BayStream 7.3
Documentation Change
Notice
BayStream Multiservice Software Version 7.3
BayStream Site Manager Version 7.3
Part No. 115385-D Rev 01
December 1998

Advertisement

Table of Contents
loading

Related Manuals for Bay Networks Baystream 7

Summary of Contents for Bay Networks Baystream 7

  • Page 1 BayStream 7.3 Documentation Change Notice BayStream Multiservice Software Version 7.3 BayStream Site Manager Version 7.3 Part No. 115385-D Rev 01 December 1998...
  • Page 2 Portions of the code in this software product may be Copyright © 1988, Regents of the University of California. All rights reserved. Redistribution and use in source and binary forms of such portions are permitted, provided that the...
  • Page 3 Software is first shipped to Licensee. If any item of Software fails to so function during its warranty period, as the sole remedy Bay Networks will at its discretion provide a suitable fix, patch, or workaround for the problem that may be included in a future Software release.
  • Page 4 7. Term and termination. This license is effective until terminated; however, all of the restrictions with respect to Bay Networks’ copyright in the Software and user manuals will cease being effective at the date of expiration of the Bay Networks copyright; those restrictions relating to use and disclosure of Bay Networks’ confidential information shall continue in effect.

  • Page 5: Table Of Contents

    Text Conventions ...xiii Acronyms ... xv Bay Networks Technical Publications ...xvi How to Get Help ...xvi New Features ... 1 Documentation Changes ... 3 Volatile File System ... 4 Configuring and Managing the File System ... 6 Using the Technician Interface ... 6 Using Site Manager ...
  • Page 6 SVC Operation ... 21 SVC Signaling ... 21 LAPF ... 22 Closed User Group (CUG) ... 22 Libraries and External Interface ... 22 Configuring the Resilient NNI ... 22 Using Site Manager ... 22 Using the Technician Interface ... 25 Enabling Statistics for SVCs and PVCs ...
  • Page 7 Setting the Synchronous IFTF Pattern ... 45 Setting the HSSI Carrier Loss Timeout ... 46 Enabling Receive All Frames ... 46 Changes to Configuring IP Services ... 46 Modified AS Boundary Router Parameter ... 48 Changes to Troubleshooting and Testing ... 49 Using the Test Traffic Generation Feature to Run Loopback Tests ...
  • Page 9 Figure 1. Creating a VFS Volume ... 6 Figure 2. Setting the Size of a VFS Volume ... 6 Figure 3. Saving Statistics to the VFS ... 13 Figure 4. Resilient NNI Architecture ... 14 Figure 5. Bay Networks Resilient NNI Configuration with HSSI Interface Only ... 16 Figure 6.
  • Page 11 Table 1. Version 7.3 New Features ... 1 Table 2. Changes in this Document to Support Version 7.3 ... 3 Table 3. NVFS Commands ... 7 Table 4. Status Enquiry and Response Messages ... 18 Table 5. Atmizer Bit Mask ... 31 Table 6.

  • Page 13: Text Conventions

    This document includes the new features for BayStream™ Version 7.3. Text Conventions This guide uses the following text conventions: angle brackets (< >) bold text braces ({}) 115385-D Rev 01 Indicate that you choose the text to enter based on the description inside the brackets.
  • Page 14 brackets ([ ]) ellipsis points (. . . ) italic text screen text separator ( > ) vertical line ( Indicate optional elements in syntax descriptions. Do not type the brackets when entering the command. Example: If the command syntax is: show ip interfaces [-alerts] show ip interfaces Indicate that you repeat the last element of the...

  • Page 15: Acronyms

    Acronyms This guide uses the following text conventions: BootP CD-ROM CSMA/CD DLCMI HDLC HSSI IFTF ISDN NVRAM OSPF SDLC SNMP TCP/IP 115385-D Rev 01 asyncronous transfer mode Bootstrap Protocol Basic Rate Interface compact disk read-only memory cyclic redundancy check carrier sense multiple access with collision detection data exchange interface Data Link Control Management Interface high-level data link control...

  • Page 16: Bay Networks Technical Publications

    Internet. Go to support.baynetworks.com/library/tpubs/. Find the Bay Networks product for which you need documentation. Then locate the specific category and model or version for your hardware or software product. Using Adobe Acrobat Reader, you can open the manuals and release notes, search for the sections you need, and print them on most standard printers.

  • Page 17: New Features

    BayStream 7.3 Documentation Change Notice This document presents the following information for BayStream™ Version 7.3: • New features • Documentation changes New Features Table 1 provides an overview and location of the sections in this document that support BayStream Version 7.3 changes Table 1.
  • Page 18 Disable Disable of PVC and SVC Billing Running a Technician Interface Telnet Session on a Predefined Slot BayStream Multiservice Software Version 7.3 Version 7.3 New Features Description of Contents Describes how to enable and disable statistics data collection for SVCs and PVCs...

  • Page 19: Documentation Changes

    Documentation Changes This document also includes: • Software improvements specific to Version 7.3 • Documentation changes specific to Version 7.3 Table 2 provides an overview of the sections and their locations in this document that support Version 7.3 changes. Table 2.

  • Page 20: Volatile File System

    Note: When running memory intensive applications, the VFS uses the memory available of the FRE card. If the available memory is less than the requested memory, BayStream software will not create it. You can dynamically change the size of the VFS whereas the FLASH/SRAM file system is restricted by its physical size.
  • Page 21 BayStream 7.3 Documentation Change Notice VFS supports the same set of Technician Interfacecommands and standard file transfer protocols as FLASH/SRAM. You can also use Site Manager to configure and manage VFS. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...

  • Page 22: Configuring And Managing The File System

    [4:1] $ set wfFrSwExtFileSysEntry.3.1 500000 NVFS/DRAM file system MIB entry Use the Technician Interface commands shown in volume. BayStream Multiservice Software Version 7.3 Figure 1 shows an example of a set command that creates a VFS Attribute identifier (1=wfFrSwExtFileSysDelete) Slot number...

