Sintrones ABOX-5000PG1 User Manual

Embedded computing
Hide thumbs
Table of Contents

Advertisement

Quick Links

ABOX-5000(P)G1
Embedded Computing
User's Manual
Document Name
ABOX-5000(P)G1 User Manual
Version
1.0
Reversion History :
Reversion
From
To
1.0
Jan. 31, 2018
Version 1.0
Date
Initial document issued
Document No.
Date
Notes
UM2018500020
Jan. 31, 2018
Author(s)
Stanley Chou

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ABOX-5000PG1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sintrones ABOX-5000PG1

Summary of Contents for Sintrones ABOX-5000PG1

  • Page 1 ABOX-5000(P)G1 Embedded Computing User's Manual Version 1.0 Document Name ABOX-5000(P)G1 User Manual Document No. UM2018500020 Version Date Jan. 31, 2018 Reversion History : Reversion Date Notes Author(s) From Jan. 31, 2018 Initial document issued Stanley Chou...
  • Page 2 Other  brands  and  product  names  used  herein are  for  identification  purposes  only  and  may be trademarks of their respective owners.  Disclaimer SINTRONES®  Technology  Corp.  shall  not  be  liable  for  any  incidental  or  consequential  damages resulting from the performance or use of this product.  SINTRONES®  Technology  Corp.  makes  no  representation  or  warranty  regarding  the  content  of  this  manual.  Information  in  this  manual  had  been  carefully  checked  for ...
  • Page 3 Safety Information Read the following precautions before setting up a SINTRONES Product.  Electrical safety  To prevent electrical shock hazard, disconnect the power cable from the electrical  outlet before relocating the system.   When  adding  or  removing  devices  to  or  from  the  system,  ensure  that  the  power  cables  for  the  devices  are  unplugged  before  the  signal  cables  are  connected.  If  possible,  disconnect  all  power  cables  from  the  existing  system  before  you  add  a ...
  • Page 4 CAUTION Incorrectly replacing the battery may damage this computer. Replace only with the same  or its equivalent as recommended by SINTRONES® Technology Corp. Dispose used battery  according to the manufacturer's instructions.    Technical Support Please do not hesitate to call or e‐mail our customer service when you still cannot fix  the problems.  Tel : +886‐2‐82280101  Fax : +886‐2‐82280100  E‐mail : sales@sintrones.com  Website : www.sintrones.com  User’s Manual Page iii...

  • Page 5: Table Of Contents

    1.0 Introduction TABLE OF CONTENTS Page # Introduction ..........................1-1     Model Specification ......................1-1     ABOX‐5000(P)G1 Illustration (MB, System) ..............1-3         Architecture ..........................1-6 Power Consumption ......................1-6     Internal Connector Specification .................... 2-1     Battery Connector (BAT1) ....................2-1     COM Port Connector (COM1/2) ..................
  • Page 6 1.0 Introduction Installing Memory ........................ 4-3     Installing MINI PCIe Expansion Card (Minicard 1, 3G/LTE) ........4-5     Installing MINI PCIe Expansion Card (MiniCard 2) ............4-7     Installing MINI PCIe Expansion Card (MiniCard 3) ............4-9     Installing mSATA Module ....................4-12     Installing Internal Antenna Cable ................... 4-14     Installing SIM Card ......................4-18     4.10 Installing Battery Module ....................4-20  ...

