• To send/read memory contents
When sending or reading memory contents, additional code
as follows must be added to appoint the memory channel.
➥ Additional code: 0000–0101 (0100=P1, 0101=P2)
• Band stacking register
To send or read the desired band stacking register's con-
tents, combined code of the frequency band and register
codes as follows are used.
For example, when sending/reading the oldest contents in
the 21 MHz band, the code "0703" is used.
• Frequency band code
Code Frequency band Frequency range (unit: MHz)
01 1.8
02 3.5
03 7
04 10
05 14
06 18
07 21
08 24
09 28
10 50
11 GENE
• Register code
Code Registered number
01
02
03
1.800000– 1.999999
3.400000– 4.099999
6.900000– 7.499999
9.900000–10.499999
13.900000–14.499999
17.900000–18.499999
20.900000–21.499999
24.400000–25.099999
28.000000–29.999999
50.000000–54.000000
Other than above
1 (latest)
2
3 (oldest)
CONTROL COMMAND
• Channel code for memory keyer
To send or read the desired memory keyer contents, the
channel and character codes as follows are used.
• Channel code
Code Channel number
01
02
03
04
• Character's code
Character ASCII code
0–9 30–39 Numerals
A–Z 41–5A Alphabetical characters
a–z 61–7A Alphabetical characters
space 20 Word space
/ 2F Symbol
? 3F Symbol
, 2C Symbol
. 2E Symbol
^ 5E e.g., to send
✱
2A Inserts contact number (can be
used for 1 channel only)
• Character's code for my call
Character ASCII code
0–9 30–39 Numerals
A–Z 41–5A Alphabetical characters
a–z 61–7A Alphabetical characters
space 20 Word space
– 2D Symbol
. 2E Symbol
/ 2F Symbol
• FM split frequency (HF/50 MHz) setting
The following data sequence is used when sending/reading
the FM split frequency setting.
q w
X 0 X X
16
M1
M2
M3
M4
Description
, enter ^4254
BT
Description
e r
0 X XX
16
