Sintrones VBOX-3200 User Manual page 9

Storage
Type
Graphics
Graphics
Resolution
Qualification
Certifications
I/O
Serial Port
USB Port
LAN
Video Port
DIO Port
Audio
SIM Card Socket
Environment
Operating Temp.
Storage Temp.
Relative Humidity
Vibration (random)
Vibration Operating
Truck Storage
Shock
Crash Hazard
Mechanical
Construction
Mounting
Weight
Dimensions
User's Manual
2 x 2.5" drive bay for SATA Type Hard Disk Drive / SSD
AMD G-T56N Radeon HD 6310 / G-T44R Radeon HD 6250
1 X DVI-I connector and VGA on rear I/O
Up to 2045 x 1560 @85H
CE, FCC, Class A
3 x RS-232 (COM1,2 with RS-422/485, RS-485 Support Auto Direction
Control)
4 x USB 2.0 Ports on Front I/O
2 x RJ45 Ports for GbE
1 x DVI-I and 1 x VGA Output
4 in and 2 out with Relay 12V / 80mA
1 x Line-out (Default is 1 on Rear I/O)
1 x SIM Card socket supported onboard with eject
-40 ~ 70ºC (SSD), ambient w/ air
-40 ~ 80ºC
10 ~ 95% (non-condensing)
2.5g@5~500 Hz with SSD
MIL-STD-810F, Method 514.5, Category 20, Ground Vehicle-Highway
MIL-STD-810F, Method 514.5, Category 24, Integrity Test
Operating: MIL-STD-810F, Method 516.5, Procedure I, Trucks and
semi-trailers=40G(11ms), Non-Operating 80G with SSD
MIL-STD-810F, Method 516.5, Procedure V, Ground equipment=100
Aluminum alloy
Supports both of wall-mount/VESA-mount
1.5 kg (bard-bone)
250 x 150 x 55 mm
1.0 Introduction
Page 1-2
