Sintrones VBOX-3200 User Manual

In-vehicle computing
Hide thumbs Also See for VBOX-3200:
Table of Contents

Advertisement

Quick Links

VBOX-3200
User's Manual
VBOX-3200 User Manual
Document Name
Version
1.2
Reversion History :
Reversion
From
To
1.0
Jun 08, 2011
1.1
Jun 25, 2012
1.1
1.2
Sept 27, 2012
In-Vehicle Computing
Version 1.2
Date
Initial document issued
Add CAN Pin assignment
M12 Connecting to the Network
Document No.
Date
Notes
UM2011320012
Sept. 27, 2012
Author(s)
Stanley Chou
Stanley Chou
Stanley Chou

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VBOX-3200 and is the answer not in the manual?

Questions and answers

Related Manuals for Sintrones VBOX-3200

Summary of Contents for Sintrones VBOX-3200

  • Page 1 VBOX-3200 In-Vehicle Computing User's Manual Version 1.2 VBOX-3200 User Manual UM2011320012 Document Name Document No. Version Date Sept. 27, 2012 Reversion History : Reversion Date Notes Author(s) From Jun 08, 2011 Initial document issued Stanley Chou Jun 25, 2012 Add CAN Pin assignment...

  • Page 2: User Manual

    Disclaimer SINTRONES® Technology Corp. shall not be liable for any incidental or consequential damages resulting from the performance or use of this product. SINTRONES® Technology Corp. makes no representation or warranty regarding the content of this manual.

  • Page 3: Safety Information

    Safety Information Read the following precautions before setting up a SINTRONES Product. Electrical safety  To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.  When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected.

  • Page 4: Technical Support

    CAUTION Incorrectly replacing the battery may damage this computer. Replace only with the same or its equivalent as recommended by SINTRONES® Technology Corp. Dispose used battery according to the manufacturer's instructions. Technical Support Please do not hesitate to call or e-mail our customer service when you still cannot fix the problems.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS Page # Introduction ..........................1-1 Model Specification ......................1-1 VBOX-3200 Illustration (MB, System) ................1-3 Internal Connector Specification .................... 2-1 SATA Power Wafer Connector ................... 2-1 Reserved JST Connector ...................... 2-1 COM Port JST Connector (COM2) ..................2-2 COM Port JST Connector (COM3) ..................
  • Page 6 M12 Connecting to the Network ..................3-4 COM Port Connector (COM1)....................3-5 DVI-I Connector (DP1+VGA)....................3-6 USB Connector (USB 0/1) ....................3-7 3.10 USB Connector (USB2/3) ....................3-8 3.11 Audio Connector ........................3-8 3.12 CAN Pin Assignment ......................3-9 3.13 UPS/3.5G LED ........................

  • Page 7: Introduction

    1.0 Introduction INTRODUCTION User’s Manual...

  • Page 8: Model Specification

    1.0 Introduction 1.0 INTRODUCTION Model Specification System AMD G-T56N Dual Core 1.6GHz AMD G-T40N Dual Core 1.0GHz AMD G-T44R Single Core 1.2GHz (Optional) Memory 2 x DDR3 1333MHz SO-DIMM up to 8GB Chipset AMD A55E Controller Hub Graphics AMD G-T56N Radeon HD 6310 / G-T44R Radeon HD 6250 2 x Realtek RTL8111E Gb/s Ethernet onboard LAN Chipset Support PXE...
  • Page 9 1.0 Introduction Storage Type 2 x 2.5” drive bay for SATA Type Hard Disk Drive / SSD Graphics AMD G-T56N Radeon HD 6310 / G-T44R Radeon HD 6250 Graphics 1 X DVI-I connector and VGA on rear I/O Resolution Up to 2045 x 1560 @85H Qualification Certifications CE, FCC, Class A...

  • Page 10: Vbox-3200 Illustration (Mb, System)

    1.0 Introduction VBOX-3200 Illustration (MB, System) Main Board User’s Manual Page 1-3...
  • Page 11 1.0 Introduction System User’s Manual Page 1-4...