  • Page 23: Table 3. Nvfs Commands

    Displays all files on a volume. Erases any existing files on a volume and formats the volume. Saves the current software configuration, aliases, or events to a file. Refer to Chapter 4 for instructions on the save Transfers a file to or from the BayStream platform.

  • Page 24: Using Site Manager

    Note: If you enter a value for the VFS memory that exceeds the available memory on the FRE card, Site Manager will not create the VFS and does not generate a warning message. BayStream Multiservice Software Version 7.3 Site Manager Procedure System responds The Volatile File Systems window opens.
  • Page 25 Site Manager displays the list of files contained in the volume you selected. BayStream Multiservice Software Version 7.3...

  • Page 26: Using File Transfer Protocols

    494376 bytes - Available free space 494376 byt4es - Contiguous free space [4:1]$ tftp get 192.32.51.114 4:config 5x:config Transfer with 192.32.52.114 completed successfully. [4:1]$ dir 5x: Volume in drive 5x: is BayStream Multiservice Software Version 7.3 TOTAL SIZE FREE SPACE 500000 499966 8388608...

  • Page 27: Ftp

    Saving Statistics to the VFS You can save statistics to either the VFS or to flash memory. By default, BayStream software saves statistics to SRAM flash memory. Use either Site Manager or the Technician Interface to explicitly save statistics to the VFS.

  • Page 28: Using Site Manager

    Master Volume Number: enter the volume number (which is the slot number on which you have VFS configured).51 5. Click on OK. 6. Click on Save. BayStream Multiservice Software Version 7.3 Site Manager Procedure System responds The Statistical Data Collection window opens.

  • Page 29: Using The Technician Interface

    Annex A of ITU-T Recommendation Q.933 to manage the activation of links that carry the NNI traffic and monitor integrity of inactive links. 115385-D Rev 01 Saving Statistics to the VFS attribute identifier Statistics MIB Entry value (1=enable; 2= disable) BayStream Multiservice Software Version 7.3 BYS0099A Code: 33...

  • Page 30: Architecture

    SVCs using FRF.4 signaling where BayStream is configured as a UNI DCE device • Resilient RNNI Slave Mode operations only • Both SVCs and PVCs on the RNNI interface BayStream Multiservice Software Version 7.3 Network A Resilient NNI Link 1 Link 2 Operates in...

  • Page 31: Master Node Operation

    In this document, only the slave node operations are discussed; the master node operations are mentioned only where applicable to slave node operations. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...

  • Page 32: Link Phases

    Bay Networks Resilient NNI Configuration with HSSI Interface Only Bay Networks Frame Relay FDDI Ring FDDI Ring BNX with HSSI card (New standardized BNX Node) BayStream Multiservice Software Version 7.3 Figure 6 show some sample Resilient NNI configurations using POP (NNI) HSSI HSSI POP B...

  • Page 33: Initialization And Startup Phase

    HSSI Other Frame Relay switch with unchannelized DS3 card MCI Timing Source Table 4 contains a description of each type of status enquiry BayStream Multiservice Software Version 7.3 POP B Frame Relay Trunk Network Other Frame Relay switch POP C...

  • Page 34: Liv Status Enquiry Procedures

    Note: The master node only sends a full status enquiry message on the selected link. This point may be reached after responding to as few as one LIV status enquiry message from the master node. BayStream Multiservice Software Version 7.3 Status Enquiry and Response Messages Description...

  • Page 35: Fast Start Procedures

    BayStream 7.3 Documentation Change Notice Fast Start Procedures The master node may implement optional fast start procedures. These procedures are used to decrease the amount of time it takes to begin active NNI traffic transfer on the selected link. During the initialization phase, the master node may choose to send full status enquiry messages on the preferred link and LIV status enquiry messages on the alternate link.

  • Page 36: Link Activation Phase

    (now backup) link unless there is a failure of the alternate (now active) link or if there is network management intervention. This scenario is based on the assumption that both links will be sufficient for handling NNI traffic. BayStream Multiservice Software Version 7.3 115385-D Rev 01...

  • Page 37: Svc Operation

    The SVC connections may be left in the “half connected” state. This condition is similar to the bouncing of UNI SVC interface on a BayStream software release prior to Revision 7.3. SVC Operation The Annex A link management and selection procedures described in the previous section are used to determine the active link for SVC operation.

  • Page 38: Lapf

    You can use Site Manager or the Technician Interface to configure Resilient NNI. Using Site Manager Configuring a Resilient NNI is a two-stage process: Configure the HSSI Ports as Resilient NNI Links. Pair the Resilient NNI Links. BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 39 H51indicates a HSSI circuit supported by the HSSI link module in slot 5 and the physical connector.) The WAN Protocol window opens. The DLCMI Configuration window opens. The Configuration Manager window opens. The Edit Connector window opens. BayStream Multiservice Software Version 7.3...
  • Page 40 5. Choose RNNI. 6. Choose Add. 7. Choose a HSSI RNNI port. 8. Click on Done. 9. Choose File. 10. Choose Exit. BayStream Multiservice Software Version 7.3 Site Manager Procedure System responds Site Manager Procedure System responds The Edit Connector window opens.

  • Page 41: Using The Technician Interface

    [4:1] $ set wfHssiEntry.wfHssiFrSwRnniEnabled.4.1 1 [4:1] $ set wfHssiEntry.wfHssiCct.4.1 3 115385-D Rev 01 Site Manager Procedure System responds The Edit Connector window opens. The Circuit Definition window opens. Site Manager returns you to the Circuit Definition window. BayStream Multiservice Software Version 7.3...

  • Page 42: Enabling Statistics For Svcs And Pvcs

    (SVCs) or permanent virtual circuits (PVCs) using either Site Manager or the Technician Interface. When you enable statistics collection on an interface, BayStream software, by default, begins collecting statistics for all PVCs on the interface. If there are SVCs on the interface, you need to use either Site Manager or theTechnician Interface to enable statistics collection explicitly.

