim Code Id Character
Transmit AIM Code ID Character Each AIM Code Identifier contains the three character string ]cm where: ]= Flag Character (ASCII 93) c= Code Character Code 39, Code 39 Full ASCII, Code 32 Code 128, Coupon (Code 128 portion) Data Matrix UPC/EAN, Coupon (UPC portion) GS1 DataBar Family Codabar...
Page 154 The modifier character is the sum of the applicable option values based on the following table. Code Option Option Type Value Code39 No Check character or Full ASCII processing. Reader has checked one check character. Reader has checked and stripped check character. Reader has performed Full ASCII character conversion.
Page 155 Code Option Option Type Value Two digit supplement data only Five digit supplement data only Combined data packet comprising 13 digits from a UPC-A, UPC-E, or EAN-13 symbol and 2 or 5 digits from a supplemental symbol. EAN-8 data packet. Example:A UPC-A bar code 012345678905 is transmitted as ]E00012345678905 Bookland EAN No options specified at this time.
Page 156 Code Option Option Type Value ECC 000-140, not supported. ECC 200. ECC 200, FNC1 in first or fifth position. ECC 200, FNC1 in second or sixth position. ECC 200, ECI protocol implemented. ECC 200, FNC1 in first or fifth position, ECI protocol implemented. ECC 200, FNC1 in second or sixth position, ECI protocol implemented.
Page 157: Prefix / Suffix Values
Prefix / Suffix Values SE4400 imager engine prefix and suffix parameters cannot be set, changed, or reset using the bar codes in this section. See previous section titled Prefix / Suffix for an explanation. Prefix (P) Parameter Default = Null Suffix1 (S1) Parameter Default = LF Suffix2 (S2) Parameter Default = CR Note:...
Page 158: Suffix 1
Suffix 1 To begin setting Suffix 1 value, scan this Scan Suffix 1 bar code: Next, scan four numeric bar codes that correspond to the computer keycode using the “Imager Keypad Number Symbols”. If you wish to change your selection, scan Cancel on the “Imager Keypad Number Symbols” page. Suffix 2 To begin setting Suffix 2 value, scan this Scan Suffix 2 bar code: Next, scan four numeric bar codes that correspond to the computer keycode using the...
Page 159: Scan Data Transmission Format
Scan Data Transmission Format Note: Parameter "Prefix/Suffix Values" for SSI hosts should be set after setting this parameter. Use this option when you want to append a prefix and suffix to the SSI host decode data. If you wish to change your selection, scan the Cancel bar code and scan again. Set the Scan Data Transmission Format parameter by scanning one of the following bar codes: * Data As Is [Data] [Suffix 1]...
Page 160 [Prefix] [Data] [Suffix 1] [Prefix] [Data] [Suffix 2] [Prefix] [Data] [Suffix 1] [Suffix 2] Now you are ready to scan one of the “Prefix/Suffix Values” bar codes. 3-30...
Page 161: Transmit "No Read" Message
Transmit “No Read” Message Scan a bar code below to select whether or not to transmit a No Read message. When enabled, the characters NR are transmitted when a bar code is not decoded. When disabled, if a symbol does not decode, nothing is sent to the host.
Page 162: Upc/Ean
UPC/EAN UPC-A Select an option by scanning either of the bar codes shown below. * Enable UPC-A Disable UPC-A UPC-E Select an option by scanning either of the bar codes shown below. * Enable UPC-E Disable UPC-E 3-32...
Page 163: Upc-E1
UPC-E1 Select an option by scanning either of the bar codes shown below. Enable UPC-E1 * Disable UPC-E1 Note: UPC-E1 is not a UCC (Uniform Code Council) approved symbology. 3-33...
Page 164: Ean-8/Jan-8
EAN-8/JAN-8 Select an option by scanning either of the bar codes shown below. * Enable EAN-8/JAN-8 Disable EAN-8/JAN-8 3-34...
Page 165: Ean-13/Jan-13
EAN-13/JAN-13 Select an option by scanning either of the bar codes shown below. * Enable EAN-13/JAN-13 Disable EAN-13/JAN-13 Bookland EAN Select an option by scanning either of the bar codes shown below. Enable Bookland EAN * Disable Bookland EAN If you enable Bookland EAN, select a Bookland ISBN Format.