  • Page 12: Internal Connector Specification

    2.0 Internal Connector Specification INTERNAL CONNECTOR SPECIFICATION User’s Manual...

  • Page 13: Sata Power Wafer Connector

    2.0 Internal Connector Specification 2.0 INTERNAL CONNECTOR SPECIFICATION SATA Power Wafer Connector A. Connector size: 1 X 4 = 4 Pin B. Connector location: CN1 POWER-2.54mm-M-180 C. Connector pin definition Signal +12V Reserved JST Connector A. Connector size: 2 X 5 = 10 Pin B.

  • Page 14: Com Port Jst Connector (Com2)

    2.0 Internal Connector Specification COM Port JST Connector (COM2) A. Connector size: 2 X 5 = 10 Pin B. Connector location: COM2 COM1 JST-2.0mm-M-180 C. Connector pin definition Signal Signal COM4_DCD# COM4_RXD COM4_TXD COM4_DTR# COM4_DSR# COM4_RTS# COM4_CTS# COM4_RI# COM Port JST Connector (COM3) A.

  • Page 15: Com Port Jst Connector (Com4)

    2.0 Internal Connector Specification D. Connector pin definition (RS-422) Signal Signal COM2_TXD- COM2_TXD+ COM2_RXD+ COM2_RXD- E. Connector pin definition (RS-485) Signal Signal COM2_TXD-/RXD- COM2_TXD+/RXD+ COM Port JST Connector (COM4) A. Connector size: 2 X 5 = 10 Pin B. Connector location: COM4 COM4 JST-2.0mm-M-180 C.

  • Page 16: Dvi-D /Lvds Connector: (Dp0)

    2.0 Internal Connector Specification DVI-D /LVDS connector: (DP0) A. Connector size: 2 X 20 = 40 Pin B. Connector location: DVII1 DVII1 MGND MGND DF-1.25mm-M-180 C. Connector pin definition Signal Signal DVI_TX0_N /LVDS_TX0_N DVI_TX0_P /LVDS_TX0_P DVI_TX1_N /LVDS_TX1_N DVI_TX1_P /LVDS_TX1_P DVI_TX2_N /LVDS_TX2_N DVI_TX2_P /LVDS_TX2_P DVI_CLK_N /LVDS_CLK_N DVI_CLK_P /LVDS_CLK_P...

  • Page 17: Vga Jst Connector

    2.0 Internal Connector Specification VGA JST Connector A. Connector size: 2 X 8 = 16 Pin B. Connector location: VGA1 VGA1 JST-2.0mm-M-180 C. Connector pin definition Signal Signal GREEN BLUE DAC_SDA HSYNC VSYNC DAC_SCL SATA Connector (SATA1) A. onnector size: 1 X 7 = 7 Pin (SATA-M-180) B.

  • Page 18: Sata Connector (Sata0)

    2.0 Internal Connector Specification SATA Connector (SATA0) A. Connector size: SATA-F-22P-90 B. Connector location: SATA2 SATA2 SATA-F-22P-90 C. Connector pin definition Signal Signal Signal P9 +5V SATA_TXP0 P10 NC SATA_TXN0 P11 GND P12 GND SATA_RXN0 P13 NC SATA_RXP0 P14 NC 2.10 USB JST Connector (USB4/5) A.

  • Page 19: Usb Jst Connector (Usb 6/7)

    2.0 Internal Connector Specification 2.11 USB JST Connector (USB 6/7) A. Connector size: 2 X 5 = 10 Pin B. Connector location: USB6 USB6 JST-2.0mm-M-180 C. Connector pin definition Signal Signal 5VSB_USB 5VSB_USB USB6_N USB7_N USB6_P USB7_P 2.12 UPS JST Connector A.

  • Page 20: Download Port Jst Connector

    2.0 Internal Connector Specification 2.13 Download Port JST Connector A. Connector size: 1 X 5 = 5 Pin B. Connector location: J5 JST-2.0mm-M-180 C. Connector pin definition Signal +3.3V_MCU MRST C2CK 2.14 BATTERY Connector (Recommend to use CR2032 Battery) A. Connector size: 1 X 2 = 2 Pin B.

  • Page 21: Rtc Reset Connector

    2.0 Internal Connector Specification 2.15 RTC RESET Connector A. Connector size: 1 X 3 = 3 Pin B. Connector location: JP1 PIN-2.54mm-M-180 C. Connector pin definition Signal RTC_BAT RTCRST# 2.16 RS232 RI# Pin Power Select Connector (COM2) A. Connector size: 1 X 5 = 5 Pin B.

