C. Connector pin definition
Pin
1 +12V
2 GND
3 GPO1
4 GPO2
5 GPI1
6 GPI2
7 GPI3
8 GPI4
3.4

RJ45 Connector (LAN0)

A. Connector size: RJ45+LED
B. Connector location: LAN2
C. Connector pin definition
Pin
1 LAN0_MDI0P
3 LAN0_MDI1P
5 LAN0_MDI2N
7 LAN0_MDI3P
9 LAN0_ACT#
11 LAN0_LINK#
User's Manual
Signal
LAN2
Green(R)
1
TD1+
2
TD1-
3
TD2+
6
Orange(L)
TD2-
4
TD3+
5
TD3-
7
TD4+
8
TD4-
RJ45+LED-90
Signal
12
L1
11
L2
10
L3
9
L4
H1
MG1
H2
MG2
H3
NH1
H4
NH2
Pin
2 LAN0_MDI0N
4 LAN0_MDI2P
6 LAN0_MDI1N
8 LAN0_MDI3N
10 LAN0_ACTPW
12 LAN0_LINKPW
3.0 External Connector Specification
Signal
Page 3-3