Page 166: Bookland Isbn Format
Bookland ISBN Format If Bookland EAN is enabled using Enable/Disable Bookland EAN, select one of the following formats for Bookland data: Bookland ISBN-10 - The bar code reader reports Bookland data starting with 978 in traditional 10-digit format with the special Bookland check digit for backward-compatibility.
Page 167: Decode Upc/Ean/Jan Supplementals (2 And 5 Digits)
Note: In order to minimize the risk of invalid data transmission, Honeywell recommends selecting whether to read or ignore supplemental characters. Select an option by scanning one of the bar codes shown below. If you wish to change your selection, scan the Cancel bar code and scan again.
Page 168 Autodiscriminate UPC/EAN/JAN Supplementals Enable 378/379 Supplemental Mode Enable 978 Supplemental Mode Enable Smart Supplemental Mode 3-38...
Page 169: Upc/Ean/Jan Supplemental Redundancy
UPC/EAN/JAN Supplemental Redundancy With Autodiscriminate UPC/EAN Supplementals selected, this option adjusts the number of times a symbol without supplementals is decoded before transmission. The range is from 2 to 30 times. Five or above is recommended when decoding a mix of UPC/EAN/JAN symbols with and without supplementals, and the autodiscriminate option is selected. Default = 10 Times.
Page 170: Transmit Upc-A Check Digit
Transmit UPC-A Check Digit This parameter determines whether the symbol will be transmitted with or without the UPC-A check digit. Select an option by scanning either of the bar codes shown below. * Enable Transmit UPC-A Check Digit Disable Transmit UPC-A Check Digit 3-40...
Page 171: Transmit Upc-E Check Digit
Transmit UPC-E Check Digit This parameter determines whether the symbol will be transmitted with or without the UPC-E check digit. Select an option by scanning either of the bar codes shown below. * Enable Transmit UPC-E Check Digit Disable Transmit UPC-E Check Digit 3-41...
Page 172: Transmit Upc-E1 Check Digit
Transmit UPC-E1 Check Digit This parameter determines whether the symbol will be transmitted with or without the UPC-E1 check digit. Select an option by scanning either of the bar codes shown below. * Enable Transmit UPC-E1 Check Digit Disable Transmit UPC-E1 Check Digit 3-42...
Page 173: Upc-A Preamble
UPC-A Preamble A preamble is a lead-in character for UPC-A symbols transmitted to the host device. The lead-in characters are considered part of the symbol. Data is sent to the host in the following format: No Preamble [data] System Character [schar] [data] System Character and Country [country code] [schar] [data]...
Page 174: Upc-E Preamble
UPC-E Preamble A preamble is a lead-in character for UPC-E symbols transmitted to the host device. The lead-in characters are considered part of the symbol. Data is sent to the host in the following format: No Preamble [data] System Character [schar] [data] System Character and Country Code [country code] [schar] [data]...
Page 175: Upc-E1 Preamble
UPC-E1 Preamble A preamble is a lead-in character for UPC-E1 symbols transmitted to the host device. The lead-in characters are considered part of the symbol. Data is sent to the host in the following format: No Preamble [data] System Character [schar] [data] System Character and Country Code [country code] [schar] [data]...
Page 176: Convert Upc-E To Upc-A
Convert UPC-E to UPC-A When this parameter is enabled, UPC-E (zero suppressed) decoded data is converted to UPC-A format before transmission. After conversion, data follows UPC-A format and is affected by UPC-A programming selections (e.g., Preamble, Check Digit, etc.). When disabled, UPC-E (zero suppressed) decoded data is transmitted without conversion. Select an option by scanning either of the bar codes shown below.
Page 177: Ean-8/Jan-8 Extend
EAN-8/JAN-8 Extend When this parameter is enabled, five leading zeros are added to decoded EAN-8 symbols to make them compatible in format to EAN-13 symbols. Use parameter “Convert EAN-8 to EAN-13 Type” to label the extended symbol. When disabled, EAN-8 symbols are transmitted as is and parameter “Convert EAN-8 to EAN-13 Type” setting is ignored. Select an option by scanning either of the bar codes shown below.