  • Page 22: Rs232 Ri# Pin Power Select Connector (Com1)

    2.0 Internal Connector Specification 2.17 RS232 RI# Pin Power Select Connector (COM1) A. Connector size: 1 X 5 = 5 Pin B. Connector location: JP7 PIN-2.0mm-M-180 C. Connector pin definition Signal POWER +12V POWER COM1_RI 2.18 MINI CARD Connector (Mini Card0) A.
  • Page 23 2.0 Internal Connector Specification C. Connector pin definition Signal Signal PCIE_WAKE# 3VSB +1.5V MINICARD0_CLKREQ# PCIE_MCARD0_CLK_N PCIE_MCARD0_CLK_P MINICARD0_DIS# PCIE_RST# PCIE_MCARD0_RX_N 3VSB PCIE_MCARD0_RX_P +1.5V SMB_CLK PCIE_MCARD0_TX_N SMB_DATA PCIE_MCARD0_TX_P USB_8N USB_8P 3VSB 3VSB +1.5V 3VSB User’s Manual Page 2-11...

  • Page 24: Mini Card Connector (Mini Card1)

    2.0 Internal Connector Specification 2.19 Mini CARD Connector (Mini Card1) A. Connector size: 2 X 26 = 52 Pin B. Connector location: MINICARD2 MINICARD2 MINI PCIE CON REV1 3.3VSB_2 REV2 GND7 Ver:1.2 REV3 1.5V_1 REV4 LED_WPAN# GND14 LED_WLAN# 3.3VSB_5 LED_WWAN# 3.3VSB_4 GND8 GND13...

  • Page 25: Mini Card Connector (Mini Card2)

    2.0 Internal Connector Specification 2.20 MINI CARD Connector (Mini Card2) A. Connector size: 2 X 26 = 52 Pin B. Connector location: MINICARD1 MINICARD1 MINI PCIE CON REV1 3.3VSB_2 REV2 GND7 Ver:1.2 REV3 1.5V_1 REV4 LED_WPAN# GND14 LED_WLAN# 3.3VSB_5 LED_WWAN# 3.3VSB_4 GND8 GND13...

  • Page 26: External Connector Specification

    3.0 External Connector Specification EXTERNAL CONNECTOR SPECIFICATION User’s Manual...

  • Page 27: Power Input Connector

    3.0 External Connector Specification 3.0 EXTERNAL CONNECTOR SPECIFICATION Power Input Connector A. Connector size: 1 X 3 = 3 Pin B. Connector location: PWR2 C. Connector pin definition Signal DC_IN IGNITION D. VBOX-3200's Power Wiring Diagram User’s Manual Page 3-1...

  • Page 28: Power Button Connector

    3.0 External Connector Specification Power Button Connector A. Connector size: 6 Pin B. Connector location: SW1 PUSH SW_LED_BR C. Connector pin definition Signal Signal PWRBT# PWRBT# LEN_N LED_P DIO Connector A. Connector size: 1 X 8 = 8 Pin B. Connector location: GPIO2 GPIO2 PHOENIX 3.5mm-F-90D User’s Manual...

  • Page 29: Rj45 Connector (Lan0)

    3.0 External Connector Specification C. Connector pin definition Signal +12V GPO1 GPO2 GPI1 GPI2 GPI3 GPI4 RJ45 Connector (LAN0) A. Connector size: RJ45+LED B. Connector location: LAN2 LAN2 Green(R) TD1+ TD1- TD2+ Orange(L) TD2- TD3+ TD3- TD4+ TD4- RJ45+LED-90 C. Connector pin definition Signal Signal LAN0_MDI0P...

  • Page 30: Rj45 Connector (Lan1)

    3.0 External Connector Specification RJ45 Connector (LAN1) A. Connector size: RJ45+LED B. Connector location: LAN1 LAN1 Green(R) TD1+ TD1- TD2+ Orange(L) TD2- TD3+ TD3- TD4+ TD4- RJ45+LED-90 C. Connector pin definition Signal Signal LAN1_MDI0P LAN1_MDI0N LAN1_MDI1P LAN1_MDI2P LAN1_MDI2N LAN1_MDI1N LAN1_MDI3P LAN1_MDI3N LAN1_ACT# LAN1_ACTPW...