  • Page 7: Introduction

    1.0 Introduction 1.0 INTRODUCTION User’s Manual...

  • Page 8: Model Specification

    2.0 Internal Connector Specification 1.0 INTRODUCTION 1.1 Model Specification System  Intel Gen 7 Core i7‐7700T (8M Cache, up to 3.80 GHz)  Intel Xeon Quad Core E3‐1268L v5 (8M Cache 2.4GHz up to 3.4GHz)  Intel Gen6 Core i7‐6700TE (8M Cache 2.4GHz up to 3.4GHz)  CPU  Intel Gen6 Core i5‐6500TE (6M Cache 2.3GHz up to 3.3GHz)  Intel Gen6 Core i3‐6100TE (4M Cache 2.7GHz)  Intel Pentium Processor G4400TE (3M Cache, 2.40 GHz)  Memory  2 x DDR4 2133 MHz SO‐DIMM up to 32GB  Chipset  Intel® Q170/C236 Platform Controller Hub  5 x Intel i210‐AT and 1 x i219LM (Support iAMT) Gb/s  LAN Chipset  Ethernet Controllers Onboard Support PXE and WOL  Audio  1 x Line‐out, 1 x Mic‐in and Line‐in  Watchdog  1 ~ 255 Level Reset TPM  2.0  Power Requirement  Power Input  9V‐48V DC Power input  Power Protection  Automatics Recovery Short Circuit Protection  Power Management  Vehicle Power Ignition for Variety Vehicle  Power Off Control  Power off Delay Time Setting by BIOS and Software  User’s Manual...
  • Page 9 2.0 Internal Connector Specification Battery  Internal Battery Kit for 10 Mins Operating (Optional)  Storage  2 x 2.5" Drive Bay for SATA Type HDD/SSD, RAID 0,1,5  Type  1 x mSATA  Qualification  Certifications  CE, FCC Class A, E13  Graphics  NVIDIA® GeForce GTX 1050 GPU (768 CUDA Cores)  Graphics  Support for OpenGL 4.5 and OpenCL™ 1.2  Support for DirectX® 12 (Feature Level 12_0) features  Resolution  Max Resolution (HDMI 2.0b) : 7680x3840@60Hz  I/O  Serial Port  4 x RS‐232/422/485 (Auto Direction Control)  USB Port  4 x USB 3.0 Ports  LAN  6 x RJ45 Ports for GbE (Optional for 4 x POE 15.4W per port)  Video Port  7 x HDMI Ports  DIO Port  8 x GPI and 4 x GPO  Audio  1 x Line‐out, 1 x Line‐in and 1 x Mic‐in  3 x Full Mini‐PCIe Slots and 1 x M.2 A‐E Key 2230 Slot (2 x SIM Card  Expansion Bus  Sockets) for LTE/3G, Wifi, Bluetooth, GPS function  Environment  Operating Temp.  ‐40ºC ~ 70ºC  Storage Temp.  ‐40ºC ~ 80ºC ...

  • Page 10: Abox-5000(P)G1 Illustration (Mb, System)

    2.0 Internal Connector Specification ABOX‐5000(P)G1 Illustration (MB, System)   Main Board  User’s Manual...
  • Page 11 2.0 Internal Connector Specification Front I/O        Rear I/O                                    User’s Manual...
  • Page 12 2.0 Internal Connector Specification System  User’s Manual...

  • Page 13: Architecture

    2.0 Internal Connector Specification Architecture GTX‐1050  Power Consumption Chip Description Intel Power consumption: Core Frequency Cache I7-7700T (4C/8T) 3.8 GHz 80°C E3-1268L v5 (4C/8T) 3.4 GHz 100°C i7-6700TE(4C/8T) 3.4 GHz 100°C i5-6500TE(4C/4T) 3.3 GHz 100°C i3-6100TE(2C/4T) 2.7 GHz 100°C G4400TE(2C/2T) 2.4 GHz 100°C User’s Manual...

  • Page 14: Internal Connector Specification

    2.0 Internal Connector Specification 2.0 INTERNAL CONNECTOR SPECIFICATION User’s Manual...

  • Page 15: Battery Connector (Bat1)

    2.0 Internal Connector Specification 2.0 INTERNAL CONNECTOR SPECIFICATION 2.1 Battery Connector (BAT1) Connector size 1 X 2 = 2 Pin Connector type JST-1.25mm-M-180 Connector location BAT1 Connector pin Signal Signal definition +3VDC Connector map User’s Manual Page 2-1...

  • Page 16: Com Port Connector (Com1/2)

    2.0 Internal Connector Specification 2.2 COM Port Connector (COM1/2) Connector size 2 X 5 = 10 Pin Connector type Dual DB9 Connector Connector location COM1/COM2 DB9 pin definition Signal RS232 RS422 RS485 TXD- TXD-/RXD- TXD+ TXD+/RXD+ RXD+ DTR# RXD- DSR# RTS# CTS# Connector map User’s Manual Page 2-2...

  • Page 17: Com Port Connector (Com3/4)

    2.0 Internal Connector Specification 2.3 COM Port Connector (COM3/4) Connector size 2 X 5 = 10 Pin Connector type JST-2.0mm-M-180 Connector location COM3/4 Connector pin Signal Signal definition DSR# RTS# CTS# DB9 pin definition Signal RS232 RS422 RS485 COM2_DCD TXD- TXD-/RXD- COM2_RXD TXD+ TXD+/RXD+ COM2_TXD RXD+...