Page 178: Ucc Coupon Extended Code
UCC Coupon Extended Code Note: UCC Coupon Extended Code replaces UPC/EAN Coupon Code. The UCC Coupon Extended Code is an additional bar code adjacent to a UCC Coupon Code. To enable or disable UCC Coupon Extended Code, scan the appropriate bar code below. When enabled, this parameter decodes UPC-A bar codes starting with digit “5”, EAN-13 bar codes starting with digit “99”...
Page 179: Code 128
Code 128 Set this parameter by scanning either of the bar codes shown below. * Enable Code 128 Disable Code 128 UCC/EAN-128 Set this parameter by scanning either of the bar codes shown below. * Enable UCC/EAN-128 Disable UCC/EAN-128 3-49...
Page 180 ISBT-128 ISBT-128 is a variant of Code 128 used in the blood bank industry. If necessary, the host must perform concatenation of the ISBT data. Set this parameter by scanning either of the bar codes shown below. * Enable ISBT-128 Disable ISBT-128 3-50...
Page 181: Code 39
Code 39 Note: This parameter must be enabled when “Convert Code 39 to Code 32” is to be enabled. Set this parameter by scanning either of the bar codes shown below. * Enable Code 39 Disable Code 39 3-51...
Page 182: Trioptic Code 39
Trioptic Code 39 Trioptic Code 39 symbols always contain six characters. When Trioptic Code 39 is enabled, set the Code 39 Full ASCII parameter to disabled. Both parameters should not be enabled simultaneously. Set this parameter by scanning either of the bar codes shown below. Enable Trioptic Code 39 * Disable Trioptic Code 39 3-52...
Page 183: Convert Code 39 To Code 32
Convert Code 39 to Code 32 Note: Code 39 must be enabled in order for this parameter to function. Note: When parameter Code 32 Prefix is to be enabled, this Convert Code 39 to Code 32 (Italian Pharmacy Code) parameter must also be enabled. Set this parameter by scanning either of the bar codes shown below.
Page 184: Set Length(S) For Code 39
Set Length(s) for Code 39 Lengths for Code 39 may be set for: any length, one or two discrete lengths, or lengths within a specific range. The length of a code refers to the number of characters, including check digits, the code contains. If Code 39 Full ASCII is enabled, Length Within a Range or Any Length are the preferred options.
Page 185: Two Discrete Lengths (Parameter L2)
Two Discrete Lengths (Parameter L2) This option decodes only those codes containing two selected lengths. For example, when you want to scan only Code 39 symbols containing 2 or 14 characters, scan the following bar code and then “0”, “2”, “1” and “4” bar codes using the Imager Keypad Number Symbols.
Page 186: Code 39 Check Digit Verification
Code 39 Check Digit Verification When enabled, this parameter checks the integrity of a Code 39 symbol to ensure it complies with specified check digit algorithms. Only Code 39 symbols which include a Modulo 43 check digit are decoded when this parameter is enabled. Note: When Transmit Code 39 Check Digit...
Page 187: Transmit Code 39 Check Digit
Transmit Code 39 Check Digit When enabled, the check digit is transmitted with the data. Note: Code 39 Check Digit Verification must be enabled for this parameter to function. Set this parameter by scanning either of the bar codes shown below. Enable Transmit Code 39 Check Digit * Disable Transmit Code 39 Check Digit 3-57...
Page 188: Code 39 Full Ascii Conversion
Code 39 Full ASCII Conversion Note: Code 39 Full ASCII and Trioptic Code 39 should not be enabled simultaneously. Code 39 Full ASCII is a variant of Code 39 which pairs characters to encode the full ASCII character set. Set this parameter by scanning either of the bar codes shown below. Enable Code 39 Full ASCII Conversion * Disable Code 39 Full ASCII Conversion When enabled, the ASCII character set assigns a code to letters, punctuation marks, numerals, and most control keystrokes...
Page 189: Code 93
Code 93 Disable Code 93 L1 Parameter Default Value : 4 L2 Parameter Default Value: 55 When enabled, Code 93 symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the bar codes shown below. Enable Code 93 * Disable Code 93 Set Lengths for Code 93 Lengths for Code 93 may be set for:...
Page 190: One Discrete Length (Parameter L1)
One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only Code 93 symbols containing 14 characters, scan the “Code 93 One Discrete Length” bar code and then “1” and “4” bar codes using the “Imager Keypad Number Symbols”.
