Installing the Processor

To install a processor, follow these instructions:
1. Observe the safety and ESD precautions at the beginning of this book. See
Information" on page
2. Power down the server and unplug all peripheral devices and the AC power cable.
3. Remove the server system cover. For instructions, see
System Cover" on page
4. Locate the processor socket and raise the socket handle completely. See
5. Push the rear tab with your finger to slightly lift the front of the load plate. Raise the
load plate completely. Raise the CPU load plate (see
Caution: Do not touch the socket pins; they are very sensitive and easily damaged.
34
iii.
24.

Figure 22. Lifting the Processor Socket Handle

A

Figure 23. Opening the Load Plate

®
Intel
"Removing the Server
AF000528
Figure
B
Server System SR1530SH/SR1530HSH User's Guide
"Safety
Figure 22.
23).
AF000529
