List of Commands

7-2 List of Commands
Command

Operation mode A set

Operation mode A read
Operation mode B set
Operation mode B read
Scaling value set
Scaling value teach
Scaling value read
Set value set
Set value teach
Set value read
Hysteresis set
Hysteresis read
Present value read
7-3

Commands and Responses

7-3-1 Operation Mode A Set
218
2. After confirming that the sign and the set value that the input word is set to
is correct, set 0000 to the output word.
3. The scaled conversion data or comparison result will stored in the input
word.
Note The Linear Sensor Interface Unit acknowledges the start or end of a com-
mand through a change in the output word value. When "0000" is set to the
parameter by the setting command, for example, even if "0000" is set at the
end of the command, the command doesn't end because there is no change
in the output word value, not allowing scaled conversion data or comparison
result to be set in the input word. To end the command, set a value other than
the one set to the parameter. However, that the value will be reflected on the
monitor output if the Unit is used in the set data D/A output mode. Therefore,
when using the Unit in the set data D/A output mode, be sure to select a value
which will not affect peripheral devices.
The following commands can be used to set the initial parameters through the
Programming Console.
Command
code
C000 Used to set operation mode A.
C100 Used to read the settings of operation mode A.
C200 Used to set operation mode B.
C300 Used to read the settings of operation mode B.
C4** Used to set a scaling value.
C5*0 Used to execute scaling value teaching.
C6*0 Used to read a scaling value.
C7** Used to set a set value.
C8*0 Used to execute the set value teaching.
C9*0 Used to read a set value.
CA00 Used to set hysteresis.
CB00 Used to read the hysteresis.
CC00 Used to read the present scaled conversion data.
This command is used to set the following operation mode data.
• Data input
• Timing hold
• Input type
• Monitor output
The above items will be stored in the nonvolatile memory and will not be lost
after the Unit is turned OFF.
Meaning
Section 7-2
Reference
page
218
219
220
221
222
223
223
224
225
225
226
226
227
