Ribbing service check

Light print occurs in right or left side of image.
Problem area
1 Printer is not level
2 Toner cartridge
3 Toner cartridge
4 Rear cover assembly
5 Photodeveloper cartridge
Action
Table printer is sitting on is slightly tilted.
Tilt should be less than 1/2 inch.
Confirm the printer table is large enough and the printer is
level.
insufficient amount of toner in the toner cartridge.
Shake the toner cartridge horizontally several times to level
the toner.
Toner in the toner cartridge is not level and collects on one
side.
Shake the toner cartridge horizontally several times to level
the toner. If problem persists, replace toner cartridge.
Open rear cover assembly, and close properly.
Photodeveloper OPC belt is off rack and becomes deformed
during operation.
Replace photodeveloper cartridge. See
cartridge removal" on page
Note: Photodeveloper cartridge is a customer order supply.
7100-XXX
"Photodeveloper
4-8.
