A.5 Service Loop Cable Routing
Figure A-7
Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
and Figure A-8 illustrate how to route the cables to the Intercom to create a service loop.
Figure A-7. Ground Cable Service Loop Routing
Figure A-8. Network Cable Service Loop Routing
Network Cable
(Not Provided)
J1
930923B
Route Cable(s) inside Gang Box to
Ground Lug
Ground Cable
(Not Provided)
Nut
(to Ground Lug
Inside 3-Gang Box
Route Cable(s) inside Gang Box to

Service Loop Cable Routing

Creates Service Loop
Creates Service Loop