Page 191: Length Within Range
Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only Code 93 symbols containing between 4 and 12 characters, scan the “Code 93 Length Within Range” bar code and then “0”, “4”, “1”...
Page 192: Code 11
Code 11 When enabled, Code 11 symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the bar codes shown below. Enable Code 11 * Disable Code 11 Set Lengths for Code 11 Lengths for Code 11 may be set for: any length, one or two discrete lengths, or lengths within a specific range.
Page 193: One Discrete Length (Parameter L1)
One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only Code 11 symbols containing 14 characters, scan the “Code 11 One Discrete Length” bar code and then “1” and “4” bar codes using the Imager Keypad Number Symbols.
Page 194: Length Within Range
Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only Code 11 symbols containing between 4 and 12 characters, scan the “Code 11 Length Within Range” bar code and then “0”, “4”, “1”...
Page 195: Code 11 Check Digit Verification
Code 11 Check Digit Verification Enable this parameter by scanning either One Check Digit bar code or Two Check Digits bar code. When enabled, this parameter checks the integrity of a Code 11 symbol to ensure it complies with the specified check digit algorithm.
Page 196: Transmit Code 11 Check Digits
Transmit Code 11 Check Digits Code 11 Check Digit Verification must be enabled for this parameter to function. Transmit (Enable) Code 11 Check Digits * Do Not Transmit (Disable) Code 11 Check Digits Interleaved 2 of 5 (ITF) When enabled, Interleaved 2 of 5 (I 2 of 5) symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the bar codes shown below.
Page 197: Set Lengths For I 2 Of 5
Set Lengths for I 2 of 5 Lengths for Interleaved 2 of 5 may be set for: any length, one or two discrete lengths, or lengths within a specific range. The length of a code refers to the number of characters, including check digits, the code contains. See the table titled “ASCII Character Equivalents”.
Page 198: One Discrete Length (Parameter L1)
One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only I 2 of 5 symbols containing 14 characters, scan the “I 2 of 5 One Discrete Length” bar code and then “1” and “4” bar codes using the “Imager Keypad Number Symbols”.
Page 199: Length Within Range
Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only I 2 of 5 symbols containing between 4 and 12 characters, scan the “I 2 of 5 Length Within Range” bar code and then “0”, “4”, “1” and “2”...
Page 200: I 2 Of 5 Check Digit Verification
I 2 of 5 Check Digit Verification When enabled, this parameter checks the integrity of an I 2 of 5 symbol to ensure it complies with a specified algorithm, either USS (Uniform Symbology Specification) or OPCC (Optical Product Code Council). Set this parameter by scanning one of the bar codes shown below.
Page 201: Transmit I 2 Of 5 Check Digit
Transmit I 2 of 5 Check Digit When enabled, the check digit is transmitted with the data. Parameter setting for “I 2 of 5 Check Digit Verification” has no effect on this parameter value. Set this parameter by scanning either of the bar codes shown below. Enable Transmit I 2 of 5 Check Digit * Disable Transmit I 2 of 5 Check Digit 3-71...
Page 202: Convert I 2 Of 5 To Ean 13
Convert I 2 of 5 to EAN 13 A successful bar code conversion requires the following to be true: Interleaved 2 of 5 scanning is enabled. One of the I 2 of 5 lengths is set to 14. The bar code has a leading zero. The bar code has a valid EAN-13 check digit.
Page 203: Set Lengths For Discrete 2 Of 5
Set Lengths for Discrete 2 of 5 Lengths for D 2 of 5 may be set for: any length, one or two discrete lengths, or lengths within a specific range. The length of a code refers to the number of characters, including check digits, the code contains. Note: Due to the construction of the D2 of 5 symbology, it is possible for a scan line covering only a portion of the code to be interpreted as a complete scan, yielding less data than is encoded in the bar code.
Page 204: One Discrete Length (Parameter L1)
One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. Default = 12. For example, when you want to scan only D 2 of 5 symbols containing 14 characters, scan the “D 2 of 5 One Discrete Length” bar code and then “1”...
Page 205: Length Within Range
Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only D 2 of 5 symbols containing between 4 and 12 characters, scan the “D 2 of 5 Length Within Range” bar code and then “0”, “4”, “1” and “2”...
