Omron CX-PROGRAMMER V9 Operation Manual page 164

OMRON
4 A list of all address_ comment followed by name_address_comment combinations with symbol
Note: If the drop-down list is displayed without any search item input in the Symbol/Address Input field, all
5 Select one of the symbols from the drop-down list and click the Enter Key or the OK Button to
Symbol Filtering Targets
Target Symbol Table:
Target Symbol (Data Type):
names or I/O comments containing the specified text string will be displayed.
symbols that can be used will be listed.
input the selected symbol in the Symbol/Address Input field.
• When a symbol or address containing a symbol name is selected, the symbol is entered in the
Symbol/Address Input field.
• When an address_comment without a symbol name is selected, the address is entered in the
Symbol/Address Input field.
Provides the symbols/addresses registered in the global symbol
table and the local symbol table for the current program.
Note: When a symbol with the same symbol name is registered
in both the local symbol table and global symbol table,
only the symbol registered in the local symbol table will be
displayed in the drop-down list.
The target symbols are BOOL type ones for BOOL type operands
and ones with data types other than BOOL for CHANNEL type
operands.
PART 1: CX-Programmer
CHAPTER 4 – Reference
CX-Programmer _Page 81
