Service log
The "Service log" area shows all the message types that were selected in the "Log settings
for service" area.
The entries contain the following properties:
Table 7- 18
Property
Date/time
Type
Entry
With the "Update", "Save as" and "Reset" buttons, you can control the entries:
● Update
The log is read in again by the communication module and the list is updated. The log
entries displayed include the most current data (200 KB).
● Save
The log read out by the communication module is saved as a *.csv file.
● Reset
The log is deleted in the communication module.
● Service file
The log read out by the communication module is saved as an *.slf file. The service file
contains additional information relevant to Siemens service personnel.
With a large number of log entries in the history, it may take several minutes before these
are displayed.
SIMATIC RF166C
Operating Instructions, 12/2019, C79000-G8976-C578-01
Displayed properties of the log messages
Description
Time stamp when the entry was made by the communication module.
Note that the time stamp is generated by the device clock (UTC time). This
time is compared with the time zone set on the PC and displayed accordingly.
Type of message
Which message types are signaled depends on the check boxes enabled in
the menu item "Settings - General" in the "Log settings" area.
Text of the message
