Sintrones DSS-1300 User Manual

Small pc with 2nd generation intel core i7/i5/i3 processors

Advertisement

Quick Links

DSS - 1300
nd
Small PC with 2
Generation Intel® Core i7/i5/i3 Processors
User's Guide
DS S - 1300 User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSS-1300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sintrones DSS-1300

  • Page 1 DSS - 1300 Small PC with 2 Generation Intel® Core i7/i5/i3 Processors User’s Guide DS S - 1300 User’s Manual...
  • Page 2 © 2011 SINTRONES Technology Corp. All rights reserved. The information in this user’s guide is provided for reference only. SINTRONES does not assume any liability arising out of the application or use of the information or products described herein. This user’s guide may contain or reference information and products protected by copyrights or patents and does not convey any license under the patent rights of Sintron , nor the rights of others.
  • Page 3: Table Of Contents

    Content Content ........................3 Figures ........................4 Tables ......................... 5 Safety Instructions ...................... 6 Before You Begin ................6 When Working Inside a Computer ............. 7 Preventing Electrostatic Discharge ............ 7 Instructions for Lithium Battery ............8 Voltage Ratings .................. 8 Preface ........................
  • Page 4: Figures

    Figures Figure 1 Front Panel ....................16 Figure 2 Rear Panel ....................18 Figure 3 Mechanical Figures ..................20 Figure 4 Connecting the DVI cable ................21 Figure 5 Connecting USB Mouse & Keyboard ............22 Figure 6 Network Cable with RJ45 Connector ............22 Figure 7 Turing on the System .................
  • Page 5: Tables

    Tables Table 1 D S S- 13 00 Product Specifications ............. 16 Table 2 BIOS Main Menu ..................30 Table 3 BIOS Advanced Menu ................. 31 Table 4 BIOS Advanced Menu – Display Configuration..........32 Table 5 BIOS Advanced Menu – Super I/O Configuration ........33 Table 6 BIOS Advanced Menu –Super IO Configuration –...
  • Page 6: Safety Instructions

    Safety Instructions Before You Begin Before handling the product, read the instructions and safety guidelines on the following pages to prevent damage to the product and to ensure your own personal safety. Refer to the “Advisories” section in the Preface for advisory conventions used in this user’s guide, including the distinction between Warnings, Cautions, Important Notes, and Notes.
  • Page 7: When Working Inside A Computer

    When Working Inside a Computer Before taking covers off a computer, perform the following steps: Turn off the computer and any peripherals. Disconnect the computer and peripherals from their power sources or subsystems to prevent electric shock or system board damage. This does not apply when hot swapping parts.
  • Page 8: Instructions For Lithium Battery

    the component in a computer. Just before unwrapping the antistatic packaging, be sure you are at an ESD workstation or grounded. This will discharge any static electricity that may have built up in your body. When transporting a sensitive component, first place it in an antistatic container or packaging.
  • Page 9: Preface

    NOTE Driver downloads and additional information are available under Downloads on our website: www. sintrones .com Unpacking When unpacking, follow these steps: After opening the box, save it and the packing material for possible future shipment.
  • Page 10: Warranty Policy

    turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
  • Page 11: Maintaining Your Computer

    common carrier in transit. Returns for Warranty must include a Failure Report for each unit, by serial number(s), as well as a copy of the original invoice showing the date of purchase. To reduce risk of damage, returns of product must be in a shipping container. If the original container has been lost or damaged, new shipping containers may be obtained from your dealer’s Customer Service at a nominal cost.
  • Page 12: Power Protection

    Humidity High-humidity can cause moisture to enter and accumulate in the system. This moisture can cause corrosion of internal components and degrade such properties as electrical resistance and thermal conductivity. Extreme moisture buildup inside the system can result in electrical shorts, which can cause serious damage to the system.
  • Page 13 cannot protect against a complete loss of power. Uninterruptible Power Supply Uninterruptible power supply (UPS) systems offer the most complete protection against variations on power because they use battery power to keep the server running when AC power is lost. The battery is charged by the AC power while it is available, so when AC power is lost, the battery can provide power to the system for a limited amount of time, depending on the UPS system.
  • Page 14: Chapter 1 Introduction

    Chapter 1 Chapter 1 Introduction Overview D S S- 13 00 is a surprisingly affordable, space-saving system that will capably serve everyday computing needs and turn your living room into home theater with ease. Featuring the 2nd Generation Intel® Core i7/i5/i3 Processors with Intel® QM67 chipset, it provides the powerful computing and graphic performance with the optimal energy efficiency.
  • Page 15: Product Specifications

