3.10 USB Connector (USB2/3)

A. Connector size: USB TYPEA
B. Connector location: USB1
C. Connector pin definition
Pin
1 5VSB_USB
3 USB2_P
5 5VSB_USB
7 USB3_P

3.11 Audio Connector

A. Connector size: Phone Jack
B. Connector location: Audio2
C. Connector pin definition
Pin
1 FRONT_OUT_L
3 NC
5 GND
User's Manual
USB1
1
VCC
2
DATA1-
3
DATA1+
4
GND
9
MGND
10
MGND
2USB-F-90
Signal Pin
LOUT1
5
4
3
1
6
2
AUDIO_PHONE-F-90
Signal Pin
5
VCC
6
DATA-
7
DATA+
8
GND
11
MGND
12
MGND
Signal
2 USB2_N
4 GND
6 USB3_N
8 GND
Signal
2 FRONT-JD
4 FRONT_OUT_R
6 GND
3.0 External Connector Specification
Page 3-8