  • Page 18: Di/Do Connector (Dio1)

    2.0 Internal Connector Specification 2.4 DI/DO Connector (DIO1) Connector size 2 X 8 = 16 Pin Connector type JST-2.0mm-M-180 Connector location DIO1 Connector pin Signal Signal definition DO_1 DO_2 DO_3 DO_4 DI_1 DI_2 DI_3 DI_4 DI_5 DI_6 DI_7 DI_8 CASE_GND DB15MALE pin definition Signal Signal...

  • Page 19: Mcu Down Connector (Mcu_Cn1) 2

    2.0 Internal Connector Specification 2.5 MCU Down Connector (MCU_CN1) Connector size 1 X 4 = 4 Pin Connector type JST-2.0mm-M-180 Connector location MCU_CN1 Connector pin Signal definition MCU_PROGRAM Connector map User’s Manual Page 2-5...

  • Page 20: Power Button Switch (Sw1)

    2.0 Internal Connector Specification 2.6 POWER Button Switch (SW1) Connector size 8 PIN Connector type DIP-Switch Connector location Connector pin Signal definition PWRBTN# PWRBTN# PWRLED_P (RED LED) PWRLED_N (GREEN LED) Connector map User’s Manual Page 2-6...

  • Page 21: Sata Power Connector (Spwr1&2)

    2.0 Internal Connector Specification 2.7 SATA Power Connector (SPWR1&2) Connector size 1 X 4 = 4 Pin Connector type WAFER 2.54mm-M-180 Connector location SPWR1 & 2 Connector pin Signal definition +12V Connector map User’s Manual Page 2-7...

  • Page 22: Sata Connector (Sata 1&2)

    2.0 Internal Connector Specification 2.8 SATA Connector (SATA 1&2) Connector size 1 X 7 = 7 Pin Connector type SATA 1.27mm-M-180D Connector location SATA1&2 Connector pin Signal definition SATA_TXP SATA_TXN SATA_RXN SATA_RXP Connector map User’s Manual Page 2-8...

  • Page 23: Sata Dom Connector (Satadom1)

    2.0 Internal Connector Specification 2.9 SATA DOM Connector (SATADOM1) Connector size 2 X 26 = 52 Pin Connector type MINI PCI-E CON 9.2mmH Connector location mSATA1 Connector pin Signal Signal definition PCIE_WAKE# 3VSB +1.5V SATA_RX_P 3VSB SATA_RX_N +1.5V SATA_TX_P SATA_TX_N USB_D- USB_D+ 3VSB 3VSB +1.5V 3VSB...
  • Page 24 2.0 Internal Connector Specification Connector map User’s Manual Page 2-10...

  • Page 25: Mini Pci-E Connector (Minicard1)

    Connector size 2 X 26 = 52 Pin Connector type MINI PCI-E CON 9.2mmH Connector location MINICARD1 (3G/LTE to SIM1 (default) or switch to SIM 2 (by a Utility*) *check with Sintrones’ sales) Connector pin Signal Signal definition PCIE_WAKE# 3VSB...
  • Page 26 2.0 Internal Connector Specification Connector map User’s Manual Page 2-12...

  • Page 27: Mini Pci-E Connector (Minicard2)

    2.0 Internal Connector Specification 2.11 Mini PCI‐E Connector (MINICARD2) Connector size 2 X 26 = 52 Pin Connector type MINI PCI-E CON 9.2mmH Connector location MINICARD2 (Mini PCI-E spec. V1.2 USB+PCIe function and connect to SIM2 when install LTE/3G module) Connector pin Signal Signal definition PCIE_WAKE#...
  • Page 28 2.0 Internal Connector Specification Connector map User’s Manual Page 2-14...

  • Page 29: Mini Pci-E Connector (Minicard3)

    2.0 Internal Connector Specification 2.12 Mini PCI‐E Connector (MINICARD3) Connector size 2 X 26 = 52 Pin Connector type MINI PCI-E CON 9.2mmH Connector location MINICARD3 (Mini PCI-E spec. V1.2 USB+PCIe function) Connector pin Signal Signal definition PCIE_WAKE# 3VSB +1.5V CLKREQ# CLK_N CLK_P W_DISABLE# PERST# PERn0...
  • Page 30 2.0 Internal Connector Specification Connector map User’s Manual Page 2-16...

