Disassembly of external casing cabinet
Remark: Make sure the power supply is cut off before disassembling and protect all the parts during disassembly.
Step
1. Disassembly of the
screws on the cover
plates
2. Disassembly of the
external casing
cabinet
125
Illustration
Handling Instruction
●Remove the screws
between right and left panels
and upper cover plates.
Remove right and left
panels. (As shown in the
illustration, circle represents
screws.)
●Disassembled the external
casing cabinet is shown in
the illustration.
