Sintrones VBOX-3200 User Manual

In-vehicle computing
Hide thumbs Also See for VBOX-3200:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Document Name VBOX-3200 User Manual
Version
1.0
Reversion History :
Reversion
From
To
1.0
Jun 08, 2011
VBOX-3200
In-Vehicle Computing
User's Manual
Version 1.0
Date
Initial document issued
Document No. UM2011320010
Date
Notes
1
Jun 08, 2011
Author(s)
Stanley Chou

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VBOX-3200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sintrones VBOX-3200

Summary of Contents for Sintrones VBOX-3200

  • Page 1 VBOX-3200 In-Vehicle Computing User's Manual Version 1.0 Document Name VBOX-3200 User Manual Document No. UM2011320010 Version Date Jun 08, 2011 Reversion History : Reversion Date Notes Author(s) From Jun 08, 2011 Initial document issued Stanley Chou...
  • Page 2 For continuing product improvement, SINTRONES® Technology Corp. reserves the right to revise the manual or make changes to the specifications of this product at any time without notice and obligation to any person or entity regarding such change.

  • Page 3: Safety Information

    Safety Information Read the following precautions before setting up a SINTRONES Product. Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected.
  • Page 4 Table of contents (1) Introduction 1.1 Model Specifications 1.2 VBOX-3200 Illustration (Mainboard, System) (2) External connector specification 2.1 POWER IN connector 2.2 POWER BUTTON connector 2.3 DIO connector 2.4 RJ45 connector: (LAN0) 2.5 RJ45 connector: (LAN1) 2.6 COM Port connector: (COM1) 2.7 DVI-I connector: (DP1+VGA)
  • Page 5 3.16 RS232 RI# Pin Power Select connector: (COM2) 3.17 RS232 RI# Pin Power Select connector: (COM1) 3.18 MINI CARD connector: (MINICARD0) 3.19 MINI CARD connector: (MINICARD1) 3.20 MINI CARD connector: (MINICARD2) (4) System Installation 4.1 System Introduction 4.2 Opening Chassis 4.3 Installing Memory 4.4 Installing MINI PCIe Expansion Card (PCIe 1) 4.5 Installing MINI PCIe Expansion Card (PCIe 2, Wifi Module)

  • Page 6: Model Specifications

    1.1 Model Specification System  AMD G‐T56N Dual Core 1.6GHz  AMD G‐T40N Dual Core 1.0GHz  AMD G‐T44R Single Core 1.2GHz (Optional)  2 x DDR3 1333MHz SO‐DIMM up to 8GB  Memory AMD A55E Controller Hub  Chipset AMD G‐T56N Radeon HD 6310 / G‐T44R Radeon HD 6250  Graphics 2 x Realtek RTL8111E Gb/s Ethernet onboard    LAN Chipset Support PXE  Realtek ALC662 HD Codec onboard  Audio 1 ~ 255 Level Reset  Watchdog Power Requirement  9V‐32V DC Power input  Power Input Automatics Recovery Short Circuit Protection  Power Protection Power Management Vehicle Power Ignition for Variety Vehicle  Power off Delay Time Setting by Software, Default is 5 Mins  Power Off Control Internal Battery Kit for 10 Mins Operating (Optional)  Battery...
  • Page 7 Graphics  AMD G‐T56N Radeon HD 6310 / G‐T44R Radeon HD 6250  Graphics 1 X DVI‐I connector and VGA on rear I/O  Up to 2045 x 1560 @85H  Resolution Storage  2 x 2.5” drive bay for SATA Type Hard Disk Drive / SSD  Type Qualification  CE, FCC, Class A  Certifications I/O  COM1,2 with RS-422/485, RS-485 Support Auto Direction Control 3 x RS‐232 ( Serial Port 4 x USB 2.0 Ports on Front I/O  USB Port 2 x RJ45 Ports for GbE  1 x DVI‐I and 1 x VGA Output  Video Port 4 in and 2 out with Relay 12V / 80mA  DIO Port 1 x Line‐out (Default is 1 on Rear I/O)  Audio 1 x SIM Card socket supported onboard with eject  SIM Card Socket Environment ...
  • Page 8 1.2 VBOX-3200 Illustration Mainboard...
  • Page 9 System...
  • Page 10 (2) System Installation 2.1 System Introduction...

