Features and Word Allocations

3-1 Features and Word Allocations
3-1-1

Features

Temperature control Units
3-1-2

Word Allocations

272
• The PID with advanced feed-forward circuitry (2 degrees of freedom) of
the CQM1-TC00@/TC10@ assures stable temperature control. The Units
can be set to ON/OFF control.
• CQM1-TC00@ Temperature Control Units for thermocouples and CQM1-
TC10@ Temperature Control Units for platinum resistance thermometers
are available. Each Temperature Control Unit can be used for two-loop
temperature control.
Temperature sensor
Thermocouple
Platinum resistance ther-
mometer
I/O Address
Output m
m + 1
Input n
n + 1
• One word each can be allocated for inputs and outputs if only one control
loop is used (when DIP switch pin 5 is ON).
• Two words each will be allocated for inputs and outputs if two control
loops are used (when DIP switch pin 5 is OFF),
• Data is handled as four digits of BCD, except that an F in the leftmost digit
is used to indicate negative values. The meaning of each digit is shown
below.
3
CQM1-TC00@:10 -10
2
CQM1-TC10@:10 -10
• The set point setting range is as follows:
F999 to 9999, or CCCC
• The contents of the process value is as follows:
F999 to 9999: Process value
E@@@: Error code
FFFF: Initialization
Output type
NPN output
CQM1-TC001
CQM1-TC101
15 12 11
Loop 1 set point (SP)
Loop 2 set point (SP)
Loop 1 process value (PV)
Loop 2 process value (PV)
2 1 0
-10 -10 , e.g., F999 = –999
1 0 –1
-10 -10 , e.g., F999 = –99.9
Section 3-1
PNP output
CQM1-TC002
CQM1-TC102
Bit
8 7 4 3 0
