Configuration using the WBM
7.3 The menu items of the WBM
Parameter
Diagnostic
messages
Read point name
Transmission
speed
User mode
The parameter values of the basic parameters can be preset automatically using the
"Autoconfiguration" button. By pressing the button, the communication module automatically
identifies the device connected to the interface and sets the appropriate parameter values.
Using the "Update firmware" link, you jump to the "System - Reader firmware" menu item in
which you can update firmware for the connected reader.
66
Parameter value
RF300 general, fast
protocol
RF300 fast protocol
RF380R fast protocol
RF600
Freeport
None
Hard errors
Hard/soft errors
--
19.2 kBd
57.6 kBd
115.2 kBd
921.6 kBd
Ident profile/RFID stand-
ard profile
FB 45
Default value
Description
None
Shows which diagnostic messages have been
set in STEP 7 (cf. Section "Parameterization of
the diagnostics (Page 131)"):
•
•
•
--
In the text box, you can assign a name to the
read point(s) (for example, "Incoming goods
gate 5" or "Welding robot 21"). Note that the
name is required for addressing the reader via
OPC UA.
115.2 kBd /
Selection depends on the Ident device/system
921.6 kBd
being used. With this parameter, you set the
data transmission speed between the commu-
nication module and reader.
Ident profile/RFID
Shows which block has been set in STEP 7:
standard profile
•
•
Operating Instructions, 12/2019, C79000-G8976-C578-01
None:
Apart from standard diagnostics, no other
alarms are generated.
Hard errors:
Critical hardware errors/faults are reported
by the S7 diagnostics.
Hard/soft errors
Critical hardware errors and errors that oc-
cur during command processing are report-
ed by the S7 diagnostics. The "Ext_Diag" bit
is set.
Ident profile/RFID standard profile:
The program block for the Ident profile/RFID
standard profile is used on the controller.
FB 45:
Single tag mode. FB 45
(PROFIBUS/PROFINET) is used in the con-
troller.
SIMATIC RF166C