  • Page 11: Power In Connector

    (2) External connector specification 2.1 POWER IN connector: A. Connector size: 1 X 3 = 3 Pin B. Connector location: PWR2 PWR2 PHOENIX 5mm-F-90D C. Connector pin definition Signal DC_IN IGNITION 2.2 POWER BUTTON connector: A. Connector size: 6 Pin B.

  • Page 12: Dio Connector

    2.3 DIO connector: A. Connector size: 1 X 8 = 8 Pin B. Connector location: GPIO2 GPIO2 PHOENIX 3.5mm-F-90D C. Connector pin definition Signal +12V GPO1 GPO2 GPI1 GPI2 GPI3 GPI4 2.4 RJ45 connector: A. Connector size: RJ45+LED B. Connector location: LAN2 LAN2 Gre e n(R) TD1+...
  • Page 13 2.5 RJ45 connector: A. Connector size: RJ45+LED B. Connector location: LAN1 LAN1 Gre e n(R) TD1+ TD1- TD2+ Orange (L) TD2- TD3+ TD3- TD4+ TD4- RJ45+LED-90 C. Connector pin definition Signal Signal LAN1_MDI0P LAN1_MDI0N LAN1_MDI1P LAN1_MDI2P LAN1_MDI2N LAN1_MDI1N LAN1_MDI3P LAN1_MDI3N LAN1_ACT# LAN1_ACTPW LAN1_LINK#...
  • Page 14 D. Connector pin definition (RS-422) Signal Signal COM1_TXD- COM1_TXD+ COM1_TXD+ COM1_RXD- E. Connector pin definition (RS-485) Signal Signal COM1_TXD-/RXD- COM1_TXD+/RXD+ 2.7 DVI-I connector: A. Connector size: DVI-I B. Connector location: DVID2 DVID2 TX0- TX2- TX1- TX0+ TX2+ TX1+ 0/5 Shield 2/4 Shield 1/3 Shield TX5-...
  • Page 15 C. Connector pin definition Signal Signal DVI_TX2_N DVI_TX2_P 5VSB_USB +12V_PWR DVI_DDC_CLK DVI_DDC_DATA CRT_VSYNC DVI_TX1_N DVI_TX1_P USB_12N USB_12P +5V_DVI_PWR DVI_HPD DVI_TX0_N DVI_TX0_P CRT_DAC_SDA CRT_DAC_SCL DVI_CLK_P DVI_CLK_N CRT_RED CRT_GREEN CRT_BLUE CRT_HSYNC 2.8 USB connector: A. Connector size: USB TYPEA B. Connector location: USB2 USB2 DATA1- DATA-...

  • Page 16: Audio Connector

    2.9 USB connector: A. Connector size: USB TYPEA B. Connector location: USB1 USB1 DATA1- DATA- DATA1+ DATA+ MGND MGND MGND MGND 2USB-F-90 C. Connector pin definition Signal Signal 5VSB_USB USB2_N USB2_P 5VSB_USB USB3_N USB3_P 2.10 Audio connector: A. Connector size: Phone Jack B.

  • Page 17: Sim Card Connector

    2.11 SIM CARD connector: A. Connector size: 6 Pin B. Connector location: SIM1 SIM1 C. Connector pin definition Signal Signal DATA 2.12 UPS/3.5G LED: A. Connector size: 2 Layer LED with Housing B. Connector location: LED1 LED1 上 下 LED_RG HOUSING C.

  • Page 18: Hdd/Acc Led

    2.13 HDD/ACC LED: A. Connector size: 2 Layer LED with Housing B. Connector location: LED2 LED2 上 下 LED_RG HOUSING C. Connector pin definition Signal Location ACC_LED_P Down ACC_LED_N HDD_LED_P HDD_LED_N...