  • Page 43: Using Site Manager

    115385-D Rev 01 Site Manager Procedure System responds The DLCMI Configuration window opens. The Edit FRSW Interface window opens. Site Manager returns you to the Configuration Manager window. Figure 8 BayStream Multiservice Software Version 7.3 Figure shows an example of a set...

  • Page 44: Statistics Data Collection File

    [4:1] $ set wfFrSwDlcmiEntry.4.wfFrSwDlcmiSvcStatsEnable 2; commit DLCMI MIB Entry Statistics Data Collection File BayStream Statistical Data Collection software gathers, aggregates, and reports on three types of records for ATM lines: • Interface card or slot (the equivalent of one OC-3 line) •...
  • Page 45 A value of 1 within the bit mask indicates that the data collection software monitors and reports the associated congestion control counter; a value of 0 within the bit mask indicates that the software ignores the associated congestion control counter. The default value...
  • Page 46 5. Click on the Values button. 6. Choose the counters you want to specify for data collection and reporting. 7. Click on Save. 8. Click on Save. BayStream Multiservice Software Version 7.3 Site Manager Procedure System responds The Options menu opens. The Statistical Data Collection window opens.

  • Page 47: Table 5. Atmizer Bit Mask

    31 (MSB) AtmizerVclRxPacketsOkWra AtmizerVclRxPacketsOk AtmizerVclRxCellsOkWrap AtmizerVclRxCellsOk AtmizerVclRxOamCount AtmizerVclRxFlowCtrlCount AtmizerVclRxInvalidHeaders 1.3.6.1.4.1.18.3.4.23.3.4.1. AtmizerVclRxOversizedSDU AtmizerVclRxCrcErrors AtmizerVclRxCrcIOErrors AtmizerVclRxLackBufCredits 1.3.6.1.4.1.18.3.4.23.3.4.1. AtmizerVclRxLackPageCredi AtmizerVclRxBufResc AtmizerVclRxPageResc 115385-D Rev 01 Object ID 1.3.6.1.4.1.18.3.4.23.3.4.1. 1.3.6.1.4.1.18.3.4.23.3.4.1. 1.3.6.1.4.1.18.3.4.23.3.4.1. 1.3.6.1.4.1.18.3.4.23.3.4.1. 1.3.6.1.4.1.18.3.4.23.3.4.1. 1.3.6.1.4.1.18.3.4.23.3.4.1. 1.3.6.1.4.1.18.3.4.23.3.4.1. 1.3.6.1.4.1.18.3.4.23.3.4.1. 1.3.6.1.4.1.18.3.4.23.3.4.1. 1.3.6.1.4.1.18.3.4.23.3.4.1. 1.3.6.1.4.1.18.3.4.23.3.4.1. 1.3.6.1.4.1.18.3.4.23.3.4.1. BayStream Multiservice Software Version 7.3 Default...

  • Page 48: Line Byte Count For Atm Circuits

    8 - 0 (LSB) Not Used Refer to Statistics for information on generating and interpreting performance reports using BayStream Statistical Data Collection software. Line Byte Count for ATM Circuits You can enable (and disable) the collection of Line Byte Count statistics for the DS-3 and OC-3 ATM circuits.

  • Page 49: Svc Call Management

    Site Manager Procedure System responds The Add Line Byte Count window opens. The Edit dialog box opens. Site Manager returns you to the Add Line Byte Count window. Site Manager returns you to the Configuration Manager window. BayStream Multiservice Software Version 7.3...

  • Page 50: Table 6. Svcs Field Descriptions

    Circuit Number Local DLCI Remote DLCI Calling Number Called Number Start Date Start Time Elapsed Days Elapsed Time Address Type BayStream Multiservice Software Version 7.3 Calling Number/ Start Date 123.45.67.89.01.21.20 10/12/98 13:31:01 123.45.67.89.01.21.14 123.45.67.89.01.21.20 10/12/98 13:31:01 123.45.67.89.01.21.14 svcs Field Descriptions...

  • Page 51: Frf.2.1 And Frf.1.1 Loopback Detection

    During link integrity verification, a bidirectional exchange of sequence numbers occurs on a periodic basis between the DCE and the DTE. The third octet of the link integrity verification information element contains the send sequence number. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...

  • Page 52: Suspected Loopback Condition

    Suspected Loopback Condition If a loopback condition is suspected, BayStream software does the following: Discards the status enquiry message Initiates the loopback verification procedure Generates a Technician Interface message of severity level info (for example:...

  • Page 53: Loopback Corrected (Normal Condition)

    If the Cross Net or Asynchronous Cross Net feature is enabled, BayStream software sends an update message to the DCE (one message for each PVC and one message for each SVC) at the other end to notify the DCE that the interface has been torn down.

  • Page 54: Enabling Loopback Detection Using The Technician Interface

    For example, you can use Technician Interface to enable traffic policing for an interface: [4:1] $ set wfFrSwDlcmiEntry.wfFrSwDlcmiBcMeasurementEnable.<circuit number> 1 You can use Technician Interface to disable traffic policing for an interface: [4:1] $ set wfFrSwDlcmiEntry.wfFrSwDlcmiBcMeasurementEnable.<circuit number> 2 BayStream Multiservice Software Version 7.3 115385-D Rev 01...

  • Page 55: Enabling Traffic Policing Using Site Manager

    Site Manager displays a list of frame relay switch interfaces. The Edit FRSW Interface window opens. Site Manager returns you to the list of frame relay switch interfaces. Site Manager returns you to the Configuration Manager window. BayStream Multiservice Software Version 7.3...

  • Page 56: Using Site Manager

    To enable billing information collection on an interface, perform the following steps: Use the Technician Interface list command to display interfaces currently configured on the BayStream switch (as shown in BayStream Multiservice Software Version 7.3 Site Manager Procedure System responds The DLCMI Configuration window opens.

