PART 2: CX-Server PLC Tools
CHAPTER 2 – PLC Memory Component
Use the following procedure to copy or move information from or in the PLC Memory component.
1, 2, 3...

PLC Memory Preferences

PLC Memory component preferences permits the setting of display properties for data monitoring.
The Display tab defines the preferred display format. Use the following procedure to change the display format
preference:
1, 2, 3...
The Monitoring tab allows the monitor update interval preference to be amended. Use the following procedure to
change the monitor update interval preference.
1, 2, 3...
The General tab permits the setting of general preferences. Use the following procedure to change the general
preferences.
1, 2, 3...
CX-Server PLC Tools_Page 16
3. Select the appropriate pushbutton to view the printout.
♦
Select the Next Page pushbutton to view the next page of the printout;
♦
Select the Prev Page pushbutton to view the next page of the printout;
♦
Select the Two Page pushbutton to view two pages of the printout at once;
♦
Select the Zoom In pushbutton to zoom in to the page;
♦ Select the Zoom Out pushbutton to zoom out from the page;
♦
Select the Print pushbutton to print from the preview.
♦
Select the Close pushbutton to close the preview window.
4. Select the Print button from the toolbar. A standard Print dialog is displayed.
5. Set up the required printer settings. Select the OK pushbutton to print the PLC Memory
details or the Cancel pushbutton to abort the operation.
Note: Printer specific settings can be applied prior to printing the PLC Memory details, by
selecting Print Setup from the File menu.
1. Select an item or items in a window.
2. Select the Copy button from the toolbar to copy the item, or the Cut button from the
toolbar to move the item.
3. Select an area to move the items to, for instance copying data area values into another data
area.
4. Select the Paste button from the toolbar to paste the item. A Paste operation can be
performed several times without copying again.
1. Select the Preferences option from the View menu.
2. Select the appropriate word display format option, either Binary, Binary Coded Decimal,
Decimal, Signed Decimal, Floating Point, Hexadecimal, Double Floating Point or Text.
3. Select the appropriate bit display format option, either Text or Numeric.
4. If required, select the appropriate font using the Change Font pushbutton.
5. Select the OK pushbutton to accept the settings or the Cancel pushbutton to abort the
operation.
1. Select the Preferences option from the View menu.
2. Select the Monitoring tab.
3. Select a Monitor Update Interval and an associated Unit from the fields.
4. Select the OK pushbutton to accept the settings or the Cancel pushbutton to abort the
operation.
1. Select the Preferences option from the View menu.
2. Select the General tab.
3. Select the Automatically Resize Column Widths option to ensure that all values remain
visible within the data area window irrespective of their display format. It is best practise
for this option to be set OFF when monitoring large data areas.
