Thank you for purchasing this Panasonic product.
■ This manual is common to all the models regardless of suffixes of the Model No.
z for USA, Canada, EU countries
B: Black model, the standard zoom lens supplied
W: White model, the standard zoom lens supplied
z for Korea
B: Black model, the standard zoom lens supplied
z for India
BD: Black model, the standard zoom lens supplied
z for Taiwan
B: Black model, the standard zoom lens supplied
z for other countries or regions with power cord for 100 V - 120 V
BX: Black model, the standard zoom lens supplied
WX: White model, the standard zoom lens supplied
z for other countries or regions with power cord for 200 V - 240 V
BE: Black model, the standard zoom lens supplied
WE: White model, the standard zoom lens supplied
■ Before operating this product, please read the instructions carefully and save this manual
for future use.
■ Before using this product, be sure to read "Read this first!" ( x pages 5 to 16).
Operating Instructions
DLP™ Projector
Model No.
Functional Manual
Commercial Use
PT-RCQ10
PT-RCQ80
LB: Black model, the lens sold separately
LW: White model, the lens sold separately
W: White model, the standard zoom lens supplied
LBD: Black model, the lens sold separately
LBX: Black model, the lens sold separately
LWX: White model, the lens sold separately
LBE: Black model, the lens sold separately
LWE: White model, the lens sold separately
ENGLISH
DPQP1295ZA/X1

Advertisement

Table of Contents
loading

Summary of Contents for Panasonic PT-RCQ80

  • Page 1 PT-RCQ10 Model No. PT-RCQ80 Thank you for purchasing this Panasonic product. ■ This manual is common to all the models regardless of suffixes of the Model No. z for USA, Canada, EU countries B: Black model, the standard zoom lens supplied...
  • Page 2: Table Of Contents

    Contents Contents Read this first! Chapter 3 Basic Operations Switching on/off the projector Chapter 1 Preparation Connecting the power cord Power indicator Precautions for use Switching on the projector Intended use of the product When the initial setting screen is displayed Cautions when transporting Making adjustments and selections Cautions when installing...
  • Page 3 Contents [PICTURE] menu [PROJECTOR SETUP] menu [PICTURE MODE] [PROJECTOR ID] [CONTRAST] [PROJECTION METHOD] [BRIGHTNESS] [LENS] [COLOR] [OPERATION SETTING] [TINT] [LIGHT OUTPUT] [COLOR TEMPERATURE] [BRIGHTNESS CONTROL] [WHITE GAIN] [STANDBY MODE] [GAMMA] [QUICK STARTUP] [SYSTEM DAYLIGHT VIEW] [NO SIGNAL SETTING] [SHARPNESS] [INITIAL STARTUP] [NOISE REDUCTION] [STARTUP INPUT SELECT] [DYNAMIC CONTRAST]...
  • Page 4 Contents Chapter 5 Operations Network connection Connecting via wired LAN Connecting via wireless LAN Web control function Computer that can be used for setting Accessing from the web browser Using the data cloning function Copying the data to another projector via LAN Copying the data to another projector using Updating the firmware Updating the firmware via LAN...
  • Page 5: Read This First

    Read this first! Read this first! WARNING: THIS APPARATUS MUST BE EARTHED. WARNING: To prevent damage which may result in fire or shock hazard, do not expose this appliance to rain or moisture. This device is not intended for use in the direct field of view at visual display workplaces. To avoid incommoding reflexions at visual display workplaces this device must not be placed in the direct field of view.
  • Page 6 Read this first! WARNING: RISK OF ELECTRIC SHOCK. DON’T OPEN Indicated on the projector The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 7 Read this first! (for Taiwan) This projector is the Class 1 laser product that complies with IEC/EN 60825-1:2014. 第 1 類雷射產品 (for India) This projector is the Class 1 laser product that complies with IEC/EN 60825-1:2014. (for other countries or regions) This projector is the Class 1 laser product that complies with IEC/EN 60825-1:2014.
  • Page 8 Supplier’s Declaration of Conformity Model Number: PT-RCQ10B / PT-RCQ10W / PT-RCQ10LB / PT-RCQ10LW PT-RCQ80B / PT-RCQ80W / PT-RCQ80LB / PT-RCQ80LW Trade Name: Panasonic Responsible Party: Panasonic Corporation of North America Address: Two Riverfront Plaza, Newark, NJ 07102-5490 General Contact: http://www.panasonic.com/support Projector Contact: https://panasonic.net/cns/projector/ This device complies with Part 15 of the FCC Rules.
  • Page 9 L or colored RED. How to replace the fuse: Open the fuse compartment with a screwdriver and replace the fuse. Importer’s name and address within the European Union Panasonic Marketing Europe GmbH Panasonic Testing Centre Winsbergring 15, 22525 Hamburg, Germany...
  • Page 10 Read this first! r Hazard distance (IEC 62471-5:2015) The distance from the projection lens surface, at which the level of exposure has reached the level of the applicable Exposure Limit Value, is known as the hazard distance (HD) or safety distance. Do not look into the projected light from inside the hazard distance (within RG3 range).
  • Page 11 0.52 0.39 ET-DLE450 0.40 0.27 0.51 0.38 ET-DLE250 0.37 0.23 0.45 0.34 PT-RCQ80 ET-DLE350 0.37 0.23 0.45 0.34 ET-DLE450 0.38 0.24 0.47 0.35 *1 HD: Hazard Distance *2 The values of D1 to D4 will change in accordance with the lens shift amount. Each value in the table is the maximum value.
  • Page 12 Read this first! WARNING: r POWER The wall outlet or the circuit breaker shall be installed near the equipment and shall be easily accessible when problems occur. If the following problems occur, cut off the power supply immediately. Continued use of the projector in these conditions will result in fire or electric shock, or will cause visual impairment.
  • Page 13 If liquid enters inside of the projector, consult your dealer. f Particular attention must be paid to children. Use the ceiling mount bracket specified by Panasonic. Using the ceiling mount bracket other than the specified one will result in falling accidents.
  • Page 14 Read this first! CAUTION: r POWER When disconnecting the power cord, be sure to hold the power plug and power connector. If the power cord itself is pulled, the lead will become damaged, and fire, short-circuits or serious electric shocks will result.
  • Page 15 Read this first! CAUTION: r ACCESSORIES When not using the projector for an extended period of time, remove the batteries from the remote control. Failure to observe this will cause the batteries to leak, overheat, catch fire or explode, which may result in fire or contamination of surrounding area.
  • Page 16 Read this first! Brazil Only Brasil Apenas r Manuseio de baterias usadas BRASIL Após o uso, as pilhas e/ou baterias deverão ser entregues ao estabelecimento comercial ou rede de assistência técnica autorizada. Cobrir os terminais positivo (+) e negativo (-) com uma fita isolante adesiva, antes de depositar numa caixa destinada para o recolhimento.
  • Page 17 “Operating Instructions – Basic Guide” is supplied with the product. At least three (3) years from delivery of this product, Panasonic will give to any third party who contacts us at the contact information provided below, for a charge no more than our cost of physically performing source code distribution, a complete machine-readable copy of the corresponding source code covered under GPL V2.0, LGPL...
  • Page 18 DRIVE technology. (x page 54) *1 When [OPERATING MODE] is set to [NORMAL] A value for PT-RCQ10. A value for PT-RCQ80 is 8 000 lm. *2 When [DYNAMIC CONTRAST] is set to [3] 4. Connect the power cord. Easy and highly flexible setup (x page 64) ▶...