  • Page 57: Figure 9. Displaying The Interfaces

    [4:1] $ set wfFrSwDlcmiEntry.wfFrSwDlcmiBillingEnable.cct 1 DLCMI MIB Entry 115385-D Rev 01 Figure 11 TI list command DLCMI MIB Entry BayStream Multiservice Software Version 7.3 Figure 10 shows an example of shows an example of a BYS0094A attribute identifier attribute value (1=enable; 2= disable)

  • Page 58: Running A Technician Interface Telnet Session On A Predefined Slot

    TI telnet command [4:1] $ telnet 192.24.22.10 1101 You can configure a local port prefix using Site Manager or the Technician Interface. BayStream Multiservice Software Version 7.3 attribute value (1=enable; 2= disable) Figure 12 shows the format for a dynamic port number.

  • Page 59: Using Site Manager

    0. Site Manager returns you to the Configuration Manager window. Configuring a Local Port Prefix attribute identifier Telnet MIB Entry value (11 through 166; 0=disable) BayStream Multiservice Software Version 7.3 Figure 13 to configure a local BYS0098A...

  • Page 60: New Mib Attribute

    This section describes changes regarding information provided in Getting Started with Site Manager, as follows: • The Getting Started with Site Manager guide incorrectly states that Bay Networks supplies the Distinct TCP/IP software with Site Manager. Before installing Site Manager on a PC, install any WINSOCK-compatible TCP/IP stack. •...

  • Page 61: Setting The Synchronous Iftf Pattern

    Force IFTF parameter set to Default. Or, you can override the defaults by setting the Force IFTF parameter to Force Flags or Force Idles. For a dial-on-demand interface, set the Force IFTF parameter to Force Idles. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...

  • Page 62: Setting The Hssi Carrier Loss Timeout

    MIB Object ID: 1.3.6.1.4.1.18.3.4.7.1.68 Changes to Configuring IP Services The OSPF software service is a soloist; to conserve resources, it runs on only one slot in the BayStream platform. By default, OSPF starts on the first available slot. You can override this default by: •...
  • Page 63 OSPF may run. If you choose an empty slot, and it is the only slot you choose, OSPF will not run; if you choose a slot that becomes disabled, and it is the only slot you choose, OSPF will not restart. MIB Object ID: 1.3.6.1.4.1.18.3.5.3.2.3.1.10 115385-D Rev 01 BayStream Multiservice Software Version 7.3...

  • Page 64: Modified As Boundary Router Parameter

    Example: 2,3,5 MIB Object ID: 1.3.6.1.4.1.18.3.5.3.2.3.1.19 Modified AS Boundary Router Parameter This section provides the modified description of the AS Boundary Router parameter. The default value is changed from No to Yes. BayStream Multiservice Software Version 7.3 115385-D Rev 01...

  • Page 65: Changes To Troubleshooting And Testing

    High-Speed Serial Interface (HSSI) Test Traffic Generation requires that frames are HDLC type so that cyclic redundancy checks (CRC) can identify bad frames received during the loopback test. Test Traffic Generation uses the BofL mechanism. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...

  • Page 66: Using Site Manager To Reallocate Memory Partitions For A Processor Module

    Using Site Manager to Reallocate Memory Partitions for a Processor Module This section supplements the “Memory or Buffer Problem” section on page 3-13 of Troubleshooting and Testing. BayStream Multiservice Software Version 7.3 Table 7 to set the MIB values to 2. Technician Interface Commands Used to Enable Test Traffic...
  • Page 67 Increasing the size of the global memory partition automatically decreases the size of the local memory partition. The BayStream Multiservice Software ensures that the sum of local and global memory always equals the total amount of memory available on a given processor.

  • Page 68: Figure 14. Switch Connection Options Window

    Timeout and Retries options. Then click on OK. From the main Site Manager window, select Administration > Kernel Configuration. The Kernel Configuration window appears BayStream Multiservice Software Version 7.3 Switch Connection Options Window (Figure 14). (Figure 15).

  • Page 69: Figure 15. Kernel Configuration Window

    BayStream 7.3 Documentation Change Notice Figure 15. Kernel Configuration Window Note: If the platform you are configuring has processor modules other than FRE-2 modules, a window appears with the following message: No valid modules were found. The message means that the processor modules found in the currently connected BayStream platform are not user-configurable.
  • Page 70 To do so, click on and hold the Slot button to display all the slots in the router. Then drag the pointer to the chosen slot number and release the mouse button. Repartition the memory and restart the slot as described in BayStream Multiservice Software Version 7.3 Description Memory dedicated to the local and global pools (described below) Memory router management.

  • Page 71: Table 8. Reallocating Memory

    Note: You must also Save from the Configuration Manager->File->Save menu selection. 3. Click on OK. The slot restarts. Click on Default rather than Update. Click on OK after the confirmation message appears. The slot restarts. BayStream Multiservice Software Version 7.3...

  • Page 72: Correction To Running Diagnostics

    It also contains incorrect information about the DIAG LED on the front panel and LED 8 on the FRE module. Refer to “Turning off the Indicator DIAG LED” on page 3-24 for the correct instructions and information. BayStream Multiservice Software Version 7.3 command after hot-swapping a link module. diags...

  • Page 73: Change To Event Messages

    Action: Check the status of the corresponding interface on the master node to see if it either missed sending LIVO polls, or a switch_over has occurred. 115385-D Rev 01 FRSW_BILLING/146 16794258 FRSW/226 16794082 FRSW/227 16794083 BayStream Multiservice Software Version 7.3...
  • Page 74 Clear the loopback condition. Entity Code/Event Code Decimal Identifier Severity: Info Message: Circuit <circuit_no.>: Loopback condition corrected. Meaning: The specified circuit has exited the loopback state. Action: BayStream Multiservice Software Version 7.3 FRSW/228 16794084 FRSW/229 16794085 FRSW/234 16794090 FRSW/235 16794091 115385-D Rev 01...

  • Page 75: Non-Volatile File System (Nvfs) Events

    The statistical data collection file requires more space than is available in the volume, so it could not write the performance file to the <DRAM VFS>. Action: Retrieve the accumulated files from < DRAM VFS>, and compact the storage media. 115385-D Rev 01 NVFS/83 16780115 TELNET/31 16787487 STATS/108 16800876 BayStream Multiservice Software Version 7.3...