  • Page 31: Com Port Connector (Com1)

    3.0 External Connector Specification C. CAT5 connector pin define Signal Signal TD1+ TD1- TD2+ TD3+ TD3- TD2- TD4+ TD4- COM Port Connector (COM1) A. Connector size: DB9 B. Connector location: COM5 COM5 COMP-M-90 C. Connector pin definition (RS-232) Signal Signal COM1_DCD COM1_RXD COM1_TXD...

  • Page 32: Dvi-I Connector (Dp1+Vga)

    3.0 External Connector Specification D. Connector pin definition (RS-422) Signal Signal COM1_TXD- COM1_TXD+ COM1_TXD+ COM1_RXD- E. Connector pin definition (RS-485) Signal Signal COM1_TXD-/RXD- COM1_TXD+/RXD+ DVI-I Connector (DP1+VGA) A. Connector size: DVI-I B. Connector location: DVID2 DVID2 TX0- TX2- TX1- TX0+ TX2+ TX1+ 0/5 Shield...

  • Page 33: Usb Connector (Usb 0/1)

    3.0 External Connector Specification C. Connector pin definition Signal Signal DVI_TX2_N DVI_TX2_P 5VSB_USB +12V_PWR DVI_DDC_CLK DVI_DDC_DATA CRT_VSYNC DVI_TX1_N DVI_TX1_P USB_12N USB_12P +5V_DVI_PWR DVI_HPD DVI_TX0_N DVI_TX0_P CRT_DAC_SDA CRT_DAC_SCL DVI_CLK_P DVI_CLK_N CRT_RED CRT_GREEN CRT_BLUE CRT_HSYNC USB Connector (USB 0/1) A. Connector size: USB TYPEA B.

  • Page 34: Usb Connector (Usb2/3)

    3.0 External Connector Specification 3.10 USB Connector (USB2/3) A. Connector size: USB TYPEA B. Connector location: USB1 USB1 DATA1- DATA- DATA1+ DATA+ MGND MGND MGND MGND 2USB-F-90 C. Connector pin definition Signal Signal 5VSB_USB USB2_N USB2_P 5VSB_USB USB3_N USB3_P 3.11 Audio Connector A.

  • Page 35: Can Pin Assignment

    3.0 External Connector Specification 3.12 CAN Pin Assignment A. Connector size: 6 Pin B. Connector location: SIM1 SIM1 C. Connector pin definition Signal Signal DATA 3.13 UPS/3.5G LED A. Connector size: 2 Layer LED with Housing B. Connector location: LED1 LED1 上...

  • Page 36: Hdd/Acc Led

    3.0 External Connector Specification 3.14 HDD/ACC LED A. Connector size: 2 Layer LED with Housing B. Connector location: LED2 LED2 上 下 LED_RG HOUSING C. Connector pin definition Signal Location ACC_LED_P Down ACC_LED_N HDD_LED_P HDD_LED_N 3.15 CAN BUS Pin Assignment A.

  • Page 37: System Installation

    4.0 System Installation SYSTEM INSTALLATION User’s Manual...

  • Page 38: System Introduction

    4.0 System Installation 4.0 SYSTEM INSTALLATION System Introduction User’s Manual Page 4-1...

  • Page 39: Opening Chassis

    4.0 System Installation Opening Chassis Step1. Unscrew the six screws of the Back Cover as shown in the picture. Step2. Unscrew the six screws of the Front Panel as shown in the picture. User’s Manual Page 4-2...
  • Page 40 4.0 System Installation Step3. Unscrew the six screws of the Rear Panel as shown in the picture. Step4. Open Top Cover as shown in the picture. User’s Manual Page 4-3...
  • Page 41 4.0 System Installation Step5. You can see three connectors connect with mainboard as shown in the picture. COM2 COM3 Step6. Pull up the connector as shown in the picture. User’s Manual Page 4-4...
  • Page 42 4.0 System Installation Step7. You can see Ipexs on the Mini PCIe module connectors as shown in the picture. Step8. Pull up the Ipexs as shown in the picture. User’s Manual Page 4-5...

