578090120091
570800100109
570800100101 VDB-800DR
570800160009 VDB-800SG
346123002001
User's Manual
HSDPA/UMTS –850/900/1900/2100MHz
Quad-band EDGE/GPRS/GSM –850/900/1800/1900MHz
Single-band CDMA –1900MHz
(MC8090) GPS is Standalone, gpsOne XTRA assistance for enhanced
standalone GPS performance, MS-based assisted
Supports Voice function
(3G Antenna Kit be included)
Embedded u-blox6 GPS Mini PCIe Card
Very high sensitivity (Tracking Sensitivity: -160 dBm)
50 Channels / Hot Start 1s / Warm Start 28s / Cold Start 28s
VDB-800S AssistNow Online and Offline A-GPS Services,OMA SUPL Compliant
Support NMEA 0183 V3.0
Update Rate 5 Hz (Max.)
(GPS Active Antenna be included)
Embedded u-blox6 GPS with
PCIe Card
Very high sensitivity (Tracking Sensitivity: -160 dBm)
50 Channels / Hot Start 1s / Warm Start 40s / Cold Start 45s
Support NMEA 0183 V3.0
AssistNow Online and Offline A-GPS Services, OMA SUPL Compliant
100% Coverage with Continuous Position Fixes Even in Tunnels
Highly Accurate and Reliable Navigation Performance
Automatic Sensor Calibration and Temperature
Include odometer cable.
(GPS Active Antenna be included)
Embedded u-blox6 GPS Mini PCIe Card and
Very high sensitivity (Tracking Sensitivity: -160 dBm)
50 Channels / Hot Start 1s / Warm Start 28s / Cold Start 28s
AssistNow Online and Offline A-GPS Services,OMA SUPL Compliant
Support NMEA 0183 V3.0
Update Rate 5 Hz (Max.)
(GPS Active Antenna be included)
50-channel u-blox6 Engine with Over 2 Million Effective Correlators
146dBm SuperSense® Acquisition and Tracking Sensitivity
AssistNow Online and Offline A-GPS Services,OMA SUPL Compliant
VDB-801 100% Coverage with Continuous Position Fixes Even in Tunnels
Highly Accurate and Reliable Navigation Performance
Automatic Sensor Calibration and Temperature
Operating Temperature : -40ºC to 80ºC
Dead Reckoning and
G-sensor
7.0 Packing List
G-sensor Mini
Page 7-2