Page 206: Codabar
Codabar When enabled, Codabar symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the bar codes shown below. Enable Codabar * Disable Codabar CLSI Editing When enabled, the start and stop characters are stripped from the bar code and a space is inserted after the 1 , and 10 characters of a 14 character Codabar symbol.
Page 207: Notis Editing
NOTIS Editing When enabled, the start and stop characters are stripped from a decoded Codabar symbol. Set this parameter by scanning either of the bar codes shown below. Enable NOTIS Editing * Disable NOTIS Editing Set Lengths for Codabar Lengths for Codabar may be set for: any length, one or two discrete lengths, or lengths within a specific range.
Page 208: One Discrete Length (Parameter L1)
One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only Codabar symbols containing 14 characters, scan the Codabar One Discrete Length bar code and then “1” and “4” bar codes using the Imager Keypad Number Symbols .
Page 209: Length Within Range
Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only Codabar symbols containing between 4 and 12 characters, scan the Codabar Length Within Range bar code and then “0”, “4”, “1”...
Page 210: Msi
When enabled, MSI symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the bar codes shown below. Enable MSI * Disable MSI Set Length(s) for MSI Lengths for MSI may be set for: any length, one or two discrete lengths, or lengths within a specific range.
Page 211: One Discrete Length (Parameter L1)
One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only MSI symbols containing 14 characters, scan the “MSI One Discrete Length” bar code and then “1” and “4” bar codes using the “Imager Keypad Number Symbols”.
Page 212: Length Within Range
Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only MSI symbols containing between 4 and 12 characters, scan the “MSI Length Within Range” bar code and then “0”, “4”, “1” and “2”...
Page 213: Msi Check Digits
MSI Check Digits With MSI symbols, one check digit is mandatory and always verified by the reader. The second check digit is optional. If the MSI codes include two check digits, scan the Two MSI Check Digits bar code to enable verification of the second check digit.
Page 214: Transmit Msi Check Digit
Transmit MSI Check Digit When enabled, the check digit is transmitted with the data. Set this parameter by scanning either of the bar codes shown below. Enable Transmit MSI Check Digit * Disable Transmit MSI Check Digit 3-84...
Page 215: Msi Check Digit Algorithm
MSI Check Digit Algorithm With MSI symbols, one check digit is mandatory and always verified by the reader. The second check digit is optional. If the MSI codes include two check digits, scan the Two MSI Check Digits bar code to enable verification of the second check digit.
Page 216: Postal Codes
Postal Codes Note: The default value for all Postal Code symbologies is “Enabled” (except 4State Postal). For best performance when reading a specific postal symbology, all other postal symbologies should be disabled. 4 State Postal To enable or disable 4 State Postal, scan the appropriate bar code: Enable 4 State Postal * Disable 4 State Postal Australian Postal...
Page 217: Dutch Postal
Dutch Postal To enable or disable Dutch Postal, scan the appropriate bar code: * Enable Dutch Postal Disable Dutch Postal 3-87...
Page 218: Japan Postal
Japan Postal To enable or disable Japan Postal, scan the appropriate bar code: * Enable Japan Postal Disable Japan Postal Transmit US Postal Check Digit Select whether to transmit US Postal data with or without the check digit: * Transmit US Postal Check Digit Do Not Transmit US Postal Check Digit 3-88...
Page 219: Uk Postal
UK Postal To enable or disable UK Postal, scan the appropriate bar code: * Enable UK Postal Disable UK Postal Transmit UK Postal Check Digit Select whether to transmit UK Postal data with or without the check digit: * Transmit UK Postal Check Digit Do Not Transmit UK Postal Check Digit 3-89...
Page 220: Us Planet
US Planet To enable or disable US Planet, scan the appropriate bar code: * Enable US Planet Disable US Planet US Postnet To enable or disable US Postnet, scan the appropriate bar code: * Enable US Postnet Disable US Postnet 3-90...