  • Page 19: Sata Power Wafer Connector

    (3) Internal connector /pin header specification 3.1 SATA power wafer connector: A. Connector size: 1 X 4 = 4 Pin B. Connector location: CN1 POWER-2.54mm-M-180 C. Connector pin definition Signal +12V 3.2 Reserved JST connector: A. Connector size: 2 X 5 = 10 Pin B.
  • Page 20 3.3 COM port JST connector: A. Connector size: 2 X 5 = 10 Pin B. Connector location: COM2 COM1 JST-2.0mm-M-180 C. Connector pin definition Signal Signal COM4_DCD# COM4_RXD COM4_TXD COM4_DTR# COM4_DSR# COM4_RTS# COM4_CTS# COM4_RI# 3.4 COM port JST connector: A. Connector size: 2 X 5 = 10 Pin B.
  • Page 21 E. Connector pin definition (RS-485) Signal Signal COM2_TXD-/RXD- COM2_TXD+/RXD+ 3.5 COM port JST connector: A. Connector size: 2 X 5 = 10 Pin B. Connector location: COM4 COM4 JST-2.0mm-M-180 C. Connector pin definition Signal Signal COM3_DCD COM3_RXD COM3_TXD COM3_DTR COM3_DSR COM3_RTS COM3_CTS COM3_RI...

  • Page 22: Dvi-D /Lvds Connector: (Dp0)

    3.6 DVI-D /LVDS connector: (DP0) A. Connector size: 2 X 20 = 40 Pin B. Connector location: DVII1 DVII1 MGND MGND DF-1.25mm-M-180 C. Connector pin definition Signal Signal DVI_TX0_N DVI_TX0_P /LVDS_TX0_N /LVDS_TX0_P DVI_TX1_N DVI_TX1_P /LVDS_TX1_N /LVDS_TX1_P DVI_TX2_N DVI_TX2_P /LVDS_TX2_N /LVDS_TX2_P DVI_CLK_N /LVDS_CLK_N DVI_CLK_P...

  • Page 23: Vga Jst Connector

    3.7 VGA JST connector: A. Connector size: 2 X 8 = 16 Pin B. Connector location: VGA1 VGA1 JST-2.0mm-M-180 C. Connector pin definition Signal Signal GREEN BLUE DAC_SDA HSYNC VSYNC DAC_SCL 3.8 SATA connector: A. Connector size: 1 X 7 = 7 Pin (SATA-M-180) B.
  • Page 24 3.9 SATA connector: A. Connector size: SATA-F-22P-90 B. Connector location: SATA2 SATA2 SATA-F-22P-90 C. Connector pin definition Signal Signal Signal SATA_TXP0 P10 NC SATA_TXN0 P11 GND P12 GND SATA_RXN0 P13 NC SATA_RXP0 P14 NC 3.10 USB JST connector: A. Connector size: 2 X 5 = 10 Pin B.

  • Page 25: Ups Jst Connector

    3.11 USB JST connector: A. Connector size: 2 X 5 = 10 Pin B. Connector location: USB6 USB6 JST-2.0mm-M-180 C. Connector pin definition Signal Signal 5VSB_USB 5VSB_USB USB6_N USB7_N USB6_P USB7_P 3.12 UPS JST connector: A. Connector size: 1 X 5 = 5 Pin B.

  • Page 26: Download Port Jst Connector

    3.13 Download Port JST connector: A. Connector size: 1 X 5 = 5 Pin B. Connector location: J5 JST-2.0mm-M-180 C. Connector pin definition Signal +3.3V_MCU MRST C2CK Recommend to use CR2032 Battery) 3.14 BATTERY connector ( A. Connector size: 1 X 2 = 2 Pin B.

