BMC
you want to display in the list. Some examples of other sensors include Temperature Sen-
sors, Fan Sensors, and Voltage Sensors etc.
Select a particular sensor from the list. You can view the Thresholds for this sensor on the
right hand side of the screen.
Thresholds are of six types:
Lower Non-Recoverable (LNR)

Lower Critical (LC)

Lower Non-Critical (LNC)

Upper Non-Recoverable (UNR)

Upper Critical (UC)

Upper Non-Critical (UNC)

The threshold states could be:
Lower Non-critical - going low,
Lower Non-critical - going high,
Lower Critical - going low,
Lower Critical - going high,
Lower Non-recoverable - going low,
Lower Non-recoverable - going high,
Upper Non-critical - going low,
Upper Non-critical - going high,
Upper Critical - going low,
Upper Critical - going high,
Upper Non-recoverable - going low,
Upper Non-recoverable - going high.
A graphical view of these events (Number of event logs vs. Thresholds) can be viewed as
shown in the Sensor Readings Page screenshot.
FRU I
NFORMATION
3-22
