1.0 INTRODUCTION
1.1
Model Specification
System
CPU
Memory
Chipset
Graphics
LAN Chipset
Audio
Watchdog
Power Requirement
Power Input
Power Protection
Power Management
Power Off Control
Battery
User's Manual
AMD G-T56N Dual Core 1.6GHz
AMD G-T40N Dual Core 1.0GHz
AMD G-T44R Single Core 1.2GHz (Optional)
2 x DDR3 1333MHz SO-DIMM up to 8GB
AMD A55E Controller Hub
AMD G-T56N Radeon HD 6310 / G-T44R Radeon HD 6250
2 x Realtek RTL8111E Gb/s Ethernet onboard
Support PXE
Realtek ALC662 HD Codec onboard
1 ~ 255 Level Reset
9V-32V DC Power input
Automatics Recovery Short Circuit Protection
Vehicle Power Ignition for Variety Vehicle
Power off Delay Time Setting by Software
Internal Battery Kit for 10 Mins Operating (Optional)
1.0 Introduction
Page 1-1
