7100-XXX

Maintenance mode

Maintenance mode contains information and settings that can be used in servicing the X5xx series MFPs.
The maintenance mode menu is entered by holding down the
items in maintenance mode are accessed by using the
each item, and pressing the
WARNING: These settings should not be used without the supervision of your secondary support center.

Display info

The default menu displayed when in maintenance mode is the Display info menu. To select this menu item,
press the key. The Display info menu item contains printer-specific information. The information in this
menu is described below. Press
Model Name
Model Name is the default menu item in the Display info submenu.This item displays the MFP model
name. The options are X500, and X502. This item cannot be changed. Press
FW Version
The FW Version submenu displays three different firmware related items. While in the Display info menu,
use the and
Version menu items are accessed by using the
item.
CTL FW Ver
CTL FW Ver displays the system board firmware version. It cannot be changed in the menu. This is the
default menu item in the FW Version submenu. Press
Fax FW Ver
The second item is Fax FW Ver which displays the fax firmware version. It cannot be changed in the menu.
Press to exit this item.
MCTL FW Ver
The third item is MCTL FW Ver which displays the engine controller board firmware version. It cannot be
changed in the menu. Press
Press to go back up to the Display info menu.
3-4
Service Manual
to select the item. Press the
to exit this menu.
keys to navigate to FW Version and press the
to exit this item.
Lexmark confidential until announce edited 1/4/2007
key when performing a POR. The various
and keys to navigate within a submenu to
key to move up a level.
key to enter the submenu. FW
and keys to navigate within the submenu to each
to exit this item.
to exit this item.
