CyberData 011310 Operation Manual page 53

Web Page Item
Remote SIP Port
Local SIP Port
Outbound Proxy
Outbound Proxy Port
User ID
Authenticate ID
Authenticate Password
Re-registration Interval (in seconds)
RTP Settings
RTP Port (even)
Call Disconnection
Terminate Call After Delay
Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
Table 2-16. SIP Configuration Parameters (continued)
Description
The Remote SIP Port is the port number the device will use as the
destination port when sending SIP messages for the Nightringer
extension. The default Remote SIP Port is 5060. The supported range is
0-65536. Enter up to 5 digits.
The Local SIP Port is the port number the device will use to receive SIP
messages for the Nightringer extension. This value cannot be the same as
the Local SIP Port
5061. The supported range is 0-65536. Enter up to 5 digits.
Enter the Outbound Proxy address as an IPv4 address in dotted decimal
notation or a fully qualified domain name (FQDN). When an IP address is
configured, the device will send all SIP messages to this IP address for the
Nightringer extension. When an FQDN is configured, the device will run
DNS NAPTR, SRV, and A queries on the FQDN to resolve an IP address
to which it will send all SIP messages for the Nightringer extension. This
field can accept entries of up to 255 characters in length.
The Outbound Proxy Port is port number used as the destination port
when sending SIP messages to the outbound proxy for the Nightringer
extension. A value of 0 will default to 5060. The supported range is 0-
65536. Enter up to 5 digits.
Specify the SIP User ID for the SIP server. This parameter becomes the
user portion of the SIP-URI for the device's Nightringer extension. Enter
up to 64 alphanumeric characters.
Specify the Authenticate ID for the SIP Server. This parameter is required
for SIP registration authentication. Enter up to 64 alphanumeric
characters.
Specify the Authenticate Password for the SIP Server. This parameter is
required for SIP registration authentication. Enter up to 64 alphanumeric
characters.
The SIP Re-registration Interval (in seconds) is the SIP Registration lease
time, also known as the expiry. The supported range is 30-3600 seconds.
Enter up to 4 digits.
Specify the port number used for the RTP stream after establishing a SIP
call. This port number must be an even number and defaults to 10500.
The supported range is 0-65536. Enter up to 5 digits.
Automatically terminate an active call after a given delay in seconds. A
value of 0 will disable this function. Enter up to 8 digits.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
930923B
Installing the VoIP Outdoor Intercom with Keypad
for the primary extension. The default Local SIP Port is
45
Intercom Setup
CyberData Corporation