  • Page 27: Rtc Reset Connector

    3.15 RTC RESET connector: A. Connector size: 1 X 3 = 3 Pin B. Connector location: JP1 PIN-2.54mm-M-180 C. Connector pin definition Signal RTC_BAT RTCRST# 3.16 COM2 RS232 RI# Pin Power Select connector: A. Connector size: 1 X 5 = 5 Pin B.
  • Page 28 3.17 COM1 RS232 RI# Pin Power Select connector: A. Connector size: 1 X 5 = 5 Pin B. Connector location: JP7 PIN-2.0mm-M-180 C. Connector pin definition Signal POWER +12V POWER COM1_RI 3.18 MINI CARD connector: A. Connector size: 2 X 26 = 52 Pin B.
  • Page 29 C. Connector pin definition Signal Signal PCIE_WAKE# 3VSB +1.5V MINICARD0_CLKREQ# PCIE_MCARD0_CLK_N PCIE_MCARD0_CLK_P MINICARD0_DIS# PCIE_RST# PCIE_MCARD0_RX_N 3VSB PCIE_MCARD0_RX_P +1.5V SMB_CLK PCIE_MCARD0_TX_N SMB_DATA PCIE_MCARD0_TX_P USB_8N USB_8P 3VSB 3VSB +1.5V 3VSB...
  • Page 30 3.19 MINI CARD connector: A. Connector size: 2 X 26 = 52 Pin B. Connector location: MINICARD2 MINICARD2 MINI PCIE CON REV1 3.3VSB_2 REV2 GND7 Ver:1.2 REV3 1.5V_1 REV4 LED_WPAN# GND14 LED_WLAN# 3.3VSB_5 LED_WWAN# 3.3VSB_4 GND8 GND13 USB_D+ GND0 USB_D- PETp0 GND9 PETn0...
  • Page 31 3.20 MINI CARD connector: A. Connector size: 2 X 26 = 52 Pin B. Connector location: MINICARD1 MINICARD1 MINI PCIE CON REV1 3.3VSB_2 REV2 GND7 Ver:1.2 REV3 1.5V_1 REV4 LED_WPAN# GND14 LED_WLAN# 3.3VSB_5 LED_WWAN# 3.3VSB_4 GND8 GND13 USB_D+ GND0 USB_D- PETp0 GND9 PETn0...

  • Page 32: System Introduction

    4 System Installation 4.1 System Introduction ...

  • Page 33: Opening Chassis

     4.2 Opening Chassis Step 1. Unscrew the six screws of the Back Cover as shown in the picture. Step 2. Unscrew the six screws of the Front Panel as shown in the picture. Step 3. Unscrew the six screws of the Rear Panel as shown in the picture.
  • Page 34 Step 5. You can see three connectors connect with mainboard as shown in the picture. COM2 COM3 Step 6. Pull up the connector as shown in the picture. Step 7. You can see Ipexs on the Mini PCIe module connectors as shown in the picture.

  • Page 35: Installing Memory

     4.3 Installing Memory Step 1. Put Memory on this place as shown in the picture. Step 2. Hold the Memory with its notch aligned with the Memory socket of the board and insert it at a 30-degree angle into the socket as shown in the picture.
  • Page 36 Step 5. Hold the Memory with its notch aligned with the Memory socket of the board and insert it at a 30-degree angle into the socket as shown in the picture. Step 6. Fully insert the module into the socket until a “click” is heard as shown in the picture.
  • Page 37  4.4 Installing MINI PCIe Expansion Card (PCIe 1) Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture. Step 2. Hold the Module with its notch aligned with the socket of the board and insert it at a 30 degree angle into the socket as shown in the picture.

  • Page 38: Installing Mini Pcie Expansion Card (Pcie 2, Wifi Module)

     4.5 Installing MINI PCIe Expansion Card (PCIe 2, Wifi Module) Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture. Step 2. Hold the Module with its notch aligned with the socket of the board and insert it at a 30 degree angle into the socket as shown in the picture.
  • Page 39  4.6 Installing MINI PCIe Expansion (PCIe 3, 3G Module only) Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture. Step 2. Hold the Module with its notch aligned with the socket of the board and insert it at a 30 degree angle into the socket as shown in the picture.

