• Password Protection of Function Blocks
Previous version (Ver. 6.0)
The function block properties could be set to
prevent the display of a function block
definition's program.
Starting the Switch Box Utility with PLC Information
Previous version (Ver. 6.0)
The Switch Box Utility could be started from
the CX-Programmer's Tools Menu, but the
PLC model and communications settings
could not be inherited in that case.
Saving the CPU Unit's Error Log as a CSV File
Previous version (Ver. 6.0)
The CPU Unit's error log could not be saved.
Displaying Current Consumption in the I/O Table Window
Previous version (Ver. 6.0)
The current consumption for the 5 V system
could not be separated from the 26 V/24 V
system in the I/O table window's current
consumption display. The total current
consumption at the different voltages could
not be separated. There was no total power
consumption display.
Displaying Unit Versions in the I/O Table Window
Previous version (Ver. 6.0)
The I/O table window's Unit profile information
display showed only the model number and
did not show the unit version.
USB Supported as a Network Type
Previous version (Ver. 6.0)
USB was not available as a network type.
CP1H Memory Cassette Transfers and Flash Memory Backup Functions
Previous version (Ver. 6.0)
The CP1H CPU Units were not supported.
New version (Ver. 6.1)
The following two kinds of password protection can be set.
• Password protection restricting both reading and writing.
• Password protection restricting writing only.
New version (Ver. 6.1)
The Switch Box Utility can start with the PLC model and
communications settings set in the CX-Programmer's project.
New version (Ver. 6.1)
The CPU Unit's error log can be saved as a CSV file. The data
collected in these CSV files can be analyzed or printed later with
programs such as MS Excel.
New version (Ver. 6.1)
The current consumption display in the I/O table window is divided into
5 V and 26 V/24 V system displays. A total power consumption display
was also added.
New version (Ver. 6.1)
The unit version was added to the I/O table window's Unit profile
information display in addition to the model number.
New version (Ver. 6.1)
As part of the CP Series support upgrade, USB is supported as a
network type for the connection between the computer and PLC. This
improvement allows the computer's USB port to be connected to the
PLC's USB port. In addition, if the computer supports automatic online
USB connections, this function can be used.
Note: This function can be used only with the CP Series PLCs, which
are equipped with USB port.
New version (Ver. 6.1)
When the PLC model is set to CP Series CP1H, it is possible to
transfer and verify data between a Memory Cassette and the CP1H
CPU Unit. The contents of Data Memory in the CPU Unit's RAM can
also be backed up to flash memory as initial values. (To access these
functions, select PLC – Edit – Memory Cassette/DM.)
