3.12 CAN Pin Assignment

A. Connector size: 6 Pin
B. Connector location: SIM1
C. Connector pin definition
Pin
C1
VCC
C2
RST
C3
CLK
SW1
GND

3.13 UPS/3.5G LED

A. Connector size: 2 Layer LED with Housing
B. Connector location: LED1
C. Connector pin definition
Pin
A1
3.5G_LED_P
C1
3.5G_LED_N
A2
UPS_LED_P
C2
UPS_LED_N
User's Manual
SIM1
C5
GND
C6
VPP
C7
I/O
W2
SW2
Signal
SW2
LED1
C2
C1
LED_RG
HOUSING
Signal
C1
VCC
C2
RST
C3
CLK
SW
SW1
Pin
Signal
C5
GND
C6
VPP
C7
DATA
GND
A2
A1
Location
Down
UP
3.0 External Connector Specification
Page 3-9
