Level Set Mode - Icom IC-756PROIII Instruction Manual

12
SET MODE

■ Level set mode

S S S S B B T T x x T T o o n n e e ( ( B B a a s s s s ) )
This item adjusts the bass level of the transmit audio
tone in SSB mode from –5 dB to +5 dB in 1 dB steps.
S S S S B B T T x x T T o o n n e e ( ( T T r r e e b b l l e e ) )
This item adjusts the treble level of the transmit audio
tone in SSB mode from –5 dB to +5 dB in 1 dB steps.
S S S S B B T T B B W W ( ( W W I I D D E E ) ) L L
These items set the transmission passband width for
wide setting by selecting the lower and higher fre-
quencies.
Lower freq. : 100 (default), 300 and 500 Hz
S S S S B B T T B B W W ( ( W W I I D D E E ) ) H H
These items set the transmission passband width for
wide setting by selecting the lower and higher fre-
quencies.
Higher freq.: 2500, 2700 and 2900 Hz (default)
S S S S B B T T B B W W ( ( M M I I D D ) ) L L
These items set the transmission passband width for
middle setting by selecting the lower and higher fre-
quencies.
Lower freq. : 100, 300 (default) and 500 Hz
S S S S B B T T B B W W ( ( M M I I D D ) ) H H
These items set the transmission passband width for
middle setting by selecting the lower and higher fre-
quencies.
Higher freq.: 2500, 2700 (default) and 2900 Hz
S S S S B B T T B B W W ( ( N N A A R R ) ) L L
These items set the transmission passband width for
narrow setting by selecting the lower and higher fre-
quencies.
Lower freq. : 100, 300 and 500 Hz (default)
95
0 d B
0 dB (default)
0 d B
0 dB (default)
1 0 0
100 Hz (default)
2 9 0 0
2900 Hz (default)
3 0 0
300 Hz (default)
2 7 0 0
2700 Hz (default)
5 0 0
500 Hz (default)
