Icom IC-756PROIII Instruction Manual page 101

■ Level set mode
S S S S B B T T B B W W ( ( N N A A R R ) ) H H
These items set the transmission passband width for
narrow setting by selecting the lower and higher fre-
quencies.
Lower freq. : 2500 (default), 2700 and 2900 Hz
M M o o n n i i t t o o r r L L e e v v e e l l
This item adjusts the transmit IF signal monitor level
from 0% to 100% in 1% steps.
See p. 70 for details.
S S i i d d e e T T o o n n e e L L e e v v e e l l
This item adjusts the CW side tone level from 0% to
100% in 1% steps.
See p. 70 for details.
S S i i d d e e T T o o n n e e L L e e v v e e l l L L i i m m i i t t
This item allows you to set a maximum volume level
for CW side tones. CW side tones are linked to the
[AF] control until a specified volume level is reached
— further rotation of the [AF] control will not increase
the volume of the CW side tones.
B B e e e e p p L L e e v v e e l l
This item adjusts the volume level for confirmation
beep tones from 0% to 100% in 1% steps. When
beep tones are turned OFF, this setting has no effect.
B B e e e e p p L L e e v v e e l l L L i i m m i i t t
This item allows you to set a maximum volume level
for confirmation beep tones. Confirmation beep tones
are linked to the [AF] control until a specified volume
level is reached — further rotation of the [AF] control
will not increase the volume of the beep tones.
(continued)
2 5 0 0
2500 Hz (default)
50% (default)
50% (default)
O O N N
CW side tone level is limited
with [AF] (default)
50% (default)
O O N N
Beep level is limited with
[AF] (default)
12
SET MODE
5 0 %
5 0 %
O O F F F F
CW side tone level is linked
to [AF]
5 0 %
O O F F F F
linked
Beep level is to [AF]
12
96