  • Page 40: Installing Internal Antenna Cable

     4.7 Installing Internal Antenna Cable Step 1. Take the SMA Connector and Plug into IO Panel as shown in the picture. Step 2. Put the Washer into the SMA Connector as shown in the picture. Step 3. Put the Oring to SMA Connector and tighten as shown in the picture.
  • Page 41 Step 5. Take the Ipex Connector and press on the wifi module as shown in the picture.(Wifi) Step 6. Take the Ipex Connector and press on the 3G module as shown in the picture. (3G) Step 7. Take the Ipex Connector and press on the GPS module as shown in the picture.

  • Page 42: Installing Sim Card

    Step 1. Use thin stick to push the button as shown in the picture. Step 2. Take the holder away from VBOX-3200 as shown in the picture. Step 3. Put your SIM Card into the holder as shown in the picture.

  • Page 43: Installing Hdd

     4.9 Installing HDD Step 1. Put the HDD into HDD Holder as shown in the picture. Step 2. Screw two screws on both side as shown in the picture. Step 3. Push the HDD Holder into the socket as shown in the picture.
  • Page 44 Step 4. Fully insert the HDD Holder into the socket until a “click” is heard as shown in the picture. Step 5. Tighten to Storage Bracket screws as shown in the picture.

  • Page 45: Ignition Power Management Quick Guide

    (5) System Resources 5.1 Ignition Power Management Quick Guide Startup/shutdown conditions from the IGNITION signal: IGNITION startup signal must be valid during 5 sec. (anti noise protection). IGNITION shutdown – IGNITION signal must be inactive during 5 minutes, then PIC controller initiate Power Button signal (OS must be set to shutdown from the Power Button).

  • Page 46: Power Management

    Ignition On/Off status detectable by SW If the ignition is off and the system is still on after 5 minutes, VBOX-3200 will shut down automatically. If the ignition is turned on again and the power-off delay is in progress, VBOX-3200 will cancel the delay function and will continue to operate normally.

  • Page 47: Gpio & Delay Time Setting

    5.2 GPIO & Delay Time Setting 5.2.1 GPIO, Delay Time and Ignition Control Register The General Purpose I/O is an interface available on some devices. These can read digital signals from other parts of a circuit, or output to control other devices. At GPIO control register, the GPI is use to receive data, the GPO is set data to send.
  • Page 48 Read Ignition Register & Example Code (pFunc != IntPtr.Zero) UInt32 PortVal; SetPortValType SetPortVal = (SetPortValType)Marshal.GetDelegateForFunctionPointer(pFunc, typeof(SetPortValType)); GetPortValType GetPortVal = (GetPortValType)Marshal.GetDelegateForFunctionPointer(pFunc, typeof(GetPortValType)); SetPortVal(0x4E, 0x87, 1); // Enter Super IO SetPortVal(0x4E, 0x87, 1); // Enter Super IO SetPortVal(0x4E, 0x07, 1); // Select Logic 7 for GPIO SetPortVal(0x4F, 0x06, 1);...
  • Page 49 (2) Read Register & Example Code (pFunc != IntPtr.Zero) UInt32 PortVal; SetPortValType SetPortVal = (SetPortValType)Marshal.GetDelegateForFunctionPointer(pFunc, typeof(SetPortValType)); GetPortValType GetPortVal = (GetPortValType)Marshal.GetDelegateForFunctionPointer(pFunc, typeof(GetPortValType)); SetPortVal(0x4E, 0x87, 1); // Enter Super IO SetPortVal(0x4E, 0x87, 1); // Enter Super IO SetPortVal(0x4E, 0x07, 1); // Select Logic 7 for GPIO SetPortVal(0x4F, 0x06, 1);...
  • Page 51 2 Watchdog Timer Programming Procedure (1) Example Code private void button2_Click(object sender, EventArgs IntPtr pFunc = GetProcAddress(hMod, "SetPortVal"); (pFunc != IntPtr.Zero) SetPortValType SetPortVal = (SetPortValType)Marshal.GetDelegateForFunctionPointer(pFunc, typeof(SetPortValType)); SetPortVal(0x266, 0x0A, 1); // Set watchdog timer value is 10 SetPortVal(0x265, 0x32, 1); // Set watchdog timer unit is sec and enable watchdog // SetPortVal(0x265, 0x3A, 1);...
  • Page 52 5.3 Gobi2000 WWAN Module Application Note Document Number: VBOX-3200-WWAN-01 1. EQUIPMENT REQUIREMENTS 2. TEST SETUP 3. TEST 4. PASS/FAIL CRITERIA : 1. EQUIPMENT REQUIREMENTS • Sierra Wireless Gobi 2000. • FETnet 3G SIM Card with HSDPA operation. 2. TEST SETUP Figure 1: Install WWAN AP Install WWAN AP and configure the EUT with the latest hardware and software.
  • Page 53 Figure 2: Signal of WWAN Module for UTMS Channels. 3. TEST Procedure Power-up the EUT until it has completed its boot up process. Place the EUT in building and check the UMTS/HSDPA signal intensity. Connect to Internet through UMTS/HSDPA channel. Check the link speed if bandwidth is 7.2Mbps.
  • Page 54 Figure 4: Link State of WWAN Module. Figure 5: Download Test File from Internet.
  • Page 55 4. PASS/FAIL CRITERIA : PASS Criterion : The signal intensity item of the WWAN module must greater than 3 steps. And download test no any error. Signal intensity item Download complete and no any error...

