5. Ensure the available firmware version is later than the current one on your device.
NOTE: The firmware release notes provide details about the changes between different firmware
versions. The file can be downloaded from the same page as the firmware.
6. Click the Download link to the right of your DXP PLUS device (see figure 115,
Figure 115. Firmware Download Link for DXP HD 4K PLUS
7. On the login page that appears next, fill in the required information to log in to
an ID number, see your Extron representative).
8. Follow the instructions on the subsequent screens to complete the software program installation. By default,
the configuration program files are stored on your computer at C:\Program Files(x86)\Extron\Firmware\
DXP HD 4K PLUS
If there is not already an Extron folder in your Program Files x86 folder, the installation program creates it as
well.
Network Setup
What is an IP Address?
An IP address is a 32-bit binary number that is used to identify each device on an Ethernet network. This number
is usually represented by four decimal numbers (called "octets"), each in the range of 0 through 255 and
separated by dots; for example, 198.123.34.240. This is called "dotted decimal notation."
An IP address is divided into two parts:
•
Network identifier
•
Host identifier
Each address on a given network must have the same network identifier value but have a unique host identifier.
As a result, there are different classes of addresses that define the range of valid addresses and the parts of the
address that are used for the network and host identifiers.
The most common IP address classes are:
Class Name
Class A
Class B
Class C
NNN refers to the network identifier and HHH refers to the host identifier.
Choosing IP Addresses
If the computer and the DXP PLUS are directly connected or connected via their own independent network, follow
the guidelines below for choosing the IP addresses.
However, if you intend to connect your computer and switcher to an existing network, you need to advise the
network administrator and ask the administrator to allocate suitable IP addresses.
On an independent network, it is generally recommended that you use the Class C format (from 192.0.0.1 to
223.255.255.254).
Valid Address Range
0.0.0.1 to 127.255.255.254
128.0.0.1 to 191.255.255.254
192.0.0.1 to 223.255.255.254
Identifier Arrangement
NNN.HHH.HHH.HHH
NNN.NNN.HHH.HHH
NNN.NNN.NNN.HHH