  • Page 76: Changes To Mibs

    Entity Code/Event Code Decimal Identifier Severity: Warning Message: Error in unmounting <DRAM VFS> Meaning: The statistical data collection software cannot dismount the specified storage device. Action: Verify the integrity of the storage device. Entity Code/Event Code Decimal Identifier Severity: Warning Message: Error in compacting volume <volume_id>: return GFS status <...
  • Page 77 When present, contains a unique value for a slot to which the VFS file extension is to be assigned to. The slot value must be in the range between 1 and 14. Name: wfFrExtFileSysSize Object ID: 1.3.6.1.4.1.18.3.5.9.6.20.1.3 Type: Integer Access: Read/Write Default: 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 78 Read Only Default: Description: Contains the actual size (in bytes) of the Volatile File System allocated. A value of zero indicates that the extended file system is currently disabled. BayStream Multiservice Software Version 7.3 Decimal Value 131072 262144 524288 1048576...

  • Page 79: Resilient Network-To-Network Interface

    Data Link Connection Management interface corresponding to the RNNI and include the error table. Name: wfFrSwRnniDlcmiEntry Object ID: 1.3.6.1.4.1.18.3.5.9.6.22.1 Index: wfFrSwRnniDlcmiLineNumber Each entry contains the following objects: • wfFrSwRnniDlcmiDelete • wfFrSwRnniDlcmiState 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 80 • wfFrSwRnniDlcmiActiveReceived • wfFrSwRnniDlcmiPolls • wfFrSwRnniDlcmiAlarmTimer • wfFrSwRnniDlcmiErrType • wfFrSwRnniDlcmiErrData • wfFrSwRnniDlcmiErrTime • wfFrSwRnniDlcmiBcMeasurementInterval • wfFrSwRnniDlcmiMcastNoBufferErrors • wfFrSwRnniDlcmiFrameTooShortErrors • wfFrSwRnniDlcmiFrameTooLongErrors • wfFrSwRnniDlcmiIllegalDlciErrors • wfFrSwRnniDlcmiUnknownDlciErrors • wfFrSwRnniDlcmiProtocolErrors • wfFrSwRnniDlcmiUnknownIEErrors • wfFrSwRnniDlcmiSequenceErrors • wfFrSwRnniDlcmiUnknownRPTErrors BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 81 Interval • wfFrSwRnniDlcmiCrossNetErrorThreshold • wfFrSwRnniDlcmiCrossNetAsyncUpdateEnable • wfFrSwRnniDlcmiBcMeasurementEnable • wfFrSwRnniDlcmiAsyncUpdateEnable • wfFrSwRnniDlcmiCrossNetListenEnable • wfFrSwRnniDlcmiSvcDisable • wfFrSwRnniDlcmiL2AddrType • wfFrSwRnniDlcmiEscapeMode • wfFrSwRnniDlcmiEscapeCircuit • wfFrSwRnniDlcmiEscapeVcCount • wfFrSwRnniDlcmiIwfMode • wfFrSwRnniDlcmiSvcBillingEnable • wfFrSwRnniDlcmiSpvcAgent • wfFrSwRnniDlcmiCallAccDlciSelectionType • wfFrSwRnniDlcmiBillingEnable 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 82 Contains a symbolic integer value that specifies the state of the wfFrSwRnniEntry object: 1 (up) -- the RNNI line is available to pass and receive traffic. 2 (down) -- the RNNI line is down. 3 (initializing) -- the RNNI line is initializing. BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 83 2 indicates that the user has identified the interface as a UNI (a User-to-Network Interface that disables bidirectional signaling). Although wfFrSwRnniDlcmiNniEnable is set by Site Manager, this object is not used by the frame relay switch software. Refer to wfFrSwRnniDlcmiBidirect.
  • Page 84 Read Only Default: 2 (disabled) Description: Contains a symbolic integer value of 1, indicating the inclusion of the control byte in Q922 format or 2, indicating that the control byte is disabled. BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 85 Contains the number of errors monitored before declaring the interface down. Name: wfFrSwRnniDlcmiMonitoredEvents Object ID: 1.3.6.1.4.1.18.3.5.9.6.22.1.12 Type: Integer Access: Read Only Default: 4 (events) Description: Contains the number of events over which the error threshold is kept. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 86 Name: wfFrSwRnniDlcmiSequenceCount Object ID: 1.3.6.1.4.1.18.3.5.9.6.22.1.17 Type: Integer Access: Read Only Default: 1 (sequence number) Description: Contains the value of the next-to-send of the sequence counter of the current switch. BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 87 Contains the value of the counter in the most recent polling cycle. Name: wfFrSwRnniDlcmiAlarmTimer Object ID: 1.3.6.1.4.1.18.3.5.9.6.22.1.22 Type: Integer Access: Read Only Description: Contains the time for the next poll from the 1/2 second timeout counter. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 88 Contains the type of the last monitored error: 1 -- no error has as yet been monitored 2 -- a lack of system resources prevented the BayStream frame relay switch software from delivering a multicast packet to all recipients (refer to...
  • Page 89 Contains the number of frames dropped that were too long to be accepted. Name: wfFrSwRnniDlcmiIllegalDlciErrors Object ID: 1.3.6.1.4.1.18.3.5.9.6.22.1.30 Type: Counter Access: Read Only Description: Contains the number of frames dropped that contained an invalid DLCI value. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 90 Contains the number of frames dropped that contained a DLCMI sequence error. Name: wfFrSwRnniDlcmiUnknownRPTErrors Object ID: 1.3.6.1.4.1.18.3.5.9.6.22.1.35 Type: Counter Access: Read Only Description: Contains the number of frames dropped that contained an unknown report type. BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 91 Object ID: 1.3.6.1.4.1.18.3.5.9.6.22.1.39 Type: Counter Access: Read Only Default: 4 (start) Description: Contains the current DLCMI gate execution status: 1 -- running 2 -- recovered 3 -- fault 4 -- start 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 92 Object ID: 1.3.6.1.4.1.18.3.5.9.6.22.1.43 Type: Integer Access: Read Only Default: 2 (disabled) Description: Contains a symbolic integer value of 1, indicating that bidirectional mode is enabled or 2, indicating that bidirectional mode is disabled. BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 93 Contains the sequence number just received from the enquiring station (for bidirectional procedures). Name: wfFrSwRnniDlcmiDteLastReceived Object ID: 1.3.6.1.4.1.18.3.5.9.6.22.1.47 Type: Integer Access: Read Only Default: 1 (sequence number) Description: Contains the sequence number just received from the end station. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 94 Name: wfFrSwRnniDlcmiDtePolls Object ID: 1.3.6.1.4.1.18.3.5.9.6.22.1.48 Type: Counter Access: Read Only Default: none Description: The counter that BayStream software is polling in the cycle. Name: wfFrSwRnniDlcmiDtePollingInterval Object ID: 1.3.6.1.4.1.18.3.5.9.6.22.1.49 Type: Integer Access: Read Only Default: 10 (seconds) Description: Contains the number of seconds between successive status enquiry messages.
  • Page 95 1 (enabled) Description: Contains a symbolic integer value of 1 indicating that BayStream software is going to send status updates for DLCIs to the other end of the network as soon as there is a change of status for the DLCI.
  • Page 96 Object ID: 1.3.6.1.4.1.18.3.5.9.6.22.1.59 Type: Integer Access: Read Only Default: 2 (disabled) Description: Contains a symbolic integer value which indicates whether an SVC is enabled (1) or disabled (2) for this access channel. BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 97 PVCs with wfFrSwVCEscapeEnable set to enabled. Name: wfFrSwRnniDlcmiEscapeVcCount Object ID: 1.3.6.1.4.1.18.3.5.9.6.22.1.63 Type: Integer Access: Read Only Default: Description: Contains the number of PVCs on the DLCMI that are configured as escape PVCs. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 98 Specifies which one of the following types of agents are enabled on this frame relay switch circuit: 1 (none) -- None 2 (cra) -- SPVC Call Request Agent 3 (caa) -- SPVC Call Accept Agent 4 (craandcaa) -- Both agent types BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 99 Name: wfFrSwRnniDlcmiSvcStatsEnable Object ID: 1.3.6.1.4.1.18.3.5.9.6.22.1.69 Type: Integer Access: Read Only Default: 1 (enabled) Description: Contains a symbolic integer which indicates whether the SVC statistics are to be included during statistics data collection. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 100 Object ID: 1.3.6.1.4.1.18.3.5.9.6.22.1.71 Type: Integer Access: Read Only Default: 2 (disabled) Description: A symbolic integer which indicates whether the Annex A software loopback detection feature is enabled (1) or disabled (2). Name: wfFrSwRnniDlcmiLineNumber Object ID: 1.3.6.1.4.1.18.3.5.9.6.22.1.72 Type: Integer Access: Read Only...

