Configuration using the WBM
7.3 The menu items of the WBM
Parameter
Reader mode
Transponder type
You can find a detailed description of these parameters in the following paragraphs.
1)
The "Transponder type" parameter
Selection of the transponders used. The selection depends on the value specified in the
parameter "Ident device / system". The following transponder types can be selected:
Reader parameter assignment
RF290R
RF300 general
RF380R
RF300 Gen 2 general
RF380R Gen 2
RF300, MOBY E
ISO 15693
ECC mode
68
Parameter value
Normal operation
P2P master
P2P master + ISO
P2P master + RF300
P2P slave
1)
Default value
Description
Normal operation
Selection of the required reader mode. This
parameter is intended for trained users. As a
rule, the "Normal operation" operating mode of
the reader is used.
For P2P mode, one reader must be configured
as a "P2P slave" and one reader as a "P2P
master". If the P2P master also communicates
with ISO or RF300 transponders, you must
select the appropriate parameter value.
Selection of the transponder types used.
1)
Values
ISO 15693
MDS D3xx, Infineon
RF300
ISO 15693 General
MDS D3xx, Infineon
MDS D4xx, Fujitsu - 4 KB
MDS D1xx, NXP
MDS D2xx, TI
MDS D261, STM
RF300
MOBY E
RF300, MOBY E
None
ISO 15693 General
MDS D3xx, Infineon
MDS D4xx, Fujitsu - 4 KB
MDS D1xx, NXP
MDS D2xx, TI
MDS D261, STM
MDS D5xx, Fujitsu - 8 KB
On
Off
Operating Instructions, 12/2019, C79000-G8976-C578-01
SIMATIC RF166C