  • Page 43: Installing Memory

    4.0 System Installation Installing Memory Step 1. Put Memory on this place as shown in the picture. Step 2. Hold the Memory with its notch aligned with the Memory socket of the board and insert it at a 30-degreeangle into the socket as shown in the picture. User’s Manual Page 4-6...
  • Page 44 4.0 System Installation Step 3. Fully insert the module into the socket until a “click” is heard as shown in the picture. Step 4. Press down on the Memory so that the tabs of the socket lock on both sides of the module.
  • Page 45 4.0 System Installation Step 6. Fully insert the module into the socket until a “click” is heard as shown in the picture. Step 7. Press down on the Memory so that the tabs of the socket lock on both sides of the module as shown in the picture.

  • Page 46: Installing Mini Pcie Expansion Card (Pcie 1)

    4.0 System Installation Installing MINI PCIe Expansion Card (PCIe 1) Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture. Step 2. Hold the Module with its notch aligned with the socket of the board and insert it at a 30 degree angle into the socket as shown in the picture.
  • Page 47 4.0 System Installation Step 3. Screw two screws to the holder as shown in the picture. Step 4. Done as shown in the picture. User’s Manual Page 4-10...

  • Page 48: Installing Mini Pcie Expansion Card (Pcie 2, Wifi Module)

    4.0 System Installation Installing MINI PCIe Expansion Card (PCIe 2, Wifi Module) Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture. Step 2. Hold the Module with its notch aligned with the socket of the board and insert it at a 30 degree angle into the socket as shown in the picture.
  • Page 49 4.0 System Installation Step 3. Screw two screws to the holder as shown in the picture. Step 4. Done as shown in the picture. User’s Manual Page 4-12...

  • Page 50: Installing Mini Pcie Expansion Card (Pcie 3, 3G Module Only)

    4.0 System Installation Installing MINI PCIe Expansion Card (PCIe 3, 3G Module only) Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture. Step 2. Hold the Module with its notch aligned with the socket of the board and insert it at a 30 degree angle into the socket as shown in the picture.
  • Page 51 4.0 System Installation Step 3. Screw two screws to the holder as shown in the picture. Step 4. Done as shown in the picture. User’s Manual Page 4-14...

  • Page 52: Installing Internal Antenna Cable

    4.0 System Installation Installing Internal Antenna Cable Step 1. Take the SMA Connector and Plug into IO Panel as shown in the picture. Step 2. Put the Washer into the SMA Connector as shown in the picture. User’s Manual Page 4-15...
  • Page 53 4.0 System Installation Step 3. Put the Oring to SMA Connector and tighten as shown in the picture. Step 4. Done as shown in the picture. User’s Manual Page 4-16...
  • Page 54 4.0 System Installation Step 5. Take the Ipex Connector and press on the wifi module asshown in the picture.(Wifi) Step 6. Take the Ipex Connector and press on the 3G module as shown in the picture. (3G) User’s Manual Page 4-17...
  • Page 55 4.0 System Installation Step 7. Take the Ipex Connector and press on the GPS module as shown in the picture. (GPS, only support passive Antenna) User’s Manual Page 4-18...

  • Page 56: Installing Sim Card

    4.0 System Installation Installing SIM Card Step 1. Use thin stick to push the button as shown in the picture. Step 2. Take the holder away from front panel as shown in the picture. User’s Manual Page 4-19...
  • Page 57 4.0 System Installation Step 3. Put your SIM Card into the holder as shown in the picture. Step 4. Take the SIM card holder and Insert it into the socket as shown in the picture. Attention: Please cut the main power when you insert the SIM. Caution : The SIM card will be not detected.

  • Page 58: Installing Hdd

    4.0 System Installation Installing HDD Step 1. Put the HDD into HDD Holder as shown in the picture. Step 2. Screw two screws on both side as shown in the picture. User’s Manual Page 4-21...
  • Page 59 4.0 System Installation Step 3. Push the HDD Holder into the socket as shown in the picture. Step 4. Fully insert the HDD Holder into the socket until a “click” is heard as shown in the picture. User’s Manual Page 4-22...
  • Page 60 4.0 System Installation Step 5. Tighten to Storage Bracket screws as shown in the picture. User’s Manual Page 4-23...

