SiK401004_A

3.1.2 Instruction to LCD Display

No. Description
1 Swing *
2 Air *
3 Sleep
4 Running mode
5 Cooling
6 Dry
7 Fan
8 Heating
9 Defrost
10 Gate-control card *
11 Lock
12 Shield
13 Turbo
14 Memory
15 Twinkle
16 Save
17 Temperature
18 E-Heater *
19 Blow
20 Timer
21 Quiet
Notes: The functions with * are reserved for other models and are not applicable for the models listed in
this manual.
FUNCTION CONTROL
Instruction to Displaying Contents
Swing function
Air exchange function
Sleeping states
Each kind of running mode of indoor unit (auto mode)
Cooling mode
Dry mode
Fan mode
Heating mode
Defrosting state
Gate control
Lock state
Shielding state (buttons, temperature, on/off, mode or save is shielded by
long-distance monitoring
Turbo function state
Memory state (Indoor unit resumes original setting state after power failure
and then power recovery)
Flicking when unit is on without operation of buttons
Energy-saving state
Ambient/setting temperature value
E-HEATER display means electric-heater is available
Blow mark
Timer-displayed location
Quiet state(two types: quiet and auto quiet)
Table 3.1