  • Page 31: Mini Pci-E Connector (Minicard4)

    2.0 Internal Connector Specification 2.13 Mini PCI‐E Connector (MINICARD4) Connector size 2 X 26 = 52 Pin Connector type MINI PCI-E CON 9.2mmH (Half Size OPT.*) * please contact with Sintrones’ sales Connector location MINICARD4 (Mini PCI-E spec. V1.2) Connector pin Signal Signal...
  • Page 32 2.0 Internal Connector Specification Connector map User’s Manual Page 2-18...

  • Page 33: E Key Connector (Ide1)

    2.0 Internal Connector Specification 2.14 M.2 E KEY Connector (IDE1) Connector size 75 Pin Connector type M.2 A-E KEY 2230 H:8.5mm Connector location IDE1 Connector pin Signal Signal definition 3.3VSB USB_D+ 3.3VSB USB_D- Module Key Module Key Module Key Module Key Module Key Module Key Module Key Module Key PERp0...
  • Page 34 2.0 Internal Connector Specification Connector map User’s Manual Page 2-20...

  • Page 35: Pse Power Board Connector (Pse1)

    2.0 Internal Connector Specification 2.15 PSE Power Board Connector (PSE1) Connector size 2x34=68 Pin Connector type Female 9.05mm pitch=1.27mm Connector location PSE1 Connector pin Signal Signal definition +3.3V 9~48V_VIN +3.3V 9~48V_VIN 9~48V_VIN 9~48V_VIN 9~48V_VIN 9~48V_VIN SMB_CLK 9~48V_VIN SMB_DATA 9~48V_VIN 9~48V_VIN PSE_AGND 9~48V_VIN PDE_INT# 9~48V_VIN PSE_AGND 9~48V_VIN PDE_OUT1...
  • Page 36 2.0 Internal Connector Specification Connector map User’s Manual Page 2-22...

  • Page 37: External Connector Specification

    3.0 External Connector Specification 3.0 EXTERNAL CONNECTOR SPECIFICATION User’s Manual...

  • Page 38: Power Input Connector (Power1)

    3.0 External Connector Specification 3.0 EXTERNAL CONNECTOR SPECIFICATION 3.1 Power Input Connector (POWER1) Connector size 1 X 5 = 5 Pin Connector type Terminal block 5PIN pitch :5.08mm Connector location POWER1 Connector pin definition Signal VIN (9VDC~48VDC) VIN (9VDC~48VDC) IGNITION Connector map User’s Manual Page 3-1...

  • Page 39: Hdmi Port Connector (Hdmi 1/2/3/4/5/6/7)

    3.0 External Connector Specification 3.2 HDMI Port Connector (HDMI 1/2/3/4/5/6/7) Connector size 19 Pin Connector type HDMI port Connector location HDMI 1/2/3/4/5/6/7 Connector pin definition Signal Signal HDMI_DATA2_P HDMI_DATA2_N HDMI_DATA1_P HDMI_DATA1_N HDMI_DATA0_P HDMI_DATA0_N HDMI_CLK_P HDMI_CLK_N CEC(NC) HDMI_SCL HDMI_SDA HDMI_+5V HDMI_HPD Connector map User’s Manual Page 3-2...
  • Page 40 3.0 External Connector Specification User’s Manual Page 3-3...

  • Page 41: Audio Connector (Audio1)

    3.0 External Connector Specification 3.3 AUDIO Connector (AUDIO1) Connector size 1 X 3 Connector type HAD Jack Connector location AUDIO1 Connector pin definition Signal Signal Signal CASE_GND MIC_In_R FRONT_OUT_R LINE_In_R MIC-JD FRONT_JD LINE_JD AUD_GND AUD_GND AUD_GND MIC_In_L FRONT_OUT_L LINE_In_L Connector map User’s Manual Page 3-4...

  • Page 42: Rj45+Usb 3.0 Connector (Usb1&2)

    3.0 External Connector Specification 3.4 RJ45+USB 3.0 Connector (USB1&2) Connector size 28 Pin Connector type USB3.0 Type A Connector location USB1 & 2 Connector pin definition Signal Signal Signal 5VSB 5VSB MDI0_P USB_N USB_N MDI0_N USB_P USB_P MDI1_P MDI1_N SSRX- SSRX- MDI2_P SSRX+ SSRX+ MDI2_N MDI3_P...