Page 221: Gs1 Databar (Rss)
GS1 DataBar (RSS) The variants of GS1 DataBar [RSS (Reduced Space Symbology)] are GS1 DataBar Omnidirectional (RSS-14), GS1 DataBar Expanded (RSS Expanded) and GS1 DataBar Limited (RSS Limited). The limited and expanded versions have stacked variants. Scan the appropriate bar codes that follow to enable or disable each variant of GS1 DataBar (RSS). GS1 DataBar Omnidirectional (RSS-14) To enable or disable GS1 DataBar Omnidirectional (RSS-14), scan the appropriate bar code: * Enable GS1 DataBar Omnidirectional (RSS-14)
Page 222: Gs1 Databar Limited (Rss Limited)
GS1 DataBar Limited (RSS Limited) To enable or disable GS1 DataBar Limited (RSS Limited), scan the appropriate bar code: * Enable GS1 DataBar Limited (RSS Limited) Disable GS1 DataBar Limited (RSS Limited) See Also: Convert GS1 DataBar (RSS) to UPC/EAN GS1 DataBar Expanded (RSS Expanded) To enable or disable GS1 DataBar Expanded (RSS Expanded), scan the appropriate bar code: * Enable GS1 DataBar Expanded (RSS Expanded)
Page 223: Convert Gs1 Databar (Rss) To Upc/Ean
Convert GS1 DataBar (RSS) to UPC/EAN This parameter only applies to GS1 DataBar Omnidirectional (RSS-14) and GS1 DataBar Limited (RSS Limited) symbols not decoded as part of a Composite symbol. Enable this parameter to strip the leading “010” from GS1 DataBar Omnidirectional (RSS-14) and GS1 DataBar Limited (RSS Limited) symbols, encoding a single zero as the first digit, and report the bar code as EAN-13.
Page 224: Composite
Composite Composite CC-C Scan one of the following bar codes to enable or disable Composite bar codes of type CC-C. Enable Composite CC-C * Disable Composite CC-C 3-94...
Page 225: Composite Cc-A/B
Composite CC-A/B Scan one of the following bar codes to enable or disable Composite bar codes of type CC-A/B. Enable Composite CC-A/B * Disable Composite CC-A/B Composite TLC-39 Scan one of the following bar codes to enable or disable Composite bar codes of type TLC-39. Enable Composite TLC-39 * Disable Composite TLC-39 3-95...
Page 226: Upc Composite Mode
UPC Composite Mode UPC symbols can be linked with a 2D symbol during transmission as if they were one symbol. There are three options for these symbols: UPC Never Linked Transmit UPC bar codes regardless of whether a 2D symbol is detected. Transmit UPC bar codes and the 2D portion.
Page 227: Ucc/Ean Code 128 Emulation Mode
UCC/EAN Code 128 Emulation Mode Select whether to enable or disable UCC/EAN Code 128 Emulation Mode for UCC/EAN Composite Codes. Enable UCC/EAN Code 128 Emulation Mode for UCC/EAN Composite Codes * Disable UCC/EAN Code 128 Emulation Mode for UCC/EAN Composite Codes 3-97...
Page 228: 2D Symbologies
2D Symbologies Aztec To enable or disable Aztec, scan the appropriate bar code below. * Enable Aztec Disable Aztec 3-98...
Page 229: Aztec Inverse
Aztec Inverse This parameter controls the setting of the Aztec Inverse decoder. Scan the appropriate bar code below. * Regular Only Inverse Only Inverse Auto Detect PDF417 To enable or disable PDF417, scan the appropriate bar code below. * Enable PDF417 Disable PDF417 3-99...
Page 230: Micropdf417
MicroPDF417 To enable or disable MicroPDF417, scan the appropriate bar code below. Enable MicroPDF417 * Disable MicroPDF417 3-100...
Page 231: Code 128 Emulation
Code 128 Emulation To enable or disable Code 128 Emulation, scan the appropriate bar code below. Enable Code 128 Emulation * Disable Code 128 Emulation When this parameter is enabled, the bar code reader transmits data from certain MicroPDF417 symbols as if it was encoded in Code 128 symbols.
Page 232: Data Matrix
Data Matrix To enable or disable Data Matrix, scan the appropriate bar code below. * Enable Data Matrix Disable Data Matrix Data Matrix Inverse This parameter controls the setting of the Data Matrix inverse decoder. Scan the appropriate bar code below. * Regular Only Inverse Only Inverse Auto Detect...
Page 233: Maxicode
Maxicode To enable or disable Maxicode scan the appropriate bar code below. * Enable Maxicode Disable Maxicode MicroQR To enable or disable MicroQR, scan the appropriate bar code below. * Enable MicroQR Disable MicroQR 3-103...
