- Page 1 SBOX-2150 Fanless Box Computing User's Manual Version 1.0 Document Name SBOX-2150 User Manual Document No. UM2012215010 Version Date Aug. 27, 2012 Reversion History : Reversion Date Notes Author(s) From Aug. 27, 2012 Initial document issued Stanley Chou...
-
Page 2: User Manual
Disclaimer SINTRONES® Technology Corp. shall not be liable for any incidental or consequential damages resulting from the performance or use of this product. SINTRONES® Technology Corp. makes no representation or warranty regarding the content of this manual. -
Page 3: Safety Information
Safety Information Read the following precautions before setting up a SINTRONES Product. Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. -
Page 4: Table Of Contents
TABLE OF CONTENTS 1 Function Introduction 1.1 Model Specifications..................6 1.2 SBOX-2150 Illustration <Mainboard, System> ..........7 1.3 Architecture ......................9 1.4 Principal Component Specification <CPU, South Bridge> ......10 1.5 Memory Module Installation ................11 1.6 Internal Connector Specification ..............12 ■ VGA Connector ...................12 ■... - Page 5 TABLE OF CONTENTS 3 BIOS 3.1 Entering The BIOS ..................41 3.2 Main ........................43 3.3 Advanced .......................44 3.4 Boot ........................50 3.5 Security ......................51 3.6 Chipset ......................52 3.7 Exit .........................54 4 Packing List 4.1 Packing List ....................55...
-
Page 6: Function Introduction
1 Function Introduction 1.1 Model Specifications • Intel Cedarview Atom D2550 Dual Core 1.86GHz Chipset • Intel NM10 Memory • 1 x DDRIII-1066 SO-DIMM Up to 4GB Display • Intel GMA3650 • 1 x Serial ATA port with 150MB/s HDD transfer rate LAN Chipset •... -
Page 7: Sbox-2150 Illustration
Relative Humidity • 10 ~ 95% @ 40°C (non-condensing) Power Input • DC 12V Input Construction • Aluminum alloy Mounting • Supports both of wall-mount/VESA-mount Weight • 1200g (barebone) Dimensions • 182 x 167.6 x 40mm 1.2 SBOX-2150 Illustration Mainboard... - Page 8 System...
-
Page 9: Architecture
1.3 Architecture... -
Page 10: Principal Component Specification
1.4 Principal Component Specification South Bridge... -
Page 11: Memory Module Installation
1.5 Memory Module Installation The SBOX-2150 provide one 204pins SODIMM slot for DDR3 1066MHz SDRAM memory modules and supports memory sizes up to 4GB. These DIMM slots are inteded for memory modules. DDR3 SO-DIMM Slot 204-pin, 1.5V Installing Memory Module 1. -
Page 12: Internal Connector Specification
1.6 Internal connector specification... -
Page 30: External Connector Specification
1.7 External connector specification... -
Page 35: System Installation
2 System Installation 2.1 System Introduction COM2 Port COM3 Port COM4 Port Line Out USB2.0 Port Power Button Power LED LAN Port COM1 Port USB2.0 Port DC 12V Input External Antenna... -
Page 36: Opening Chassis
2.2 Opening Chassis Step 1. Unscrew the four screws of the Mounting Bracket as shown in the picture. Step 2. Unscrew the four screws of the Back Cover and the four screws of Rear/Front Panel as shown in the picture. Step 3. -
Page 37: Installing Memory
2.3 Installing Memory Step 1. Put Memory on this place as shown in the picture. Step 2. Hold the Memory with its notch aligned with the Memory socket of the board and insert it at a 30-degree angle into the socket as shown in the picture. -
Page 38: Installing Hdd/Ssd
2.4 Installing HDD / SSD Step 1. Put the HDD/SSD on the Back Cover as shown in the picture. Step 2. Turn over the Back Cover and screw the four screws of the Back Cover as shown in the picture. -
Page 39: Installing Mini Pci Express Expansion Card
2.5 Installing MINI PCI Express Expansion Card Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture. Step 2. Hold the Module with its notch aligned with the socket of the board and insert it at a 30 degree angle into the socket as shown in the picture. -
Page 40: Installing Mini Pci Express Expansion Card
2.6 Installing MINI PCI Express Expansion Card Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture. Step 2. Hold the Module with its notch aligned with the socket of the board and insert it at a 30 degree angle into the socket as shown in the picture. -
Page 41: Bios
• Upon boot-up, the 1st line appearing after the memory count is the BIOS version. It is usually in the format. SBOX-2150 Mainboard V1.0 073109 where : 1st digit refers to BIOS maker as A = AMI, W = AWARD, and P = PHOENIX 2nd - 5th digit refers to the model number. -
Page 42: Control Keys
Control Keys Power on the computer and the system will start POST (Power On Self Test) process. When the message below appears on the screen, press (DEL) key to enter Setup. <↑> Move to the previous item <↓> Move to the next item <←>... -
Page 43: Main
3.2 Main System Time This setting allows you to set the system time. The time format is <Hour> <Minute> <Second>. System Date This setting allows you to set the system Date. The time format is <Day> <Month> <Date> <Year>. -
Page 44: Advanced
3.3 Advanced CPU Configuration ... - Page 45 » Max CPUID Value Limit The Max CPUID Value Limit BIOS feature allows you to circumvent problems with older operating systems that do not support the Intel Pentium 4 processor with Hyper-Threading Technology. When enabled, the processor will limit the maximum CPUID input value to 03h when queried, even if the processor supports a higher CPUID input value.
- Page 46 PCI/ PCIE Device Configuration ...
-
Page 47: Super Io Configuration
Super IO Configuration » Serial Port 0/1/2/3/4/5 Enable or Disable Select an Enable or Disable for the specified serial ports. » Serial Port 0 Mode The settings specify the RS-232/RS-422/RS-485 mode of the serial prot 0. -
Page 48: Hardware Health Configuration
Hardware Health Configuration These items display the current status of all monitored hardware devices/components such as voltages, temperatures and all fans' speeds. - Page 49 GPIO Configuration » GPO 0/ 1/ 2/ 3/ Data These settings configure special GPIO data.
-
Page 50: Boot
3.4 Boot » 1st/2nd/3rd Boot Device The items allow you to set the sequence of boot devices where BIOS attempts to load the disk operating system. » Try Other Boot Devices Setting the option to [Enabled] allows the system to try to boot from other device if the system fail to boot from the 1st/2nd/3rd boot device. -
Page 51: Security
3.5 Security » Administrator Password Administrator Password controls access to the BIOS Setup utility. These settings allow you to set or change the administrator password. » User Password User Password controls access to the system at boot. These settings allow you to set or change the user password. -
Page 52: Chipset
3.6 Chipset... - Page 53 » Select Graphic Output Mode...
-
Page 54: Exit
3.7 Exit » Save Changes and Exit Save changes to CMOS and exit the Setup Utility. » Discard Changes and EXit Abandon all changes and exit the Setup Utility. » Discard Changes Abandon all changes and continue with the Setup Utility. »... -
Page 55: Packing List
4 Packing List 4.1 Packing List Part Number Module Name 762120011000 SBOX-2150 370821201000 SBOX-2150 Mount Bracket 548201206001 Power Adapter 12V/5A 60W Jack Option 514001105200 Memory 1GB SO-DIMM DDR3 1333 514002105200 Memory 2GB SO-DIMM DDR3 1333 514004105200 Memory 4GB SO-DIMM DDR3 1333 521340012200 HDD WD 160GB SATA HDD/5400/8MB/12ms, 9.5mm...