  • Page 43: Lan Connector (Lan3/4 & Lan5/6)

    3.0 External Connector Specification 3.5 LAN Connector (LAN3/4 & LAN5/6) Connector size 32 Pin Connector type Dual Port RJ45+LED With PoE Connector location LAN3/4 & LAN5/6 Connector pin definition Signal Signal MDI0P MDI0N MDI1P MDI2P MDI2N MDI1N MDI3P MDI3N DOWN Signal Signal MDI0P MDI0N MDI1P MDI2P MDI2N...
  • Page 44 3.0 External Connector Specification Connector map User’s Manual Page 3-7...
  • Page 45 3.0 External Connector Specification User’s Manual Page 3-8...

  • Page 46: System Installation

    4.0 System Installation 4.0 SYSTEM INSTALLATION User’s Manual...

  • Page 47: System Introduction

    4.0 System Installation 4.0 SYSTEM INSTALLATION 4.1 System Introduction 4.2 Opening Chassis User’s Manual Page 4-1...
  • Page 48 4.0 System Installation Step1. Unscrew the six screws of the Back Cover as shown in the picture.        Step2. Unscrew the three screws of the Front Panel as shown in the picture.        Step3. Unscrew the three screws of the Rear Panel as shown in the picture.    User’s Manual Page 4-2...

  • Page 49: Installing Memory

    4.0 System Installation     Step4. Open Bottom Cover as shown in the picture.        4.3 Installing Memory User’s Manual Page 4-3...
  • Page 50 4.0 System Installation Step1. Put Memory on this place as shown in the picture.        Step2. Hold the Memory with its notch aligned with the Memory socket of the board  and insert it at a 30‐degree angle into the socket as shown in the picture.      Step3. Press down on the Memory so that the tabs of the socket lock on both sides of  the module as shown in the picture.  User’s Manual Page 4-4...

  • Page 51: Installing Mini Pcie Expansion Card (Minicard 1, 3G/Lte)

    4.0 System Installation   4.4 Installing MINI PCIe Expansion Card (Minicard 1, 3G/LTE)   Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture.  User’s Manual Page 4-5...
  • Page 52 4.0 System Installation       Step 2. Hold the Module with its notch aligned with the socket of the  board and insert it at a 30 degree angle into the socket as shown in the picture.      Step 3. Screw one screw to the holder as shown in the picture.    User’s Manual Page 4-6...

  • Page 53: Installing Mini Pcie Expansion Card (Minicard 2)

    4.0 System Installation     Step 4. Done as shown in the picture.    4.5 Installing MINI PCIe Expansion Card (MiniCard 2)   Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture.  User’s Manual Page 4-7...
  • Page 54 4.0 System Installation       Step 2. Hold the Module with its notch aligned with the socket of the board and insert it  at a 30 degree angle into the socket as shown in the picture.      Step 3. Screw one screw to the holder as shown in the picture.    User’s Manual Page 4-8...

  • Page 55: Installing Mini Pcie Expansion Card (Minicard 3)

    4.0 System Installation     Step 4. Done as shown in the picture.    4.6 Installing MINI PCIe Expansion Card (MiniCard 3)   Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture.  User’s Manual Page 4-9...
  • Page 56 4.0 System Installation       Step 2. Hold the Module with its notch aligned with the socket of the board and insert it  at a 30 degree angle into the socket as shown in the picture.      Step 3. Screw one screw to the holder as shown in the picture.    User’s Manual Page 4-10...
  • Page 57 4.0 System Installation     Step 4. Done as shown in the picture.            User’s Manual Page 4-11...

  • Page 58: Installing Msata Module

    4.0 System Installation 4.7 Installing mSATA Module   Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture.      Step 2. Hold the Module with its notch aligned with the socket of the board and insert it  at a 30 degree angle into the socket as shown in the picture.      User’s Manual Page 4-12...
  • Page 59 4.0 System Installation Step 3. Screw one screw to the holder as shown in the picture.        Step 4. Done as shown in the picture.      User’s Manual Page 4-13...

