Product Information
LCD Projector
1
Speaker
2
Remote Control Sensor ........................ See page 11.
3
Security Lock
4
POWER Button/
POWER Indicator STANDBY(R) ON(G) See page 14.
5
VOLUME+ / - Buttons ............................. See page 18.
6
Adjust
Buttons .................. See pages 19, 22.
7
AUTO SETUP Button ............................ See page 32.
8
INPUT Button ......................................... See page 17.
9
ENTER Button ....................................... See page 19.
10 MENU Button ......................................... See page 19.
11 KEYSTONE Button ................................ See page 25.
12 STATUS CODE ...................................... See page 48.
13 Air outlet port
14 USB connector ...................................... See page 46.
15 Zoom Ring ............................................. See page 16.
16 FOCUS Ring .......................................... See page 16.
17 Remote Control Sensor ........................ See page 11.
18 Carrying Handle .................................. See page 47.
19 AC Socket (100 V - 240 V) ................... See page 14.
20 Main Power Switch ............................. See page 14.
21 Lens Cap
22 Air Filter ............................................... See page 49.
23 Adjuster Button ................................... See page 15.
24 Adjustable legs ................................... See page 15.
25 Lamp Cover Screws .................... See pages 51, 52.
26 Lamp Cover ................................. See pages 51, 52.
27 MOUSE Connector ..............................See page 46.
28 RGB Audio Input Connector ...... See pages 41, 42.
29 Video Audio Input Connector ........... See page 40.
30 S-Video Input Connector .................... See page 40.
31 RS232C Connector ............................. See page 44.
32 RGB1 Input Connector .......................See page 41.
33 RGB2/YP
P
Input Connector ... See pages 41, 42.
B
R
34 Audio Output Connector ............. See pages 40-42.
35 Video Input Connector .......................See page 40.
8
