$6 KEYPAD
➥ Pushing a key selects the operating band.
• [(GENE)•] selects the general coverage band.
➥ Pushing the same key 2 or 3 times calls up other
stacked frequencies in the band. (p. 24)
• Icom's triple band stacking register memorizes 3 fre-
quencies in each band.
➥ After pushing [(F-INP)ENT], enters a keyed fre-
quency or memory channel. Pushing [(F-
INP)ENT] or [Y Y ]/[Z Z ] is necessary at the end.
(pgs. 25, 77)
• e.g. to enter 14.195 MHz, push [(F-INP)ENT] [1] [4]
[•] [1] [9] [5] [(F-INP)ENT].
$7 MEMO PAD-WRITE SWITCH [MP-W] (p. 82)
Programs the selected readout frequency and op-
erating mode into a memo pad.
• The 5 most recent entries remain in memo pads.
• The transmit frequency is programmed when pushed to-
gether with [XFC].
• The memo pad capacity can be expanded from 5 to 10
in set mode for your convenience. (p. 102)
$8 SPLIT SWITCH [SPLIT] (p. 71)
➥ Turns the split function ON and OFF when
pushed.
➥ Turns the split function ON, equalizes the sub
readout frequency to the main readout and sets
the sub readout for frequency input when pushed
for 1 sec. in non-FM modes.
• The offset frequency is shifted from the main readout
frequency in FM mode. (pgs. 52, 100)
• The quick split function can be turned OFF using set
mode. (p. 100)
➥ Turns the split function ON and shifts the sub
readout frequency after input an offset (±4 MHz
in 1 kHz steps).
$9 DUALWATCH SWITCH [DUALWATCH] (p. 63)
➥ Turns the dualwatch function ON and OFF when
pushed.
➥ Turns the dualwatch function ON and equalizes
the sub readout frequency to the main readout
when pushed for 1 sec.
• The quick dualwatch function can be turned OFF
using set mode. (p. 98)
%0 MAIN/SUB CHANGE SWITCH [CHANGE]
➥ Switches the frequency and selected memory
channel between main and sub readouts when
pushed.
• Switches between transmit frequency and receive fre-
quency when the split frequency function is ON.
(p. 71)
➥ Equalizes the sub readout frequency to the main
readout frequency when pushed for 1 sec.
(Quick split function)
(Quick dualwatch function)
PANEL DESCRIPTION
%1 VFO/MEMORY SWITCH [VFO/MEMO]
➥ Switches the selected readout operating mode
between the VFO mode and memory mode when
pushed. (pgs. 23, 77)
➥ Transfers the memory contents to VFO when
pushed for 1 sec. (p. 80)
%2 MAIN/SUB•M.SCOPE SWITCH
[MAIN/SUB•M.SCOPE]
➥ Push momentarily to select access to the main or
sub readout. (p. 23)
• The sub readout frequency is displayed in outline or
mesh font. The sub readout functions only during split
operation or dualwatch.
➥ Push for 1 sec. to turn the mini spectrum scope
screen indication ON and OFF. (p. 55)
• The mini spectrum scope screen can be indicated
with another screen, such as memory, set mode
screen, simultaneously.
%3 LCD FUNCTION DISPLAY (See p. 9 for details.)
Shows the operating frequency, function switch
menus, spectrum scope screen, memory channel
screen, set mode settings, etc.