    Chapter 1 Product Specifications 200 x 35 x 153.1 mm (WxHxD) Dimensions 1.1 Kg (Net)/2.5 Kg (Gross) Weight Intel® Huron River Platform 2nd Generation Intel® Core™ i3/i5/i7 Processors CPU/ Chipset Intel® QM67 2x DDR3 1066/1333 SO-DIMM up to 8GB 1 x 2.5” SATA HDD or SSD Storage 3x 3.5mm Phone Jack, support 5.1 channel audio output 1x S/PDIF Output...
  • Page 16: System Tour

    Chapter 1 System tour Refer to the figures below to identify the components of the system. Front Panel Figure 1 Front Panel Power Button The power push button allows powering ON and OFF the system. Clear CMOS Button To clear the CMOS, use the tip of a pen to press the button briefly (for less than three seconds).
  • Page 17 Chapter 1 The USB (Universal Serial Bus) port is compatible with USB devices such as keyboards, mouse devices, cameras, and hard disk drives. USB allows many devices to run simultaneously on a single computer, with some peripheral acting as additional plug-in sites or hubs. S/PDIF S/PDIF output for carrying digital audio signals out to the device.
  • Page 18: Figure 2 Rear Panel

    Chapter 1 Rear Panel Figure 2 Rear Panel DC Jack The supplied power adapter converts AC power to DC for use with this jack. Power supplied through this jack supplies power to the PC. To prevent damage to the PC, always use the supplied power adapter. HDMI HDMI connector for display output Display Port...
  • Page 19: Mechanical Dimensions

    Chapter 1 DVI-I DVI-I connector for DVI-D or VGA output D-Sub 9 pin connector for RS-232 connection 3G External Antenna Spared hole on the casing for connecting 3G external antenna WiFi External Antenna Spared hole on the casing for connecting WiFi external antenna D S S- 13 00 User’s Manual...
  • Page 20: Figure 3 Mechanical Figures

    Chapter 1 Mechanical Figures Dimension: 200 x 35 x 153.1 mm (W x H x D) Figure 3 Mechanical Figures D S S- 13 00 User’s Manual...
  • Page 21: Chapter 2 Getting Started

    Chapter 2 Getting Started Setting up your PC Connect the monitor, mouse and keyboard Connecting the monitor Connect the DVI cable from your display to the DVI port. Figure 4 Connect the DVI cable NOTE When the system reboots without connecting the DVI, there might be no image on screen when you insert the DVI cable.
  • Page 22: Figure 5 Connecting Usb Mouse & Keyboard

    Chapter 2 Connecting USB mouse & keyboard Your D S S- 13 00 does not come with a keyboard and mouse, but you can use any USB keyboard or mouse with your computer. Figure 5 Connecting USB mouse & keyboard NOTE Using a third-party USB mouse or keyboard may require software drivers.
  • Page 23: Figure 7 Turing On The System

    Chapter 2 Turning on the system Connect the power adapter cable to the DC jack (DC IN) of the D S S- 13 00 Connect the power cable to the power adapter Connect the power cable to a power outlet Press the power switch on the front panel to turn on the system Figure 7 Turing on the system DS S - 13 00 User’s Manual...
  • Page 24: Connecting Vesa Mount On Ds S- 13 00

    Chapter 2 Connecting VESA Mount on D S S- 13 00 Take out the VESA mounting kit form your package and facing it onto the bottom of D S S- 13 00; then tightening the screws on your D SS - 13 00 as figures shown below.
  • Page 25: Mounting Your Pc To A Monitor

    Chapter 2 Mounting your PC to a monitor Firstly, mount your VESA kit on the backside of the monitor with four screws in the package. Secondly, place the D S S- 13 00 on the VESA mounting kit and then tightening the screws from the holes on both sides of the VESA bracket - make sure the computer is fitting well on the bracket.
  • Page 26: Changing Memory And Mini-Pcie

    Chapter 2 Changing Memory and mini-PCIe Firstly, Opening the cover by loosening the two screws on the bottom of D S S- 13 00 as shown below; Figure 11 Opening the Cover on the Bottom Then you may able to change the DDR SO-DIMM and/or mini-PCIe modules. Figure 12 Bottom view of Main Board Remarks: Please use Full Size Mini-PCIe slot for expansion if you are using 3G module.
  • Page 27: Figure 13 So-Dimm Installation (1)

