2.4.13 Configure the Door Strike Relay

The Door Strike Relay (DSR) is a network device designed to control an electronic door strike. The
DSR is meant to be used as a replacement for (or an addition to) the on-board relay. In addition to
being a drop-in 12 Amp relay, the DSR can monitor and record when the door is open or closed.
The DSR can be configured to trigger in the following ways: on the entry of a DTMF code, during
different call events, manually through the web interface, or by using a Windows application.
1. Click on the DSR menu button to open the DSR page
Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
Installing the VoIP Outdoor Intercom with Keypad
Figure 2-30. DSR Page
930923B
Intercom Setup
(Figure 2-30).
CyberData Corporation
65
