5.3.6 System Bus Configuration

Figure 5-12 System Bus Configuration
Systemboard Configuration
Hard Disk Configuration
PCI Configuration
EISA Configuration
SCSI Configuration
MC Bus Configuration
Memory Configuration
1 2
McBus Module Name
1 Memory
2 CPU (EV56 Cached)
3 CPU (EV56 Cached)
4 MCBus-PCI Bridge
5 MCBus-PCI Bridge
ESC=Exit
²
MC bus number — Identifies the location of a component on the system bus.
³
Module name — The DIGITAL internal identifier for a system component.
´
Module type — Identifies the function of the system component.
µ
Revision — A DIGITAL internal number representing the manufacturing
revision level of the system component.
¶
Physical slot — Represents the actual location of the system component on the
bus.
5-18 User's Guide
Display System Configuration
3 4
Module Type Revision
0 0000
3 0002
3 0002
6008 0031
6000 0031
F1=Help
5
Physical Slot
MEM
CPU0
CPU1
IOD0/1
IOD0/1
PK-0744D-97