Page 234: Qr Code
QR Code To enable or disable QR Code scan the appropriate bar code below. * Enable QR Code Disable QR Code QR Inverse This parameter controls the setting of the QR Inverse decoder. Scan the appropriate bar code below. * Regular Only Inverse Only Inverse Auto Detect 3-104...
Page 235: Redundancy Level
Redundancy Level The decoder offers four levels of decode redundancy. Select higher redundancy levels for decreasing levels of bar code quality. As redundancy levels increase, the decoder’s aggressiveness decreases. Select the redundancy level appropriate for the bar code quality and then scan the appropriate Redundancy Level bar code on the following page.
Page 236 * Redundancy Level 1 Redundancy Level 2 Redundancy Level 3 Redundancy Level 4 3-106...
Page 237: Security Level
Security Level The decoder offers four levels of decode security for delta bar codes, which include the Code 128 family, UPC/EAN, and Code Select increasing levels of security for decreasing levels of bar code quality. There is an inverse relationship between security and decoder aggressiveness, so choose only that level of security necessary for any given application.
Page 238 Security Level 3 3-108...
Page 239: Intercharacter Gap Size
Intercharacter Gap Size Code 39 Codabar symbologies have an intercharacter gap that is typically quite small. Due to various bar code- printing technologies, this gap can grow larger than the maximum size allowed, preventing the decoder from decoding the symbol. If this problem occurs, scan the Large Intercharacter Gaps parameter to tolerate these out-of-specification bar codes.
Page 240: Imager Keypad Number Symbols
Imager Keypad Number Symbols The bar code labels shown below represent a numeric keypad, with decimal values 0 through 9. Each label should be scanned individually. Use these numeric value symbols to enter numeric input in the course of performing an imager engine system configuration. To correct an error or change a selection, scan Cancel then scan a desired bar code.
Page 241 Cancel 3-111...
Page 242 3-112...
Page 243: Chapter 4 - Decode Zones
Chapter 4 - Decode Zones The scan ranges listed in the following tables are based on the following factors: Decode zone is a function of various symbol characteristics including density, print contrast, wide-to-narrow ratio and edge acuity. Symbols test labels are examples of optimum quality bar codes. As distance decreases the visible scan line also decreases (visible scan length = 1.8 x distance to label x TAN (scan angle / 2).
Page 244: Ring Laser
Ring Laser Valid for BTRS HX2 HX3 Factory Default Scan Angle -- Wide (47°) Typical Working Ranges Guaranteed Working Ranges Symbol Density Near Near 4 mil 1.0 in / 2.50 cm 5.50 in / 13.97 cm 2.20 in / 5.60 cm 3.20 in / 8.13 cm...
Page 245: Ring Imager
Ring Imager Valid for BTRS HX2 HX3 The decode distances in this section are based on the current Focus Mode setting in the ring imager. Note that when Far Focus is set, the imager is optimized to read at its far position. With Near Focus, the imager is optimized to read at its near position.
Page 246: Pl4407 Toggled Focus Decode Distances
PL4407 Toggled Focus Decode Distances Typical Working Ranges Guaranteed Working Ranges Symbol Density Near Near 5.0 mil 3.5 in / 8.9 cm 7.5 in / 19.1 cm 4.25 in / 10.8 cm 6.0 in / 15.24 cm 6.67 mil 3.75 in / 9.5 cm 6.0 in / 15.24 cm 4.5 in / 11.4 cm 5.75 in / 14.61 cm...
Page 247: Chapter 5 - Technical Assistance
For our latest contact information, please check our website at the link above. Product Service and Repair Honeywell International Inc. provides service for all of its products through service centers throughout the world. To obtain warranty or non-warranty service, please visit www.honeywellaidc.com and select Support > Contact Service and Repair to see your region’s instructions on how to obtain a Return Material Authorization number (RMA #).
Page 248 Honeywell Scanning & Mobility 9680 Old Bailes Road Fort Mill, SC 29707 www.honeywellaidc.com E-SW-RINGSCANPG Rev H 1/13...

This manual is also suitable for:

Hx3

Honeywell HX2 Programming Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Honeywell HX2

Summary of Contents for Honeywell HX2