  • Page 56: Gobi2000 Gps Module Application Note

    5.4 Gobi2000 GPS Module Application Note Document Number: VBOX-3200-GPS-01 1. EQUIPMENT REQUIREMENTS 2. TEST SETUP 3. TEST 4. PASS/FAIL CRITERIA : 5. EQUIPMENT REQUIREMENTS • Sierra Wireless Gobi 2000. • FETnet 3G SIM Card with HSDPA operation. • GPSview program.
  • Page 57 Figure 2: Signal of WWAN Module for UTMS Channels. 7. TEST Out door power-up the EUT until it has completed its boot up process. Place the EUT in building and check the UMTS/HSDPA and GPS signal intensity. Get GPS longitude and latitude; connect to Internet through UMTS/HSDPA channel.
  • Page 58 Figure 4: Link State of WWAN Module. Figure 5: GPS longitude and latitude information...
  • Page 59 Figure 6: Link to Google Maps. Figure 7: GPSview program test.
  • Page 60 8. PASS/FAIL CRITERIA : PASS Criterion : We must check two results. One is amount of satellite, and another one is the satellite set and fix time. The amount of satellite must exceed five satellites, and the intensity must exceed 30. The satellite set and fix time must be smaller than 60 sec.
  • Page 61 (6) BIOS 6.1 Super IO Configuration Select Serial Port Mode...
  • Page 62 Select Power off delay time...

  • Page 63: Packing List

    (7) Packing List 7.1 Packing List Item Part Number Module Name 663200001000 VBOX-3200-T56N/2GB 370832001100 VBOX-3200 Mount Bracket 351102040110 Screw I Type M2*4L ISO NI 351103040250 Screw F Type M3*4 326710039661 CABLING PHOENIX CON MALE 3PIN 324610088661 CABLING PHOENIX CON MALE 8PIN...
  • Page 64 / software upgradable to BT3.0+HS(Motorola) Combo Mini Card WiFi 570802010062 QCOM Ralink 802.11b/g/N, 2T2R,(DSS-3000) Mini PCIe SINTRONES Neosonic-Polymer 800mAH 3S1P Battery kit for Battery Kits 221401280000 VBOX-3000 Windows Embedded Standard 2009 (Windows XP 972009720000 Microsoft Embedded)