  • Page 60: Installing Internal Antenna Cable

    4.0 System Installation 4.8 Installing Internal Antenna Cable   Step 1. Take the SMA Connector and Plug into IO Panel as shown in the picture.        Step 2. Put the Washer into the SMA Connector as shown in the picture.      User’s Manual Page 4-14...
  • Page 61 4.0 System Installation Step 3. Retaining nut to the to SMA Connector and tighten as shown in the picture.        Step 4. Done as shown in the picture.          User’s Manual Page 4-15...
  • Page 62 4.0 System Installation Step 5. Take the Ipex Connector and press on the wifi module as shown in the  picture.(Wifi)        Step 6. Take the Ipex Connector and press on the 3G module as shown in the picture.  (3G/LTE)      User’s Manual Page 4-16...
  • Page 63 4.0 System Installation Step 7. Take the Ipex Connector and press on the GPS module as shown in the picture.  (GPS)  User’s Manual Page 4-17...

  • Page 64: Installing Sim Card

    4.0 System Installation 4.9 Installing SIM Card   Step 1. Use thin stick to push the button as shown in the picture.        Step 2. Take the holder away from front panel as shown in the picture.      User’s Manual Page 4-18...
  • Page 65 4.0 System Installation Step 3. Put your SIM Card into the holder and take the SIM card holder and Insert it into  the socket as shown in the picture.                                  Attention:  When insert a SIM card to the SIM card holder, please remove the main                                        power at input to avoid undetectable SIM card.     ...

  • Page 66: Installing Battery Module

    4.0 System Installation 4.10 Installing Battery Module   Step 1. Put the battery on the back cover        Step 2. Screw two screws as shown in the picture.      User’s Manual Page 4-20...
  • Page 67 4.0 System Installation Step 3. Done as shown in the picture.        Step 4. Connect the battery with motherboard on UPS location          User’s Manual Page 4-21...

  • Page 68: Installing Hdd

    4.0 System Installation 4.11 Installing HDD   Step 1. Put the HDD into HDD Holder as shown in the picture. Step 2. Screw two screws on both side as shown in the picture. User’s Manual Page 4-22...
  • Page 69 4.0 System Installation Step 3. Push the HDD Holder into the socket as shown in the picture. Step 4. Fully insert the HDD Holder into the socket until a “click” is heard as shown in the picture. User’s Manual Page 4-23...
  • Page 70 4.0 System Installation Step 5. Tighten to Storage Bracket screws as shown in the picture. User’s Manual Page 4-24...

  • Page 71: Installing Poe Module

    4.0 System Installation 4.12 Installing POE Module   Step 1. Put POE Module on this place as shown in the picture.          Step 2. Unscrew the four screws of the motherboard as shown in the picture      User’s Manual Page 4-25...
  • Page 72 4.0 System Installation Step 3. Screw the four hex standoff of the motherboard as shown in the picture        Step 4. Put the POE‐8P module on the motherboard as shown in the picture            User’s Manual Page 4-26...
  • Page 73 4.0 System Installation Step 5. Screw the four screws as shown in the picture        Step 6. Done as shown in the picture          User’s Manual Page 4-27...

  • Page 74: Installing M.2 Module

    4.0 System Installation 4.13 Installing M.2 Module   Step 1. Put M.2 Module on this place as shown in the picture.        Step 2. Unscrew the one screw of the motherboard as shown in the picture      User’s Manual Page 4-28...
  • Page 75 4.0 System Installation Step 3. Screw the one hex standoff of the motherboard as shown in the picture        Step 4 Hold the Module with its notch aligned with the socket of the board and insert it  at a 30 degree angle into the socket as shown in the picture.          User’s Manual Page 4-29...
  • Page 76 4.0 System Installation Step 5. Screw one screw to the holder as shown in the picture.        Step 6. Take the Ipex Connector and press on the M.2 module as shown in the picture.  User’s Manual Page 4-30...
  • Page 77 4.0 System Installation User’s Manual Page 4-31...

