Byte
Additional information
15
16
17
18
19
20
21
22
23
You can find the description of error code in the following table.
1)
Error codes of the diagnostics text messages
The following table lists the error codes of the diagnostics alarms (byte 19 of the diagnostics
frame).
Table 10- 6
Error code (hex)
0x0F
0x03
0x11
0x12
0x14
0x20
0x21
0x81
0x82
0x83
0x31
0x32
0x33
0x34
0x35
0x36
0x37
0x38
0x39
0x3A
0x3B
0x3C
0x3D
SIMATIC RF166C
Operating Instructions, 12/2019, C79000-G8976-C578-01
Name Description
moby_code_1 0
moby_code_2 0
moby_code_3 0
moby_code_4 Error information of FB 45 ("Error_MOBY")
meldecode Error codes for diagnostics alarms
counter_high Continuous event counter high-order byte
counter_low Continuous event counter low-order byte
fw_version_high Firmware version high-order byte
fw_version_low Firmware version low-order byte
Error codes of the diagnostics text messages of the communication module
Error description
Communication module started up
Connection error to the reader
Short-circuit on the reader
Error in the firmware
Fatal error
Hardware fault
Loader error
Download active
Download done
Download error
Antenna 1 not connected
Antenna 2 not connected
Antenna 3 not connected
Antenna 4 not connected
Antenna 5 not connected
Antenna 6 not connected
Antenna 7 not connected
Antenna 8 not connected
Antenna 1: Antenna type or version is incorrect
Antenna 2: Antenna type or version is incorrect
Antenna 3: Antenna type or version is incorrect
Antenna 4: Antenna type or version is incorrect
Antenna 5: Antenna type or version is incorrect
Service and maintenance
10.1 Diagnostics
1)
