Removing and Attaching the Carrying Handle

The LCD Projector Carrying Handle can be removed and
attached. When the Projector is set up so that it need not be
moved, you can improve the appearance of the Projector by
removing the handle.
Please follow the instructions below to remove and attach
the carrying handle.
When Removing the Carrying Handle
1
Hold in the two lock buttons
at the base of the handle as shown.
Note
• Remove the handle while in the raised position.
Removal is difficult if in the lowered position.
2
Turn the Lock Ring
to RELEASE on the LCD Projector.
3
Repeat steps 1 and 2
4
Slowly pull the carrying handle
LCD Projector.
When Attaching the Carrying Handle
1
Insert the carrying handle
the mark on the Lock Ring is aligned with RELEASE on the
LCD Projector.
2
Hold in the two lock buttons
at the base of the handle as shown.
3
Turn the Lock Ring
LOCK on the LCD Projector and you hear it click into the locked
position. (The Lock Ring is locked.)
4
Repeat steps 1 and 2
Note
• Attach the carrying handle securely. If you carry the LCD
Projector with the carrying handle improperly attached, the
handle could come off and you sometimes cause injury.
, located on the Lock Ring
to the left so that the
and remove the other Lock Ring.
straight out from the
into the LCD Projector so that
, located on the Lock Ring
to the right so the mark points to
and remove the other Lock Ring.
mark points
Lock Ring
Carrying Handle