  • Page 101: The Rnni Configuration (Cfg) Table

    (a maximum of two ports) participating in the RNNI interface. Name: wfFrSwRnniCfgEntry Object ID: 1.3.6.1.4.1.18.3.5.9.6.23.1 Index: wfFrSwRnniDlcmiLineNumber Each entry contains the following objects: • wfFrSwRnniCfgDelete • wfFrSwRnniCfgState • wfFrSwRnniCfgLineNumber • wfFrSwRnniCfgPeerLineNumber • wfFrSwRnniCfgDlcmiCct 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 102 8 (notpres) -- the RNNI entity is not present on this link Name: wfFrSwRnniCfgLineNumber Object ID: 1.3.6.1.4.1.18.3.5.9.6.23.1.3 Type: Integer Access: Read Only Default: None Description: Contains the instance identifier for this entry. BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 103 3 (detailed) -- Log message of high level, some environmental variables, gate IDs, and gate handles are displayed in the log file Note: When setting the debug level to high or detailed, performance may be degraded due to the additional checking and log messages. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...

  • Page 104: The Resilient Nni Virtual Circuit Table

    • wfFrSwRnniVcCircuit • wfFrSwRnniVcDlci • wfFrSwRnniVcState • wfFrSwRnniVcStateSet • wfFrSwRnniVcMulticast • wfFrSwRnniVcInBe • wfFrSwRnniVcOutBe • wfFrSwRnniVcInThroughput • wfFrSwRnniVcOutThroughput • wfFrSwRnniVcOutBc • wfFrSwRnniVcInBc • wfFrSwRnniVcInBcOctets • wfFrSwRnniVcBecnState • wfFrSwRnniVcReportedStatus • wfFrSwRnniVcReceivedStatus • wfFrSwRnniVcCrossNetStatus BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 105 • wfFrSwRnniVcDropNonDeFrames • wfFrSwRnniVcDropNonDeOctets • wfFrSwRnniVcDropDeFrames • wfFrSwRnniVcDropDeOctets • wfFrSwRnniVcInactiveVcDropFrames • wfFrSwRnniVcInactiveVcDropOctets • wfFrSwRnniVcRecvNonDeFrames • wfFrSwRnniVcRecvNonDeOctets • wfFrSwRnniVcRecvDeFrames • wfFrSwRnniVcRecvDeOctets • wfFrSwRnniVcRecvFecnFrames • wfFrSwRnniVcRecvFecnOctets • wfFrSwRnniVcRecvBecnFrames • wfFrSwRnniVcRecvBecnOctets • wfFrSwRnniVcRecentNonDeOctets • wfFrSwRnniVcXNetErrors 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 106 • wfFrSwRnniVcAtmIwfVCI • wfFrSwRnniVcAtmIwfLossPriorityPolicy • wfFrSwRnniVcAtmIwfDePolicy • wfFrSwRnniVcAtmIwfEfciPolicy • wfFrSwRnniVcEscapeEnable • wfFrSwRnniVcSpvcCallState • wfFrSwRnniVcCallReqCalledAddr • wfFrSwRnniVcCallReqDlciSelectionType • wfFrSwRnniVcCallReqCalled Dlci • wfFrSwRnniVcCallReqRetryTimer • wfFrSwRnniVcCallReqMaxRetries • wfFrSwRnniVcCalledNumber • wfFrSwRnniVcCallingNumber • wfFrSwRnniVcAddressType • wfFrSwRnniVcLineNumber BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 107 Valid entries are determined by the address field length (see wfFrSwDlcmiAddressLen). For 2-byte addressing, values range from 16 to 1007; for 3-byte addressing, from 1024 to 64511; for 4-byte addressing, from 131072 to 8257535. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 108 1007; for 3-byte addressing -- 1024 to 64511; for 4-byte addressing -- 131072 to 8257535. 2 identifies the active state. At PVC creation, the initialization software confirms that the assigned DLCI (wfFrSwRnniVcDlci) is within allowable ranges and that wfFrSwRnniVcStateSet, the object that specifies user control of the PVC, is equal to 2 (active).
  • Page 109 2 (Active) -- enables the PVC to become operational. For a newly configured PVC, the BayStream frame relay switch software transitions the PVC to the active or control state (refer to wfFrSwRnniVcState on); for an existing PVC, the BayStream frame relay switch software transitions the PVC directly to the active state.
  • Page 110 Name: wfFrSwRnniVcOutBe Object ID: 1.3.6.1.4.1.18.3.5.9.6.24.8 Type: Integer Access: Read/Write Default: Null Description: This object is not used in the current BayStream software version. Name: wfFrSwRnniVcInThroughput Object ID: 1.3.6.1.4.1.18.3.5.9.6.24.9 Type: Integer Access: Read/Write Default: Null Description: Contains the incoming throughput for the PVC. Incoming throughput is the average number of CPE-generated information field bits over a measured interval of time.
  • Page 111 Contains a symbolic integer value of 0 or 1 specifying the local BECN state. 0 -- the BayStream frame relay switch software is not setting the BECN bit. 1 -- the BayStream frame relay switch software is setting the BECN bit.
  • Page 112 For an advertisement to the remote end of a PVC segment: DLCMI ignores wfFrSwRnniVcCrossNetStatus to avoid status update loops. If wfFrSwRnniVcState and wfFrSwRnniVcReceivedStatus are both active, the PVC is advertised as active. Otherwise, the PVC is advertised as inactive. BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 113 DLCMI has sent a cross-network poll during the current polling interval (refer to wfFrSwDlcmiCrossNetPollingInterval). DLCMI transitions wfFrSwRnniVcXNetSent to 2 when it issues a cross-net poll; it transitions wfFrSwRnniVcXNetSent to 1 at the expiration of the polling cycle. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 114 Contains the DLCI used by the remote end of the PVC. This DLCI may be serviced by this BayStream platform (local to local switching), or by another BayStream platform accessed over the switched network (remote to local switching). BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 115 32-bit Traffic Information field. Tagged traffic entering the network across an interface on which congestion control is enabled is placed in priority-specific software queues (specified by bits 0 - 7 of the Traffic Information field), and, in the event of congestion, discarded as specified by the discardability index (bits 8 - 15 of the Traffic Information field).