    Chapter 2 Changing Memory Carefully follow the steps below in order to install the SO-DIMMs: To avoid generating static electricity and damaging the SO-DIMM, ground yourself by touching a grounded metal surface or use a ground strap before you touch the SO-DIMM. Do not touch the connectors of the SO-DIMM.
  • Page 28: Figure 15 Mini-Pcie Installation

    Changing mini-PCIe (1) Place your mini‐PCIe module toward the mini‐PCIe socket.    Figure 15 mini-PCIe Installation (2) Tightening the screw on the hole of the mini‐PCIe module as shown above.    D S S- 13 00 User’s Manual...
  • Page 29: Chapter 3 Ami Bios Setup

    Chapter 3 AMI BIOS Setup Overview This chapter provides a description of the AMI BIOS. The BIOS setup menus and available selections may vary from those of your product. For specific information on the BIOS for your product, please contact with your dealer. NOTE: The BIOS menus and selections for your product may vary from those in this chapter.
  • Page 30: Main Menu

    Main Menu The BIOS Setup is accessed by pressing the DEL key after the Power-On Self-Test (POST) memory test begins and before the operating system boot begins. Once you enter the BIOS Setup Utility, the Main Menu will appear on the screen. The Main Menu provides System Overview information and allows you to set the System Time and Date.
  • Page 31: Advanced Menu

    Advanced Menu Table 3 Advanced Menu BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S e r v e r M g m t S a v e & E x i t A d v a n c e d Onboard LAN1 Controller [Enabled]...
  • Page 32 Table 4 Advanced Menu – Display Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S e r v e r M g m t S a v e & E x i t A d v a n c e d Display Configuration Select the Aperture Size...
  • Page 33 Table 5 Advanced Menu – Super IO Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d Super IO Configuration Set Parameters of Serial Port 1 (COM1)
  • Page 34 Serial Port Options: Disabled, Enabled Change Settings Options: Auto IO=3F8h; IRQ=4; IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=2E8h;...
  • Page 35: Watchdog Timer Configuration

    Table 7 Advanced Menu – Power Management Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S e r v e r M g m t S a v e & E x i t A d v a n c e d Power Management Configuration Select the highest ACPI sleep...
  • Page 36 Table 8 Advanced Menu – CPU Advanced Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d CPU Advanced Configuration Enable/Disable Intel ®...
  • Page 37 Table 9 Advanced Menu – Trusted Computing BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d TPM Configuration Enable or Disable TPM support.
  • Page 38 Table 10 Advanced Menu – SATA Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d SATA Controller(s) [Enabled] Enable or Disable SATA Device.
  • Page 39 Table 11 Advanced Menu – Intel TXT (LT) Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d Intel Trusted Execution technology Configuration Select Screen Intel TXT support only can be enabled / disabled if SMX enabled.
  • Page 40 Intel AMT Options: Disabled, Enabled Intel AMT Setup Prompt Options: Disabled, Enabled BIOS Hotkey Pressed Options: Disabled, Enabled MEBx Selection Screen Options: Disabled, Enabled Verbose MEBx Output Options: Disabled, Enabled Hide Un-Configure ME Confirmation Options: Disabled, Enabled MEBx Debug Message Output Options: Disabled, Enabled Un-Configure ME Options: Disabled, Enabled...
  • Page 41 Table 13 Advanced Menu – USB Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d Enables Legacy USB support.
  • Page 42: Cpu Warning Temperature

    Table 14 Advanced Menu – H/W Monitor BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d PC Health Status CPU Warning Temperature [Disabled]...
  • Page 43: Boot Menu

    Boot Menu Table 15 Boot Menu BIOS SETUP UTILITY M a i n A d v a n c e d S e c u r i t y S a v e & E x i t B o o t Boot Configuration Enables or Disables Quiet Boot option...
  • Page 44: Security Menu

    Security Menu Table 16 Security Menu BIOS SETUP UTILITY M a i n A d v a n c e d B o o t S a v e & E x i t S e c u r i t y Password Description Set Setup Administrator Password...
  • Page 45: Save & Exit Menu

    Save & Exit Menu Table 17 Save & Exit Menu BIOS SETUP UTILITY M a i n A d v a n c e d B o o t S e c u r i t y S a v e & E x i t Save Changes and Exit Exit system setup after saving the changes.
  • Page 46 load the previously saved values. Load Optimal Defaults Load Optimal Default values for all the setup values. This option allows you to load optimal default values for each of the parameters on the Setup menus, which will provide the best performance settings for your system. The F9 key can be used for this operation.
  • Page 47: Chapter 4 Driver Installation

    For other operating systems, please contact with your nearest SINTRONES Sales. D S S- 13 00 User’s Manual...
