2.3

COM Port JST Connector (COM2)

A. Connector size: 2 X 5 = 10 Pin
B. Connector location: COM2
C. Connector pin definition
Pin
1 COM4_DCD#
3 COM4_TXD
5 GND
7 COM4_RTS#
9 COM4_RI#
2.4

COM Port JST Connector (COM3)

A. Connector size: 2 X 5 = 10 Pin
B. Connector location: COM3
C. Connector pin definition (RS-232)
Pin
1 COM2_DCD
3 COM2_TXD
5 GND
7 COM2_RTS
9 COM2_RI/+5V/+12V
User's Manual
COM1
1
3
5
7
9
JST-2.0mm-M-180
Signal Pin
10
COM3
1
3
5
7
9
JST-2.0mm-M-180
Signal Pin
10
2
4
6
8
10
Signal
2 COM4_RXD
4 COM4_DTR#
6 COM4_DSR#
8 COM4_CTS#
GND
2
4
6
8
10
Signal
2 COM2_RXD
4 COM2_DTR
6 COM2_DSR
8 COM2_CTS
GND
2.0 Internal Connector Specification
Page 2-2
