Internal Components (SR1530HSH)
M
A.
Rack Handles (two)
B.
PCI Air Baffle
C.
System Blower Fans (two)
D.
Processor Air Duct
E.
Server Board
F.
PCIe* Riser Assembly
G.
Processor and Heat Sink
®
Intel
Server System SR1530SH/SR1530HSH User's Guide
C
B
A
L
K
J
Figure 7. System Components (SR1530HSH)
F
E
D
I
A
H.
Power Supply
I.
Front Panel Board
J.
Front Panel
K.
Hard Drive Carriers (two)
L.
Slimline Optical Drive Bay
M. Hard Drive Carrier (one)
G
H
AF002315
11
