Omron CX-PROGRAMMER V9 Operation Manual page 405

PART 2: CX-Server PLC Tools
CHAPTER 12 – PLC Backup Tool
CX-Server PLC Tools_Page 162
Select the check boxes in the number column to set the target Units, and then click the Start
4.
Button. The following Confirm Restore to PLC Dialog Box will be displayed.
Select this check box to select the
data for the Unit.
Execute the following steps to select the data for each Unit.
5.
1. Select the Select the unit data Check Box.
2. Click the OK Button. The Select Data to be Restored Dialog Box will be displayed.
The displayed data will depend on the unit type.
3. Select the check boxes for the data to be restored.
4. Click the Start Button.
To restore all of the data, do not select the Select the unit data Check Box and click the OK
Button.
If the CPU Unit is not in PROGRAM mode, the following dialog box will be displayed to
6.
confirm that it is OK to change the operating mode. If it is OK to change the operating
mode, click the Yes Button.