  • Page 61: System Resource

    5.0 System Resource SYSTEM RESOURCE User’s Manual...

  • Page 62: Ignition Power Management Quick Guide

    5.0 System Resource 5.0 SYSTEM RESOURCE Ignition Power Management Quick Guide Startup/shutdown conditions from the IGNITION signal:  IGNITION startup signal must be valid during 5 sec. (anti noise protection).  IGNITION shutdown – IGNITION signal must be inactive during 5 minutes, then PIC controller initiate Power Button signal (OS must be set to shutdown from the Power...
  • Page 63 / 12hr  Ignition On/Off status detectable by SW  If the ignition is off and the system is still on after 5 minutes, VBOX-3200 will shut down automatically.  If the ignition is turned on again and the power-off delay is in progress, VBOX-3200 will cancel the delay function and will continue to operate normally.

  • Page 64: Gpio & Delay Time Setting

    5.0 System Resource GPIO & Delay Time Setting 5.2.1 GPIO, Delay Time and Ignition Control Register The General Purpose I/O is an interface available on some devices. These can read digital signals from other parts of a circuit, or output to control other devices. At GPIO control register, the GPI is use to receive data, the GPO is set data to send.

  • Page 65: Gpio Programming Procedure

    5.0 System Resource Read Ignition Register & Example Code (pFunc != IntPtr.Zero) UInt32 PortVal; SetPortValType SetPortVal = (SetPortValType)Marshal.GetDelegateForFunctionPointer(pFunc, typeof(SetPortValType)); GetPortValType GetPortVal = (GetPortValType)Marshal.GetDelegateForFunctionPointer(pFunc, typeof(GetPortValType)); SetPortVal(0x4E, 0x87, 1); // Enter Super IO SetPortVal(0x4E, 0x87, 1); // Enter Super IO SetPortVal(0x4E, 0x07, 1); // Select Logic 7 for GPIO SetPortVal(0x4F, 0x06, 1);...

  • Page 66: Wdt Setting

    5.0 System Resource (2) Read Register & Example Code (pFunc != IntPtr.Zero) UInt32 PortVal; SetPortValType SetPortVal = (SetPortValType)Marshal.GetDelegateForFunctionPointer(pFunc, typeof(SetPortValType)); GetPortValType GetPortVal = (GetPortValType)Marshal.GetDelegateForFunctionPointer(pFunc, typeof(GetPortValType)); SetPortVal(0x4E, 0x87, 1); // Enter Super IO SetPortVal(0x4E, 0x87, 1); // Enter Super IO SetPortVal(0x4E, 0x07, 1); // Select Logic 7 for GPIO SetPortVal(0x4F, 0x06, 1);...
  • Page 67 5.0 System Resource Watchdog Timer Function Watch dog timer is provided for system controlling. If time-out can trigger one signal to high/low level/pulse, the signal is depend on register setting. The time unit has two ways from 1sec or 60sec. In pulse mode, there are four pulse widths can be selected (1ms/25ms/125ms/5sec).
  • Page 68 5.0 System Resource 2 Watchdog Timer Programming Procedure (1) Example Code private void button2_Click(object sender, EventArgs IntPtr pFunc = GetProcAddress(hMod, "SetPortVal"); (pFunc != IntPtr.Zero) SetPortValType SetPortVal = (SetPortValType)Marshal.GetDelegateForFunctionPointer(pFunc, typeof(SetPortValType)); SetPortVal(0x266, 0x0A, 1); // Set watchdog timer value is 10 SetPortVal(0x265, 0x32, 1); // Set watchdog timer unit is sec and enable watchdog // SetPortVal(0x265, 0x3A, 1);...