  • Page 116 BayStream frame relay switch software transmitted across the access line to the CPE or associated switch (on an NNI). This counter is maintained by the BayStream congestion control software, and periodically read by the BayStream billing software as it prepares billing files (refer to wfFrSwUsageUpdateInterval.
  • Page 117 CPE (refer to wfFrSwRnniVcTxNonDeFrames) or associated switch (on an NNI). This counter is maintained by the BayStream congestion control software, and periodically read by the BayStream billing software as it prepares billing files (refer to wfFrSwUsageUpdateInterval).
  • Page 118 Name: wfFrSwRnniVcSetBecnOctets Object ID: 1.3.6.1.4.1.18.3.5.9.6.24.32 Type: Counter Access: Read Only Default: Null Description: Indicates the number of octets in frames sent to the interface in which this switch set the BECN bit. BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 119 Type: Counter Access: Read Only Default: Null Description: Indicates the number of octets in frames received over the interface that were discarded, excluding any frames in which the DE bit was set. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 120 Read Only Default: Null Description: This counter, which is maintained by the BayStream congestion control software, contains the number of frames addressed to wfFrSwRnniVcDlci that the BayStream frame relay switch software dropped because the PVC was inactive (refer to wfFrSwRnniVcState). Name:...
  • Page 121 Indicates the number of frames received over this interface in which the DE bit was set. Name: wfFrSwRnniVcRecvDeOctets Object ID: 1.3.6.1.4.1.18.3.5.9.6.24.44 Type: Counter Access: Read Only Default: Null Description: Indicates the number of octets in frames received over the interface in which the DE bit was set. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 122 Indicates the number of frames received over the interface in which the BECN bit was set. Name: wfFrSwRnniVcRecvBecnOctets Object ID: 1.3.6.1.4.1.18.3.5.9.6.24.48 Type: Counter Access: Read Only Default: Null Description: Indicates the number of octets in frames received over the interface in which the BECN bit was set. BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 123 Indicates the number of excess burst frames dropped on this virtual circuit. Name: wfFrSwRnniVcDropExcessBurstOctets Object ID: 1.3.6.1.4.1.18.3.5.9.6.24.52 Type: Counter Access: Read Only Default: Null Description: Indicates the number of excess burst octets dropped on this virtual circuit. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 124 5 -- the switch will redirect the PVC from the backup circuit to the primary if the cross-network of the primary becomes active. 6 -- the switch will redirect the PVC from the primary circuit to the backup if the cross-network of the primary becomes inactive. BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 125 (or semimanual) operation of the redirect; will allow traffic only through backup. 21 (Hold Down) -- the down state is used as an intermediate state at switching time (for not more than 1 second); all traffic is dropped. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 126 Object ID: 1.3.6.1.4.1.18.3.5.9.6.24.60 Type: Integer Access: Read Only Default: 1 (inactive) Description: Contains the cross-network status of the backup remote end of the PVC. Values may be 1 (Inactive) 2 (Active) BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 127 Indicates the virtual path identifier (VPI) associated with the frame relay PVC identified by the virtual circuit identifier (VCI). This parameter is relevant only when frame relay/ATM interworking is enabled for this PVC. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 128 This parameter is relevant only when the ATM/FR interworking is enabled for this PVC. 1 (Map frame relay DE to ATM CLP) 2 (Set CLP to 1) 3 (Set CLP to 0) BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 129 PVC on the second segment. If you are configuring a BayStream gateway PVC on the first segment, and you set up the PVC on the remote segment of the BayStream as an ingress PVC, the setting of this object has no meaning. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 130 Indicates to the calling end of an SPVC call request whether to use any available DLCI or a specified DLCI. A value of 2 (Specific) indicates that the called DCLI value is specified in wfFrSwRnniVcCallReqCalledDlci. 1 (any) 2 (specific) BayStream Multiservice Software Version 7.3 115385-D Rev 01...
  • Page 131 Indicates the number of times the call request agent should retry failed call setup requests before declaring the SPVC to be invalid. Name: wfFrSwRnniVcCalledNumber Object ID: 1.3.6.1.4.1.18.3.5.9.6.24.75 Type: Octet String Access: Read Only Default: No default Description: Specifies the called party number. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...

