Control Panel Display - Compaq AlphaServer 1200 User Manual

Table 8–1 Control Panel Display
Field Content
²
CPU number
³
Status
´
Test number (for DIGITAL use only)
µ
Suspected device
1
CPU module
2
Memory module
3
System board
Display Meaning
P0–P1 CPU reporting status
TEST Tests are executing
FAIL Failure has been detected
MCHK Machine check has occurred
INTR Error interrupt has occurred
CPU0–1 CPU module number
MEM0–7 and Memory pair number and low
L, H, or * module, high module, or either
IOD0 Bridge to PCI bus 0
IOD1 Bridge to PCI bus 1
FROM0 Flash ROM
COMBO COM controller
PCEB PCI-to-EISA bridge
ESC EISA system controller
NVRAM Nonvolatile RAM
TOY Real time clock
I8242 Keyboard and mouse controller
1
2
3
3
3
3
3
3
3
3
3
Troubleshooting 8-5
