Icom IC-756PROIII Instruction Manual page 116

16
CONTROL COMMAND
• Command table
Command Sub command
00 —
01 Same as
command 06
02 —
03 —
04 —
05 —
06 00
01
02
03
04
05
07
08
07 —
B0
B1
C0
C1
D0
D1
08 —
0001–0101*
09 —
0A —
0B —
0E 00
01
02
03
12
13
22
23
0E A1–A7
B0
B1
D0
D3
0F 00
01
10 00
01
02
03
04
05
06
07
08
11 00
06
12
18
111
Description
Send frequency data
Send mode data
Read band edge frequencies
Read operating frequency
Read operating mode
Set frequency data
Select LSB
Select USB
Select AM
Select CW
Select RTTY
Select FM
Select CW-R
Select RTTY-R
Select VFO mode
Exchange main and sub readouts
Equalize main and sub readouts
Turn the dualwatch OFF
Turn the dualwatch ON
Select main readout
Select sub readout
Select memory mode
Select memory channel
1
* P1=0100, P2=0101
1
Memory write
Memory to VFO
Memory clear
Scan stop
Programmed/memory scan start
Programmed scan start
∂F scan start
Fine programmed scan start
Fine ∂F scan start
Memory scan start
Select memory scan start
Set ∂F scan span (A1=±5 kHz,
A2=±10 kHz, A3=±20 kHz,
A4=±50 kHz, A5=±100 kHz,
A6=±500 kHz, A7=±1 MHz)
Set as non-select channel
Set as select channel
Set scan resume OFF
Set scan resume ON
Turn the split function OFF
Turn the split function ON
Select 10 Hz (1 Hz) tuning step
Select 100 Hz tuning step
Select 1 kHz tuning step
Select 5 kHz tuning step
Select 9 kHz tuning step
Select 10 kHz tuning step
Select 12.5 kHz tuning step
Select 20 kHz tuning step
Select 25 kHz tuning step
Attenuator OFF
Attenuator ON (6 dB)
Attenuator ON (12 dB)
Attenuator ON (18 dB)
Command Sub command
12 00
01
13 00
01
02
14 01 + Level data [AF] level setting (0=max. CCW to
02 + Level data [RF] level setting (0=max. CCW to
03 + Level data [SQL] level setting (0=11 o'clock to
06 + Level data [NR] level setting (0=min. to
07 + Level data Inside [TWIN PBT] setting or IF
08 + Level data Outside [TWIN PBT] setting
09 + Level data [CW PITCH] setting (0=low pitch
0A + Level data [RF POWER] setting (0=mini. to
0B + Level data [MIC GAIN] setting (0=mini. to
0C + Level data [KEY SPEED] setting (0=slow to
0D + Level data [NOTCH] setting (0=low freq. to
0E + Level data [COMP] setting (0=mini. to
0F + Level data [BK-IN DELAY] setting (0=short
10 + Level data [BAL] level setting (0=max. CCW,
12 + Level data [NB] level setting (0=mini. to
15 + Level data Monitor gain setting (0=0% to
16 + Level data VOX gain setting (0=0% to
17 + Level data Anti-VOX gain setting (0=0% to
18 + Level data LCD contrast setting (0=0% to
19 + Level data LCD bright setting (0=0% to
15 01
02
11
12
13
14
16 02
12
Description
Select/read antenna selection
(00=ANT1, 01=ANT2 : Add 0 or 1
to turn [RX ANT] OFF or ON, re-
spectively.)
Announce with voice synthesizer
(00=all data; 01=frequency and
S-meter level; 02=receive mode)
255=max. CW)
255=11 o'clock)
255=max. CW)
255=max.)
shift setting (0=max. CCW,
128=center, 255=max. CW)
(0=max. CCW, 128=center,
255=max. CW)
to 255=high pitch)
255=max.)
255=max.)
255=fast)
255=high freq.)
255=max.)
delay to 255=long delay)
128=center, 255=max. CW)
255=max.)
255=100%)
255=100%)
255=100%)
255=100%)
255=100%)
Read squelch condition
Read S-meter level
Read Po meter level
Read SWR meter level
Read ALC meter level
Read COMP meter level
Preamp (0=OFF; 1=preamp 1;
2=preamp 2)
AGC selection (1=Fast; 2=Mid;
3=Slow)