  • Page 78: Bios

    5.0 BIOS 5.0 BIOS User’s Manual...

  • Page 79: Enter The Bios

    5.0 BIOS 5.0 BIOS 5.1 Enter The BIOS Power on the computer and the system will start POST (Power On Self Test) process.  When the message below appears on the screen, press (DEL) key to enter Setup.    Press DEL to enter SETUP If the message disappears before you respond and you still wish to enter Setup, restart  the system by turning it OFF and On or pressing the RESET button. You may also restart  the system by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys.    Important   The items under each BIOS category described in this chapter are under continuous  update  for  better  system  performance.  Therefore,  the  description  may  be  slightly  different from the latest BIOS and should be held for reference only.   Upon boot‐up, the 1st line appearing after the memory count is the BIOS version. It  is usually in the format.    ABOX‐5000(P)G1 Mainboard V1.0 073109 where : 1st digit refers to BIOS maker as A = AMI, W = AWARD, and P = PHOENIX  2nd ‐ 5th digit refers to the model number.  6th digit refers to the chipset as I = Intel, N = NVIDIA, A = AMD and V = VIA.  7th ‐ 8th digit refers to the customer as MS = all standard customers.  V1.0 refers to the BIOS was released.  073109 refers to the date this BIOS was released.  User’s Manual Page 5-1...
  • Page 80 5.0 BIOS Control Keys Power on the computer and the system will start POST (Power On Self Test) process.  When the message below appears on the screen, press (DEL) key to enter Setup.    <↑>  Move to the previous item  <↓>  Move to the next item  <←>  Move to the item in the left hand  <→>  Move to the item in the right hand <Enter>  Select the item  <Esc>  Jumps to the Exit menu or returns to the main menu from a submenu  <+/PU>  Increase the numeric value or make changes <‐/PD>  Decrease the numeric value or make changes  <F1>  General Help  <F3>  Load Optimized Defaults  <F4>  Save all the CMOS changes and exit    Getting Help After entering the Setup menu, the first menu you will see is the Main Menu.    Main Menu  The main menu lists the setup functions you can make changes to. You can use the arrow  keys (↑↓) to select the item. The on‐line description of the highlighted setup function is  displayed at the bottom of the screen.    Sub‐Menu  If you find a right pointer symbol (as shown in the right view) appears to the left of certain  fields  that  means  a  sub‐menu  can  be  launched  from  this  field.  A  sub‐menu  contains  addi onal op ons for a field parameter. You can use arrow keys ( ↑↓ ) to highlight the ...

  • Page 81: Main

    5.0 BIOS 5.2 Main Time Setting » System Date  This setting allows you to set the system Date. The time format is <Day> <Month> <Date>  <Year>.    » System Time  This setting allows you to set the system time. The time format is <Hour> <Minute> <Second>.              User’s Manual Page 5-3...

  • Page 82: Advanced

    5.0 BIOS 5.3 Advanced AMT Configuration         Serial Port Configuration User’s Manual Page 5-4...
  • Page 83 5.0 BIOS     » Serial Port 1/2/3/4 Enable or Disable  Select an Enable or Disable for the specified serial ports.    » COM1 RS232/422/485 Select          User’s Manual Page 5-5...
  • Page 84 5.0 BIOS » Watch Dog Function                                    User’s Manual Page 5-6...

  • Page 85: Chipset

    5.0 BIOS 5.4 Chipset RAID Mode User’s Manual Page 5-7...
  • Page 86 5.0 BIOS User’s Manual Page 5-8...

  • Page 87: Boot

    5.0 BIOS 5.5 Boot » 1st/2nd Boot Device  The items allow you to set the sequence of boot devices where BIOS attempts to  load the disk operating system.    » Try Other Boot Devices  Setting the option to [Enabled] allows the system to try to boot from other device if  the system fail to boot from the 1st/2nd boot device.    » Hard Disk Drives, CD/DVD Drives, USB Drives  These settings allow you to set the boot sequence of the specified devices.                  User’s Manual Page 5-9...

  • Page 88: Packing List

    6.0 Packing List 6.0 PACKING LIST User’s Manual...

  • Page 89: Packing List

    6.0 Packing List 6.0 PACKING LIST 6.1 Packing List System  Item  Part Number  Module Name  1  765000040009  ABOX‐5000G1‐i7 System  2  765000040010  ABOX‐5000PG1‐i7 System  3  765000040015  ABOX‐5000G1‐C1 System  4  765000040016  ABOX‐5000PG1‐i7K System    Accessory  Picture  Part Number Module Name Q’ty 326510051061  Cabling MC101‐508‐05GA1 F 90D  1    370850001000  ABOX‐5000 MOUNT BRACKET  2    351103040250  Screw F Type M3*4L ISO BK  4   ...