  • Page 132: Data Link Connection Management Interface

    The following attribute is new to the wfFrSwDclmiEntry table. Name: wfFrSwDlcmiBillingEnable Object ID: 1.3.6.1.4.1.18.3.5.9.6.1.1.68 Type: Integer Access: Read/Write Default: Enabled Description: Indicates whether the PVC billing feature on this access channel is set to enable. BayStream Multiservice Software Version 7.3 115385-D Rev 01...

  • Page 133: High Speed Serial Interface

    1.3.6.1.4.1.18.3.5.9.6.1.1.71 Type: Integer Access: Read/Write Default: Disabled Description: This attribute enables the Annex A software loopback detection feature. High Speed Serial Interface The following HSSI attributes are new to the wfHSSIEntry table. 115385-D Rev 01 BayStream Multiservice Software Version 7.3...
  • Page 134 Name: wfHssiLoopback Object ID: 1.3.6.1.4.1.18.3.4.7.1.67 Type: Integer Access: Read/Write Default: No default Description: Loopback type requested: Local Digital (Loop A), Local Line (Loop B), Remote Line (Loop C), or none. BayStream Multiservice Software Version 7.3 115385-D Rev 01...

  • Page 135: Statistical Data Collection

    A value of 1 within the bit mask indicates that the BayStream data collection software monitors and reports the associated ATM counter; a value of 0 within the bit mask indicates that the BayStream data collection software ignores the associated ATM counter. The default value (0xFFFFFE00) monitors and reports the first 22 items in, mask positions.

  • Page 136: Table 9. Atm Bit Mask

    AtmizerVclRxBufResc AtmizerVclRxPageResc AtmizerVclTxPacketsOkWrap AtmizerVclTxPacketsOk AtmizerVclTxCellsOkWrap AtmizerVclTxCellsOk AtmizerVclTxOamCount AtmizerVclTxFlowCtrlCount AtmizerVclTxOversizedSDUs AtmizerVclTxLackBufCredits AtmizerVclTxLackPageCredits 8 - 0 (LSB) Not Used BayStream Multiservice Software Version 7.3 Object ID 1.3.6.1.4.1.18.3.4.23.3.4.1.4 1.3.6.1.4.1.18.3.4.23.3.4.1.5 1.3.6.1.4.1.18.3.4.23.3.4.1.6 1.3.6.1.4.1.18.3.4.23.3.4.1.7 1.3.6.1.4.1.18.3.4.23.3.4.1.8 1.3.6.1.4.1.18.3.4.23.3.4.1.9 1.3.6.1.4.1.18.3.4.23.3.4.1.10 Yes 1.3.6.1.4.1.18.3.4.23.3.4.1.11 Yes 1.3.6.1.4.1.18.3.4.23.3.4.1.12 Yes 1.3.6.1.4.1.18.3.4.23.3.4.1.13 Yes 1.3.6.1.4.1.18.3.4.23.3.4.1.14 Yes 1.3.6.1.4.1.18.3.4.23.3.4.1.15 Yes...

  • Page 137: The Virtual Circuit Table

    Default: No default Description: Specifies the calling party number. Name: wfFrSwVcAddressType Object ID: 1.3.6.1.4.1.18.3.5.9.6.7.1.77 Type: Integer Access: Read Only Default: No default Description: Specifies the type of addressing format (X121 or E164). 115385-D Rev 01 BayStream Multiservice Software Version 7.3...

  • Page 138: Changes To Configuring Frame Relay Switching Services

    This parameter is relevant only when frame relay to ATM interworking is enabled for this PVC. Instructions: Accept the default. MIB Object ID: 1.3.6.1.4.1.18.3.5.9.6.7.1.67 BayStream Multiservice Software Version 7.3 SET FECN TO 1 SET FECN TO 0 115385-D Rev 01...

  • Page 139: Changes To Configuring Frame Relay To Atm Interworking

    Function: Identifies the virtual path of the PVC. The virtual channel identifier (VCI) is part of the cell header. The cell header can contain a maximum of 16 VCI bits. Instructions: Enter a value from 32 through 8191. MIB Object ID: 1.3.6.1.4.1.18.3.5.9.6.7.1.64 115385-D Rev 01 BayStream Multiservice Software Version 7.3...

  • Page 140: Change To Configuring Atm Trunks

    Mode 1B for the DXI Mode value, enter a value from 32 through 63. If you select Mode 2 or Mode 2 Proprietary, enter a value from 32 through 8191. MIB Object ID: 1.3.6.1.4.1.18.3.5.9.5.14.1.4 BayStream Multiservice Software Version 7.3 115385-D Rev 01...

This manual is also suitable for:

Baystream 7.3

Table of Contents