  • Page 69: Gobi2000 Wwan Module Application Note

    5.0 System Resource Gobi2000 WWAN Module Application Note Document Number: VBOX-3200-WWAN-01 1. EQUIPMENT REQUIREMENTS 2. TEST SETUP 3. TEST 4. PASS/FAIL CRITERIA : 1. EQUIPMENT REQUIREMENTS • Sierra Wireless Gobi 2000. • FETnet 3G SIM Card with HSDPA operation. 2. TEST SETUP Figure 1: Install WWAN AP Install WWAN AP and configure the EUT with the latest hardware and software.
  • Page 70 5.0 System Resource Figure 2: Signal of WWAN Module for UTMS Channels. 3. TEST Procedure Power-up the EUT until it has completed its boot up process. Place the EUT in building and check the UMTS/HSDPA signal intensity. Connect to Internet through UMTS/HSDPA channel.
  • Page 71 5.0 System Resource Figure 4: Link State of WWAN Module. Figure 5: Download Test File from Internet. User’s Manual Page 5-10...
  • Page 72 5.0 System Resource 4. PASS/FAIL CRITERIA : PASS Criterion : The signal intensity item of the WWAN module must greater than 3 steps. And download test no any error. Signal intensity item Download complete and no any error User’s Manual Page 5-11...

  • Page 73: Gobi2000 Gps Module Application Note

    5.0 System Resource Gobi2000 GPS Module Application Note Document Number: VBOX-3200-GPS-01 1. EQUIPMENT REQUIREMENTS 2. TEST SETUP 3. TEST 4. PASS/FAIL CRITERIA : 1. EQUIPMENT REQUIREMENTS • Sierra Wireless Gobi 2000. • FETnet 3G SIM Card with HSDPA operation. • GPSview program.
  • Page 74 5.0 System Resource Figure 2: Signal of WWAN Module for UTMS Channels. 3. TEST Out door power-up the EUT until it has completed its boot up process. Place the EUT in building and check the UMTS/HSDPA and GPS signal intensity. Get GPS longitude and latitude;...
  • Page 75 5.0 System Resource Figure 4: Link State of WWAN Module. Figure 5: GPS longitude and latitude information. User’s Manual Page 5-14...
  • Page 76 5.0 System Resource Figure 6: Link to Google Maps. Figure 7: GPSview program test. User’s Manual Page 5-15...
  • Page 77 5.0 System Resource 4. PASS/FAIL CRITERIA : PASS Criterion : We must check two results. One is amount of satellite, and another one is the satellite set and fix time. The amount of satellite must exceed five satellites, and the intensity must exceed 30. The satellite set and fix time must be smaller than 60 sec.

  • Page 78: Bios

    6.0 BIOS BIOS User’s Manual...

  • Page 79: Super Io Configuration

    6.0 BIOS 6.0 BIOS Super IO Configuration Select Serial Port Mode User’s Manual Page 6-1...
  • Page 80 6.0 BIOS Select Power off Delay Time User’s Manual Page 6-2...

  • Page 81: Packing List

    7.0 Packing List PACKING LIST User’s Manual...

  • Page 82: Packing List

    7.0 Packing List 7.0 PACKING LIST Packing List Item Part Number Module Name 663200001000 VBOX-3200-T56N/2GB 370832001100 VBOX-3200 Mount Bracket 351103040250 Screw F Type M3*4L ISO BK 326710039661 CABLING PHOENIX CON MALE 3PIN 324610088661 CABLING PHOENIX CON MALE 8PIN Optional Part No.
  • Page 83 7.0 Packing List HSDPA/UMTS –850/900/1900/2100MHz Quad-band EDGE/GPRS/GSM –850/900/1800/1900MHz Single-band CDMA –1900MHz 578090120091 (MC8090) GPS is Standalone, gpsOne XTRA assistance for enhanced standalone GPS performance, MS-based assisted Supports Voice function (3G Antenna Kit be included) Embedded u-blox6 GPS Mini PCIe Card Very high sensitivity (Tracking Sensitivity: -160 dBm) 50 Channels / Hot Start 1s / Warm Start 28s / Cold Start 28s 570800100109...
  • Page 84 (Only for GOBI Series) 343235002000 GPS-Active-5M GPS Active Antenna 5M / SMA male 221401280005 BAT-3000 Neosonic-Polymer 800mAH 3S1P Battery kit for VBOX-3200 972009720000 Microsoft Windows Embedded Standard 2009 (Windows XP Embedded) 970000750000 Microsoft Windows XP Pro license fee 970007740000 Microsoft Windows®...
  • Page 85 7.0 Packing List User’s Manual Page 7-4...
