- Page 1 BayStream 6.10 (Revision 14) Release Notes BayStream Multiservice Software Version 6.10 (Revision 14) BayStream Site Manager Software Version 6.10 (Revision 14) December 1997...
- Page 2 Portions of the code in this software product are Copyright © 1988, Regents of the University of California. All rights reserved. Redistribution and use in source and binary forms of such portions are permitted, provided that the above...
- Page 3 Upon delivery of the Software, Bay Networks grants to licensee a personal, nontransferable, nonexclusive license to use the Software with the Equipment with which or for which it was originally acquired, including use at any of licensee’s facilities to which the Equipment may be transferred, for the useful life of the Equipment unless earlier terminated by default or cancellation.
- Page 4 Licensee shall not reverse assemble, reverse compile, or in any way reverse engineer the Software. [Note: For licensees in the European Community, the Software Directive dated 14 May 1991 (as may be amended from time to time) shall apply for interoperability purposes. Licensee must notify Bay Networks in writing of any such intended examination of the Software and Bay Networks may provide review and assistance.]...
-
Page 5: About This Guide
This document describes anomalies resolved in BayStream™ Multiservice Software Version 6.10 (Revision 14) and BayStream Site Manager 6.10 (Revision 14). Acronyms DLCI DLSw DVMRP FRSW IGMP ISDN LLCP OSPF PCAP BayStream Multiservice Software Version 6.10 (Revision 14) About This Guide... -
Page 6: Ordering Bay Networks Publications
The Bay Networks Press catalog is available on the World Wide Web at support.baynetworks.com/Library/GenMisc. Bay Networks publications are available on the World Wide Web at support.baynetworks.com/Library/tpubs. BayStream Multiservice Software Version 6.10 (Revision 14) Reverse Address Resolution Protocol Synchronous Data Link Control... -
Page 7: Bay Networks Customer Service
Technical Solutions Center Telephone number Billerica, MA Santa Clara, CA Valbonne, France Sydney, Australia Tokyo, Japan BayStream Multiservice Software Version 6.10 (Revision 14) Telephone number 800-2LANWAN; then enter Express Routing Code (ERC) 290, when prompted, to purchase or renew a service contract 978-916-8880 (direct) - Page 9 This Bay Networks report describes fixes to anomalies found in BayStream Multiservice Software Version 6.10 (Revision 14) and BayStream Site Manager Software Version 6.10 (Revision 14). Anomaly: OSPF Max Aged external type 1 routes are not getting aged out of the IP routing table.
- Page 10 Resolved: The software now calculates the files size and inserts it in the record header correctly. ________________________________________________________________________________ Anomaly: The wfStatsDcLbcEntry counters line byte counter stops updating.
- Page 11 Although the slot did not decode the information element properly, the slot did process outgoing calls correctly. The software incorrectly managed the value of the extension bit in the calling address information element (IE). This prevented determining the calling E.164 address correctly.
- Page 12 The software should have included the LLCP information element in the connect message for the negotiated call. Presently, the LLCP is not being included in the connect message for this call.
- Page 13 When updating the DLCI IE, the SVC software did not always set the Preferred/ Exclusive bit to 1. Resolved: The software is modified to set the Preferred/Exclusive bit to 1 when it updates the DLCI information element. ________________________________________________________________________________ BayStream Multiservice Software Version 6.10 (Revision 14)
- Page 14 33790 Description: When the BayStream software received a SETUP message in which the calling party address was not identical to the local port address, the call request was rejected with a message bearing a cause code that indicated “Invalid IE.” In this case, it would be more accurate to issue a rejection message with a cause code indicating “Unallocated...
- Page 15 Site Manager failed to configure Multiline on three QMCT1 logical lines. Configuring Multiline on two logical lines was successful but the third logical line failed. Resolved: The software is modified to enable configuring multiline on three QMCT logical lines. ________________________________________________________________________________ Anomaly: The STA entity was not available in the Site Manager Trap Configuration menu.
- Page 16 Site Manager displayed is AG13110114 for the DS3 card. The correct part number is AG13110115. Resolved: The software now displays the correct part number for the DS3 card. ________________________________________________________________________________ Anomaly: The LAPF entity is not available in the Site Manager Trap Configuration menu.
