Mount the Intercom
Figure A-2. Shroud Dimensions and Mounting Hole Locations
7.638 [194.00]
3.434 [87.23]
ø0.280 [ø7.11]
ø0.854 [ø21.69]
(3 PLACES)
3.380 [85.85]
3.819 [97.00]
7.638 [194.00]
Di ensions are in Inches [Milli eter]
